ODNW60UC / ODNW65UC
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ODNW60UC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cleyver ODNW60UC

Summary of Contents for Cleyver ODNW60UC

  • Page 1 ODNW60UC / ODNW65UC User Manual...

  • Page 2: Table Of Contents

    User Manual 1. WELCOME 2. HEADSET BT OVERVIEW 2.1 HEADSET OVERVIEW 2.2 OPTIONAL ACCESSORIES 3. HOW TO WEAR 3.1 STEREO 3.2 ADJUST THE HEADBAND 3.3 POSITION THE MICROPHONE 3.4 STORING THE MICROPHONE 4. HOW TO CHARGE THE BATTERY 5. HOW TO CONNECT 5.1 CONNECT TO PC (USING USB Dongle) 5.2 CONNECT TO MOBILE DEVICE (USING BLUETOOTH) 6.

  • Page 3: Welcome

    1. WELCOME Thank you for using the BT Headset BT HEADSET FEATURES Connects to PC via USB Dongle Bluetooth adapter Connects to mobile devices via Bluetooth Integrated busylight Rotate the microphone boom-arm back to vertical position when not on calls Superior music and voice capabilities Hi-Fi Sound...

  • Page 4: Headset Bt Overview

    2. HEADSET BT OVERVIEW 2.1 HEADSET Adjustable headband Volume up Power on/Power off/Busylight indicator Multi-function button Volume down Bluetooth Microphone indicator boom-arm USB charging port On/off/connect switch Base Charge Point...

  • Page 5: Optional Accessories

    2.2 INCLUDED ACCESSORIES Carry pouch USB cable Charging Base (Optional)

  • Page 6: How To Wear

    3. HOW TO WEAR 3.1 RIGHT WEARING STYLE The Headset BT can be worn only on the right.

  • Page 7: Adjust The Headband

    3.2 ADJUST THE HEADBAND Adjust the headband to find the most comfortable fit. 3.3 POSITION THE MICROPHONE It is recommended to position the microphone close to your mouth (0.5 inches).

  • Page 8: Storing The Microphone

    The microphone is bendable for personal preference. 3.4 STORING THE MICROPHONE When listening to music or outdoors, the microphone boom-arm can be rotated back to the vertical position near the headband.

  • Page 9: How To Charge The Battery

    4. HOW TO CHARGE THE BATTERY Option 1: The headset battery will charge when connected to a PC using a USB cable, or when using any USB charger supplied with your mobile device. Option 2: If you have a charging base, you could plug the charging base into a powered USB port and then dock the headset.

  • Page 10: How To Connect

    5. HOW TO CONNECT 5.1 CONNECT TO PC (USING USB Dongle) 1. Ensure the headset is switched on. 2. Plug the USB Dongle dongle into a USB port on your PC. The headset and USB Dongle are already pre-connected.

  • Page 11: Connect To Mobile Device (Using Bluetooth)

    5.2 CONNECT TO MOBILE DEVICE (USING BLUETOOTH) 1. Wear the headset. 2. Hold (2 secs) the On/off/connect switch in the connect position until you hear the voice guided instructions. The Bluetooth indicator will flash blue. 3. Follow the voice guided instructions to connect.

  • Page 12: How To Use

    6. HOW TO USE Volume up Power on/Power off/Busylight indicator Multi-function button Volume down Bluetooth indicator USB charging port On/off/connect switch Base Charge Point...

  • Page 13: Calls

    6.1 EVERYDAY USE FUNCTION ACTION LED STATUS Green Light flash Headset on Slide the on switch twice in succession Red Light flash Headset off Slide the off switch twice in succession Pairing Slide the Pair Button Blue Light flash Pairing Blue Light flash successfully twice in succession...

  • Page 14: Multiple Call Handling

    6.2 MULTIPLE CALL HANDLING The headset can accept and handle multiple calls at the same time. FUNCTION ACTION End current call and Tap the answer incoming call Multi-function button Press and hold Put current call on hold (2 secs) the and answer incoming call Multi-function button...

  • Page 15: Support

    7. SUPPORT 7.1 FAQ View the FAQs on www.Vbet.cn 7.2 HOW TO CARE FOR YOUR HEADSET Always store the headset with the power off and safely protected. Avoid storage at extreme temperatures (above 55°C or below -10°). This can shorten battery life and may adversely affect the headset. 8.
  • Page 16 BLUETOOTH ADAPTER SPECIFICATION (USB Dongle) PC connection: USB 2.0 Bluetooth version: Bluetooth range: Up to 30m (100 feet), Class 1 Bluetooth profiles: A2DP (V1.2), Hands free profile (V1.6) Simultaneous Bluetooth connection: Support SoftPhone： Skype for Business/3CX Phone Bluetooth audio bandwidth： HD voice (wideband), A2DP Visual indicators: Multicolor LED...

  • Page 17: Product Disposal Treatment And Fcc Statement

    9. Product Disposal Treatment and FCC statement 1. Dispose of in accordance with local regulations as headphones and recycling regulations. Never treated headset as household waste. Do not dispose of the headset in a fire, this battery may explode. If damaged, the battery may explode. 2.
  • Page 18 Made in China MODEL: ODNW60UC / ODNW65UC FCC ID: 2AC67-9605 BT Declaration of Conformity can be found on...

This manual is also suitable for:

Odnw65uc
