18V Li-Ion Cordless Impact Wrench
Instruction Manual
Important
- Please read these instructions fully before operating or maintaining your impact wrench
These instructions contain important information that will help you get the best from your
impact wrench, ensuring it remains safe to operate.
If you need help or have damaged or missing parts, call the Customer Helpline on 1300 889 028
After Sales Support
FREE CALL 1300 889 028
EMAIL:salesau@positecgroup.com
CIW18BWG.9
Advertisement
Related Manuals for ToolPRO CIW18BWG.9
Summary of Contents for ToolPRO CIW18BWG.9
- Page 1 TOOLPRO 18V Li-Ion Cordless Impact Wrench CIW18BWG.9 Instruction Manual After Sales Support FREE CALL 1300 889 028 EMAIL:salesau@positecgroup.com Important - Please read these instructions fully before operating or maintaining your impact wrench These instructions contain important information that will help you get the best from your impact wrench, ensuring it remains safe to operate.
-
Page 2: Table Of Contents
Contents Safety Information.....................3 In The Box........................9 Accessories........................9 Operating Instructions.....................10 Problem solution......................15 Maintenance......................15 Technical Data......................16 Customer Helpline 1300 889 028... -
Page 3: Safety Information
Safety Information Important - Please read these instructions fully before starting assembly Warning Symbols To reduce the risk of injury, Please read the instruction manual Warning Wear ear protection Wear eye protection Wear dust mask For indoor use only (for charger) Fuse Do not burn Li-ion battery. - Page 4 Safety Information Important - Please read these instructions fully before starting assembly General Power Tool Safety Warnings WARNING! Read all safety warnings, instructions, illustrations and specifications provided with this power tool. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference.
- Page 5 Safety Information Important - Please read these instructions fully before starting assembly General Power Tool Safety Warnings have the switch on invites accidents. d) Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations. e) Dress properly.
- Page 6 Safety Information Important - Please read these instructions fully before starting assembly General Power Tool Safety Warnings clips, coins, keys, nails, screws or other small metal objects, that can make a connection from one terminal to another. Shorting the battery terminals together may cause burns or a fire.
- Page 7 Safety Information Important - Please read these instructions fully before starting assembly Additional safety warning for impact wrench 1. Hold power tool by insulated gripping surfaces, when performing an operation where the fastener may contact hidden wiring. Fasteners contacting a “live” wire may make exposed metal parts of the power tool “live”...
- Page 8 Safety Information Important - Please read these instructions fully before starting assembly General Safety Warnings for your battery charger WARNING Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference.
-
Page 9: In The Box
In The Box Parts LED Light Forward/Reverse Rotating Control On/Off Switch With Variable Speed Control Belt Clip Battery Capacity Indicator Battery Pack* Tool Holder Battery Pack Release Button* * Not all the accessories illustrated or described are included in standard delivery. Accessories Belt clip Customer Helpline 1300 889 028... -
Page 10: Operating Instructions
Operating Instructions NOTE: Before using the tool, read the instruction book carefully. Intended Use This tool is intended for the fastening and loosening of bolts, nuts and various threaded fasteners. This tool is not intended for use as a drill. BEFORE PUTTING INTO OPERATION 1. - Page 11 Operating Instructions C) CHARGING INDICATOR This charger is designed to detect some problems that can arise with battery packs. Indicator lights indicate problems (see table below). If this occurs, insert a new battery pack to determine if the charger is OK. If the new battery charges correctly, then the original pack is defective and should be returned to a service center or recycling service center.
- Page 12 Operating Instructions ASSEMBLY 1. INSTALLING AND REMOVING THE BATTERY PACK (NOT SUPPLIED) a) TO REMOVE THE BATTERY PACK (SEE FIG B1) Depress the battery pack release button firmly first and then slide the battery pack out from your tool. b) TO INSTALL THE BATTERY PACK (SEE FIG B2) Slide the fully charged battery pack onto the tool with sufficient force until it clicks into position.
- Page 13 Operating Instructions OPERATION 1. ON/OFF SWITCH (SEE FIG. D) Depress the on/off switch to start and release to stop your tool. The on/off switch is fitted with a brake function which stops your chuck immediately when you quickly release the switch. It is also a variable speed switch that delivers higher speed and torque with increased trigger pressure.
- Page 14 Operating Instructions 4. USING THE SIGHT LIGHT To turn on the light, press the on/off switch and make sure the forward/reverse rotation control is on right/left position. When you release the on/off switch, the light will be off. LED lighting increases visibility-great for dark or enclosed area. 5.
-
Page 15: Problem Solution
Operating Instructions 9. PROTECTION AGAINST DEEP DISCHARGING The Li-ion battery is protected against deep discharging by the “Discharging Protection System”. When the battery is empty, the tool is switched off by means of a protective circuit: The inserted tool no longer rotates. Problem solution 1. -
Page 16: Technical Data
Technical Data Technical Data Table Type CIW18BWG.9 (CIWI -designation of machinery, representative of impact wrench) Voltage 18 V No load speed 0-3200 /min Impact rate 0-3600 bpm Max torque 300 N.m Chuck Size 12.7 mm (1/2˝) Machine weight (without battery) 1.07 kg...
