PRODUCT NO.
BASE MODEL NO.
FFC05C3CW0
FFC05C3CW
MARKET
North America
WIRING DIAGRAM - # 216787900, SERVICE DATA - # 216787900
OWNER'S GUIDE - # 216802800
ENERGY GUIDE - # 216793805
ELECTROLUX HOME PRODUCTS, INC.
P.O BOX 212378, AUGUSTA , GA 30917
FACTORY PARTS CATALOG
SERIES
COLOR
134A
white
Publication No.
5995390407
030512
-EN/SERVICE /MLR
365
FREEZER
VOLTS
115
CHEST FREEZER
Model number:
FFC05C3CW0
©2003 Electrolux Home Products, Inc.
All rights reserved
Advertisement
Related Manuals for Frigidaire FFC05C3CW0
Summary of Contents for Frigidaire FFC05C3CW0
- Page 1 PRODUCT NO. BASE MODEL NO. FFC05C3CW0 FFC05C3CW MARKET North America WIRING DIAGRAM - # 216787900, SERVICE DATA - # 216787900 OWNER’S GUIDE - # 216802800 ENERGY GUIDE - # 216793805 ELECTROLUX HOME PRODUCTS, INC. P.O BOX 212378, AUGUSTA , GA 30917...
