- Page 1 Installation Instructions Use and Care Information Instructions d'installation Utilisez et d'entretien Instrucciones de instalación Información de uso y cuidado KSEG24XU - KSEG30XU...
- Page 2 READ AND SAVE THESE INSTRUCTIONS BEFORE YOU START INSTALLING THIS RANGE HOOD WARNING: - TO REDUCE THE RISK OF A RANGE TOP GREASE FIRE: a) Never leave surface units unattended at high settings. Boilovers cause smoking and greasy spillovers that may ignite. Heat oils slowly on low or medium setting. Suzette, Cherries Jubilee, Peppercorn Beef Flambé).
- Page 3 When cutting or drilling into wall or ceiling, do not damage electrical wiring and other hidden utilities. Ducted fans must always be vented to the outdoors. ALL WALL AND FLOOR OPENINGS WHERE THE RANGE HOOD IS INSTALLED MUST BE SEALED. This Range Hood requires at least 24"...
- Page 4 ELECTRICAL REQUIREMENTS A 120 volt, 60 Hz AC-only electrical supply is required on a separate 15 amp fused circuit. A time-de- lay fuse or circuit breaker is recommended. The fuse must be sized per local codes in accordance WARNING • Electrical ground is required on this Range Hood. •...
- Page 5 RANGE HOOD DIMENSIONS 21" 47 " RANGE HOOD DIMENSIONS 28" 47 "...
- Page 6 INSTALLATION HEIGHT REQUIREMENTS MIN. 24" OVER ELECTRIC MIN. 30" OVER GAS WARNING THE INCA SMART IS NOT DESIGNED FOR USE OVER PRO-STYLE COOKING SURFACES, INSTALLATIONS OVER PRO-STYLE COOKING SURFACES WILL COMPLETELY VOID THE WARRANTY OF THIS PRODUCT .
-
Page 7: Main Parts
MAIN PARTS Components Ref. Qty. Product Components Hood Body, complete with: Controls, Light, Filters,Blower. Damper ø 5" Ref. Qty. Installation Components Screws (for hood installation) Screws 1/8"x1/2" (for Cover installation) Qty. Documentation Instruction Manual Torx Screwdriver Pozi Screwdriver... - Page 8 Parts needed - 5" Round Metal ductwork . Available Accessories Activated Charcoal Filter sku #; KITFC142 Two men required for installation Wear work gloves for safety...
- Page 9 Choose your ducting method Ducted Venting Installation Non Ducted - Recirculation Caution: If an elbow is required, Requires purchase of Activated do it as far away from the hood's Charcoal Accessory # KITFC142 exhaust opening as possible. Requires purchase of Grille and screws for air outlet cover.
- Page 10 INSTALL THE RANGE HOOD Remove the bottom of the Range Hood by pulling forward as shown.
- Page 11 The Hood can be installed directly on the underside of the cabinet (minimum 24" for electric ranges and 30" for gas ranges). Create an opening in the bottom of the Cabinet, as shown. Attention: The cabinet must be accessible so that you can access the hood cable and plug in the future, after installing the product.
- Page 12 Insert the hood until the side supports snap into place. Lock in position by tightening the screws Vf from underneath the hood. Fasten using the 10 screws 12a provided. Attention: KSEG24XU uses 8 screws KSEG30XU uses 10 screws...
- Page 13 Replace the bottom of the Range Hood by 4 screws 12b as shown.
- Page 14 CHOOSE YOUR DUCTING METHOD Non Ducted - Ducted Venting Installation Recirculation Option Install Damper that is included with the Hood before connecting to the ductwork. For Non-Ducted Recirculation venting, route the ductwork to a location above the hood where the discharge is vented back into the room.
- Page 15 ELECTRICAL INSTALLATION WITH CONNECTION CABLE GROUNDING INSTRUCTIONS This appliance must be grounded. In the event of an electrical short circuit, grounding reduces the risk of electric shock by providing an escape wire for the electric current. This appliance is equipped with a cord having a grounding wire with a grounding plug. The plug must be plugged into an outlet that is properly installed and grounded.
- Page 16 For Non-Ducted Recirculation Option as indicated. Required Activated Charcoal Filter Accessory - sku # - KITFC142...
-
Page 17: For Best Results
USE AND CARE INFORMATION For Best Results Range Hood to operate for several minutes after cooking is complete to clear all smoke and odors from the kitchen. Button Function Press the button to turn the light ON and press again to turn it OFF. Move the switch to "1"... -
Page 18: Cleaning Exterior Surfaces
