SERVICE MANUAL
CAUTION : Before servicing this chassis, read the "PRODUCT SAFETY SERVICE FOR VIDEO PRODUCTS" section
on page 2 of this manual.
All manuals and user guides at all-guides.com
CONTENTS
SERVICE PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . 2,3
BLOCK DIAGRAMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
ELECTRICAL TROUBLE SHOOTING GUIDE. . . . . . . . . . 5,15
PRINTED CIRCUIT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16,20
REPLACEMENT PARTS LIST . . . . . . . . . . . . . . . . . . . . . . 21,24
MODEL
DVD-300

Advertisement

loading
Need help?

Need help?

Do you have a question about the DVD-300 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Prology DVD-300

Summary of Contents for Prology DVD-300

  • Page 1 All manuals and user guides at all-guides.com SERVICE MANUAL MODEL DVD-300 CAUTION : Before servicing this chassis, read the "PRODUCT SAFETY SERVICE FOR VIDEO PRODUCTS" section on page 2 of this manual. CONTENTS SERVICE PRECAUTIONS ..... . . 2,3 BLOCK DIAGRAMS .

  • Page 2: Product Safety Servicing Guidelines For Video Products

    All manuals and user guides at all-guides.com PRODUCT SAFETY SERVICING GUIDELINES FOR VIDEO PRODUCTS CAUTION: DO NOT ATTEMPT TO MODIFY THIS PRODUCT IN ANY WA Y AND SUBJECT: X-RADIATION N E V E R P E R F O R M C U S T O M I Z E D I N S T A L L AT I O N S W I T H O U T 1.

  • Page 3: Servicing Precautions

    All manuals and user guides at all-guides.com SERVICING PRECAUTIONS CAUTION : Before servicing the DVD covered by this Electrostatically Sensitive (ES) Devices service data and its supplements and ADDENDUMS, read Some semiconductor (solid state) devices can be damaged and follow the SAFETY PRECAUTIONS NOTE : if easily by static electricity.
  • Page 4 All manuals and user guides at all-guides.com OVERALL BLOCK DIAGRAM XS100 TO PICK UP XS103 MECHANISM CHASSIS SLED+ SLED- VIDEO 27MHz SERVO RF AMP XS102 ENCODER & TRAY HCU04 DRIVER D1890 CLOSE CHROMA CS4955 RED/AGND OPEN LUMA UNLOD BLUE/AGND BA5954 16M SDRAM* 2 LOAD CVBS2...
  • Page 5 All manuals and user guides at all-guides.com Electrical Trouble Shooting Guide Connection of the unit is correct. Setting of the unit is correct Is power normal? Refer to power guide. Is fluoresce display correct? Refer to display guide Is open/close normal? Refer to open/close guide Can disc be read?
  • Page 6 All manuals and user guides at all-guides.com Power Circuit abnormal Start 12V out of output Board normal 12V AC input L401 is open XS402 is open XP002 is open Is there pulse Is there pulse wave in V302? wave in V301? C301 or R301 is open.
  • Page 7 All manuals and user guides at all-guides.com Display abnormal START Check if voltage of screen F1 and F2 is 3.3V. Check if voltage of 34 pin of UPD16311 is -24V. Does the screen Check grounded negative voltage of screen F1 and F2. appear? Replace UPD16311.
  • Page 8 All manuals and user guides at all-guides.com Open/close abnormal The door isn't open. Is "OPEN" showed on the screen? Is there voltage difference Check if RMC pin of in XP102UNLOAD pin and XS107 has a waveform. LOAD pin? Does XS107 power have voltage? Does drive motor have voltage?
  • Page 9 All manuals and user guides at all-guides.com Read disc abnormal DISC IN Refer to focus guide. Focus on? Refer to laser guide Is laser normal? Refer to focus guide Does the disc turn? Refer to TOC guide Can TOC be read? Normal...
  • Page 10 All manuals and user guides at all-guides.com Video abnormal Check connection between Is voltage of XS109 normal? video encoder and XS109. No picture, no sound. Replace main board. Check jack of output board No picture, have sound. or replace main board. Have picture, no color or color Check main board and replace disappeared during playback .
  • Page 11 All manuals and user guides at all-guides.com Audio abnormal Have picture, no sound Check connection between R, L pin of XP001 Check if voltage of R, L pin and PCM1723 of XP001 is normal Is N001 and N002 signal Check 4558 and surrounding components output? Is transistor V304 and Replace transistor...
  • Page 12 All manuals and user guides at all-guides.com Focus abnormal No focus 1. Check connection cord. Does normal voltage at FCS+ 2. Replace pickup. and FCS- of XS100? 1. Check connection between 14, 7 pin of BA5945 and FCS+, FCS- of XS100. Does normal voltage at 2.
  • Page 13 All manuals and user guides at all-guides.com Laser abnormal No laser 1. Check connection between pickup Is LD pin of XS100(18, 30) and main board. 4.5V? 2. Replace pickup. 1. Check connection between D1890 of pin LD and XS100. Does voltage at D103 2.
  • Page 14 All manuals and user guides at all-guides.com Turn abnormal Disc doesn't turn. Check if voltage of SP+ and Check connection of mechanism. SP- of XS103 are different. 1. Check connections between BA5954 and XS103. Check if voltage of 11 and 2.
  • Page 15 All manuals and user guides at all-guides.com TOC abnormal TOC doesn't read. 1. Refer to laser guide. Limited switch is closed. 2. Check slide motor and connections Is laser on? to main board. Is FOK normal? 1. Check connection between 39 pin of D1890 and 7 pin of XS100.

  • Page 16: Output Board

    All manuals and user guides at all-guides.com OUTPUT BOARD...
  • Page 17 All manuals and user guides at all-guides.com KEY BOARD...
  • Page 18 All manuals and user guides at all-guides.com POWER BOARD...
  • Page 19 All manuals and user guides at all-guides.com 168 KEY BOARD 168 OUTPUT BOARD 168 POWER BOARD...
  • Page 20 All manuals and user guides at all-guides.com DSM7012B DECODER...

  • Page 21: Replacement Parts List

    All manuals and user guides at all-guides.com REPLACEMENT PARTS LIST PART No. PARTS NAME Q'TY DVD300 S8027 KHL232C(UL) LOADING 01003 D168K KEY ASS'Y 0856 DC168 POWER ASS'Y 00948 DSM7012B DECODER ASS'Y 0857 D168OUT OUTPUT ASS'Y S3230 RCA CORD AUDIO S3231 RCA CORD VIDEO S3118 WIRE...
