Frigidaire FFC09C4CW Factory Parts Catalog

Frigidaire FFC09C4CW Factory Parts Catalog

Frigidaire ffc09c4cw: supplementary guide
Hide thumbs
1
2
3
4
5
6
7

Advertisement

Quick Links

Download this manual
PRODUCT NO.
BASE MODEL NO.
FFC09C4CW1
FFC09C4CW
MARKET
North America
WIRING DIAGRAM - # 216929600
OWNER'S GUIDE - # 216802800 ENERGY GUIDE - # 216794008
SERVICE DATA SHEET - # 216929600
ELECTROLUX HOME PRODUCTS, INC.
P.O BOX 212378, AUGUSTA , GA 30917
FACTORY PARTS CATALOG
SERIES
COLOR
134A
white
Publication No.
5995397261
031010
-EN/SERVICE /MLR
365
FREEZER
VOLTS
115
CHEST FREEZER
Model number:
FFC09C4CW
©2003 Electrolux Home Products, Inc.
All rights reserved

Advertisement

loading

Related Manuals for Frigidaire FFC09C4CW

Summary of Contents for Frigidaire FFC09C4CW

  • Page 1 PRODUCT NO. BASE MODEL NO. FFC09C4CW1 FFC09C4CW MARKET North America WIRING DIAGRAM - # 216929600 OWNER’S GUIDE - # 216802800 ENERGY GUIDE - # 216794008 SERVICE DATA SHEET - # 216929600 ELECTROLUX HOME PRODUCTS, INC. P.O BOX 212378, AUGUSTA , GA 30917...
  • Page 2 Publication No FFC09C4CW1 5995397261 DOOR 10/03...
  • Page 3 POS. NO 14 # 16 # 47 # # = Fast-moving Parts * = Non-Illustrated Parts FFC09C4CW1 DOOR PART NO DESCRIPTION 216481001 Gasket-door,white 5303925107 Lock Assy 216702900 Key,lock 216829800 Panel-lid 216923001 Plug button,1/4" ,white 216117935 Lid,white 216816801 Insert-nameplate 216822900 Switch,light/lamp ,ramp 216846400 Light Bulb/Lamp 216817600...
  • Page 4 Publication No FFC09C4CW1 5995397261 CABINET 10/03...
  • Page 5 POS. NO 21 # # = Fast-moving Parts * = Non-Illustrated Parts FFC09C4CW1 CABINET PART NO DESCRIPTION 216117700 Catch-lock 216502600 Plug,drain ,interior 216073905 Plug-drain,exterior 216117500 Breaker-hinge side,white 216117600 Breaker-lock side 216105600 Breaker-ends,white 216707200 Knob,temp control 216787700 Control-temperature 06594648 Light-signal,amber 216337700 Screw,hex washer head ,10-24 x 0.500 216478800 Hinge Assy...
  • Page 6 Publication No FFC09C4CW1 5995397261 SYSTEM 10/03...
  • Page 7 POS. NO 29 # # = Fast-moving Parts * = Non-Illustrated Parts FFC09C4CW1 SYSTEM PART NO DESCRIPTION 5300120781 Condenser 216634500 Drier-filter 216927800 Harness-main 216056400 Clip,compressor mtg ,SPRING 216707700 Screw,8-18 X 1/2 5308002681 Grommet,compressor 216888300 Compressor,w/o electricals 216888500 Starter,relay 216100113 Overload Protector 216707800 Screw,PH ,8-32 x 1/2 ,wiring harness 216347800...
