Canopy Factory 22589 Quick Manual

"Sets Up in 60 Seconds!"
SET UP
STEP 1
Begin by placing your canopy near
the center of the set-up area. Along
with a helper grasp a canopy leg in
each hand. Slightly lift the frame off
the ground and step backwards,
pulling the frame apart until your
arms are fully extended as shown
in the illustration.
STEP 2
Carefully unfold the fabric top and
place it over the frame, making
sure to align the corners of the top
with the corners of the frame.
STEP 3
While taking care not to pinch your fingers, grasp the frame section
marked "Open Here" and push up until the canopy is fully opened.
12 x 12
Please read instructions
COMPLETELY before assembly.
Missing Parts,Need Replacements,or Help
with Assembly Please Contact Customer Service:
1-800-524-9970
West Haven, CT 06516
STEP 4
Slide the auto slider at
each corner up, while
holding the corner of the
frame down until the snap
button engages into the
hole. Then, pull the corner
of the cover down snugly.
STEP 5
Attach the top to the frame by matching the loop fastening strip on
the frame. pull the corners down fully. Push the loop firmly together
at each corner.
STEP 6
Lift up outer legs and slide out the inner legs until the snap button
locks. Repeat on the other legs.
Page 1
Model #22589
POP-UP CANOPY
Note:
Slide out the Middle
inner leg first!
01-22589 1/27/05
