Summary of Contents for Vulcan-Hart YK-D Series
- Page 1 INSTRUCTION MANUAL Model Series YK-D Hot Runner Controllers...
- Page 2 HOW TO SET TEMPERATURE AND FUNCTIONAL PARAMETERS TO SET TEMPERATURE: Press UP or DOWN arrow keys to desired temperature. The controller will confirm and store the setting until it is changed. NORMAL STARTUP Press MODE key for 2 seconds, or until BLUE indicator light turns to MANUAL Press MODE key for 2 seconds or until BLUE indicator light turns to STANDBY Turn SOFT START function ON or OFF by pressing the MODE key and the SETUP key simultaneously.
- Page 3 PANEL DESCRIPTION PV - ACTUAL TEMPERATURE INDICATOR LIGHTS HEAT HEATER OUTPUT BOOST FAST HEATING ALARM FAULT INDICATOR SV - SET TEMPERATURE INDICATOR LIGHTS NORMAL AUTOMATIC CONTROL MODE MANUAL MANUAL CONTROL MODE STANDBY STANDBY MODE KEY FUNCTIONS ARROW UP / DOWN ADJUST HEAT SETUP FUNCTION OPTION KEY...
- Page 4 YK-D-15A Specifications ITEM PARAMETER Input Voltage 185-250 VAC Frequency 50-60 HZ Operating Temperature -20C / 60C (-4F/140F) Storage Temperature -30 / 70C (-22F/158F) Thermocouple Type J or K (adjustable) Over Temp Alarm Limit 30C (+85F) Low Temp Alarm Limit -30C (-85F) Temperature Unit C or F Fuses...
