ITEMS INCLUDED:
•
(2) Fan Assembly with steel support straps, hardware and 20 foot power cord
•
(2) Duct Support Straps & hardware
•
(2) Acoustic Flex Duct, 7 foot length with collars
•
Gravity Damper Assembly
•
"Eggcrate" style Inlet Grille (white) with mounting screws
•
Wall Mount Controls with (2) 2-Speed On/Off Switches, White Decora duplex wall
plate, and Plastic Double Gang Wall Box
This device MUST be installed by a qualifi ed agency in accordance with the manufacturer's installation instructions. The defi nition of
a qualifi ed agency is: any individual, fi rm, corporation or company which either in person or through a representative is engaged
in, and is responsible for, the installation and operation of HVAC appliances, who is experienced in such work, familiar with all the
precautions required, and has complied with all the requirements of the authority having jurisdiction.
Installed By:
INSTALLATION MANUAL
®
Everest
WHOLE HOUSE FAN SYSTEMS
EV6.5 MODEL
Please retain these instructions after installation.
Phone:
Series
Installation Date:
P/N 780105004 03/21 Rev A
Advertisement
Table of Contents
Related Manuals for Air+Health Everest Series
Summary of Contents for Air+Health Everest Series
- Page 1 INSTALLATION MANUAL ® Everest Series WHOLE HOUSE FAN SYSTEMS EV6.5 MODEL ITEMS INCLUDED: • (2) Fan Assembly with steel support straps, hardware and 20 foot power cord • (2) Duct Support Straps & hardware • (2) Acoustic Flex Duct, 7 foot length with collars •...
- Page 2 (THIS PAGE LEFT INTENTIONALLY BLANK) P/N 780105004 03/21 Rev A page 2 of 16...
-
Page 3: Safety Considerations
® Thank you for purchasing an Everest ducted Whole House Fan. This fan has been designed to provide many years of natural, quiet, and energy-effi cient cooling. Please take a few minutes to read over this manual and its accompanying documents to make sure you are prepared to install the Whole House Fan system. -
Page 4: Electrical Requirements
All electrical components, whether included with the Everest system or supplied by others, must be rated for the fan system’s electrical load requirements; please refer to the Everest Series specifi cations table for the elec- trical load requirements of the specifi c model to be installed. -
Page 5: Ventilation Requirements
VENTILATION REQUIREMENTS It is very important that the attic be suffi ciently ventilated for the fan system to operate properly. Without adequate ventilation, hot air exhausted from the home cannot easily escape from the attic, which creates back-pressure that will substantially reduce the fan’s performance. Operating this fan in an attic with less net free ventilation area than recommended will decrease its airfl ow and energy effi ciency. - Page 6 • Even though the Everest series fan systems are engineered to be extremely quiet, we specifi cally recommend against installing it in a bedroom as humans’ perception of noise is far greater when the surrounding environment is quiet (such as within a bedroom at night).
- Page 7 INSTALLATION: GRAVITY DAMPER GRAVITY DAMPER ORIENTATION NOTE The ideal orientation of unit’s gravity damper is in a level position. If necessary, however, the damper can be in- stalled at a slight angle. TIP: before beginning the installation, make sure that the fan assembly is undamaged, and that the fan blade rotates freely.
- Page 8 Make sure that the exact location chosen for the rough opening will allow installation of the eggcrate inlet grille, and will not interfere with any lighting fi xtures, smoke alarms, or other objects installed in the ceiling. 5. Remove any insulation from the area of the exact chosen location, and make sure that no wiring, plumbing, bracing or other building elements will interfere with the damper...
- Page 9 INSTALLATION: FAN & DUCT NOTES: • The fan assembly must be soundly supported by attachment to structurally sound framing. Provide additional framing with minimum 2-by-4 lumber as needed for fan support. • Each fan assembly should be positioned with at least 24” of free space in front of the fan, for air to be freely blown into the attic by the fan.
- Page 10 All electrical components, whether included with the Everest system or supplied by others, must be rated for the fan system’s electrical load requirements; please refer to the Everest Series specifi cations table for the for the fan system’s electrical load requirements; please refer to the Everest Series specifi cations table for the electrical load requirements of the specifi c model to be installed.
- Page 11 DIAGRAM 1: For EV6.5 Models Hardwired to Fan Assembly DIAGRAM 2: For EV6.5 Models with Dual 2-Speed Wall Controls P/N 780105004 03/21 Rev A page 11 of 16...
-
Page 12: Operation
FIGURE 10 : STANDARD 2 SPEED SWITCH OPERATION Before starting this fan for the fi rst time, verify that: Before starting this fan for the fi rst time, verify that: • • All wiring and connection have been made according to this manual and all applicable wiring codes and All wiring and connection have been made according to this manual and all applicable wiring codes and standards. -
Page 13: Maintenance And Troubleshooting
MAINTENANCE & TROUBLESHOOTING Make sure the appropriate circuit breakers at the home’s electrical panel are turned OFF before servicing this fan. There is no routine maintenance required for this fan other than making sure the fan assembly and gravity damper are kept clean of any possible buildup of debris. -
Page 14: Specifications
SPECIFICATIONS* Speed Settings: 3 (OFF/LOW/HIGH) - 2 Speed Motors Gravity Damper Rough Opening Dimensions: 14.25 inches W x 36.25 inches L Grille Construction: Aluminum Cube Core, Steel frame with White Powder Coat Fan Diameter: 2 - 18.75 inch sections 2 - 7 ft sections Duct Length: 2 x 16 inches Duct Diameter:... - Page 15 P/N 780800700 RevA P/N 780105004 03/21 Rev A page 15 of 16...
- Page 16 Whole House Fans Whole House Fans Twelve (12) Year Limited Warranty Provisions: 1. Contact Retailer for which original purchase has been made with warranty claim 2. Valid proof of purchase 3. Provide model number, serial number, and date code 4. Labor charges are not covered as part of the limited warranty a.
