EchoLife
HG8245A/HG8245H/HG8240A/HG8045A/HG8247H
Gateway ONT
V300R013C00
Product Description
Issue
02
Date
2013-09-27
HUAWEI TECHNOLOGIES CO., LTD.

Advertisement

Table of Contents
loading

Related Manuals for Huawei EchoLife HG8245A

Summary of Contents for Huawei EchoLife HG8245A

  • Page 1 EchoLife HG8245A/HG8245H/HG8240A/HG8045A/HG8247H Gateway ONT V300R013C00 Product Description Issue Date 2013-09-27 HUAWEI TECHNOLOGIES CO., LTD.
  • Page 2 Notice The purchased products, services and features are stipulated by the contract made between Huawei and the customer. All or part of the products, services and features described in this document may not be within the purchase scope or the usage scope. Unless otherwise specified in the contract, all statements, information, and recommendations in this document are provided "AS IS"...

  • Page 3: About This Document

    Indicates a tip that may help you solve a problem or save Issue 02 (2013-09-27) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 4 Modified topics:  1.2 Network Applications  1.3 Specifications Differences Between Different Product Models Issue 01 (2013-08-08) This is the first official release for the V300R013C00 version. Issue 02 (2013-09-27) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 5: Table Of Contents

    4.3 GE Port Specifications ........................... 24 4.4 POTS port ..............................25 4.5 CATV Port Specifications ..........................25 4.6 USB Port ................................ 26 4.7 Wireless Network Access ..........................26 Issue 02 (2013-09-27) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 6: Introduction

    As a network terminal, the ONT is deployed at the GPON access layer and connects the home user to the Internet through the optical upstream port. Figure 1-1 shows the position of the ONT on a network. Issue 02 (2013-09-27) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 7: Specifications Differences Between Different Product Models

    This topic introduces the specification differences between ONTs in V300R013C00, specifically, features supported by different ONTs. Item HG8247H HG8245A HG8245H HG8240A HG8045A Ethernet 4xGE 4xFE 4xGE 4xFE 4xFE Access Issue 02 (2013-09-27) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 8 Storage and File Sharing Services 4.2 FE Port Specificatio 4.3 GE Port Specificatio 4.4 POTS port 4.5 CATV Port Specificatio 4.6 USB Port 4.7 Wireless Network Access Issue 02 (2013-09-27) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 9: Product Overview

    Introduced the appearance, interfaces, LEDs, and device parameters of the HG8247H. Appearance Figure 1-2 Appearance of the HG8247H Port/Button Figure 1-3 Figure 1-4 show the ports on the rear panel and side panel of the HG8247H respectively. Issue 02 (2013-09-27) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 10 Indicates auto-sensing 10/100/1000M Base-T Ethernet ports LAN1–LAN4 (RJ-45), used to connect to PCs or IP set-top boxes (STBs). CATV Indicates an RF port, used to connect to a TV set. Issue 02 (2013-09-27) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 11 WLAN function. Indicates the WLAN protected setup. The HG8247H has a fiber management tray. Figure 1-5 shows the optical fiber routing. Figure 1-5 Optical ports on the HG8247H Issue 02 (2013-09-27) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 12 CATV signals are received. CATV port CATV The CATV function is disabled or CATV signals are not received. WPS LED Steady on The WPS function is enabled. Issue 02 (2013-09-27) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 13 The Ethernet connection is not set Connection Table 1-5. Authentication Table 1-5. Steady on The device is powered on. Power supply POWER The power supply is cut off. Issue 02 (2013-09-27) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 14 About 1000 g Operating temperature: 0°C to +40°C Working environment Environment humidity: 5% RH to 95% RH (non-condensing) Pressure environment: 86 kPa to 106 kPa Altitude: 2000 m Issue 02 (2013-09-27) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 15: Hg8245H

    Introduced the appearance, interfaces, LEDs and device parameters of the HG8245H. Appearance Figure 1-7 Appearance of the HG8245H Port/Button Figure 1-8 Figure 1-9 show the ports on the rear panel and side panel of the HG8245H respectively. Issue 02 (2013-09-27) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 16 Indicates VoIP telephone ports (RJ-11), used to connecting to TEL1–TEL2 the ports on telephone sets. Indicates auto-sensing 10/100/1000M Base-T Ethernet ports LAN1–LAN4 (RJ-45), used to connect to PCs or IP set-top boxes (STBs). Issue 02 (2013-09-27) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 17 Indicates the WLAN button, used to enable or disable the WLAN WLAN function. Indicates the WLAN protected setup. Figure 1-10 shows optical ports on the HG8245H. Figure 1-10 Optical ports on the HG8245H Issue 02 (2013-09-27) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 18 Table 1-10 Indications of the LEDs on the HG8245H Description Status Description Always on The device is powered on. Power supply POWER The power supply is cut off. Authentication Table 1-11. Issue 02 (2013-09-27) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 19 WPS LED Blinking system. The WPS function is disabled. Table 1-11 Indications of the PON and LOS LEDs LED Status Description The ONT is disabled by the OLT. Issue 02 (2013-09-27) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 20 Pressure environment: 86 kPa to 106 kPa Altitude: 2000 m Power specifications Power adapter input: 100 V AC to 240 V AC, 50 Hz to 60 Hz Issue 02 (2013-09-27) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 21 Specifications System power supply: 11 V DC to 14 V DC, 2 A Power consumption  Static power consumption: 5 W  Maximum power consumption: 15.5 W Issue 02 (2013-09-27) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 22: Product Functions And Features

     Anti-DoS  Device maintenance Local service configuration, query, and software upgrade on the webpage  Automatic remote service provisioning, device management, and software upgrade through OMCI Issue 02 (2013-09-27) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 23 VLAN filtering, VLAN transparent Ethernet features transmission  VLAN N:1 aggregation and VLAN 1:1 switch Power-saving features  Dynamic power adjustment For details about the features, see the Feature Description. Issue 02 (2013-09-27) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 24: Product Highlights

    On the LAN side, the ONT provides abundant hardware ports to implement multiple access services, including the home network attached storage, Internet access, voice, and video services, providing users with the comprehensive triple play service. Issue 02 (2013-09-27) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 25: Quality Catv Service Transmission

    Only HG8247H supports CATV. 3.3 Secure and Reliable Wi-Fi Access The ONT helps users build a secure and reliable wireless network based on the 802.11 b/g/n Wi-Fi access. Issue 02 (2013-09-27) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 26: Convenient Home Network Attached Storage And File Sharing Services

    The USB port implements the FTP client for home storage, that is, downloading files from the FTP server in a public network to the USB storage device. Issue 02 (2013-09-27) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 27: Secure And Powerful Gateway Functions

    Supports remote fault locating of the ONT through the NMS. Through alarm reporting and remote loopback diagnosis, the fault can be located remotely, which decreases the maintenance cost. Issue 02 (2013-09-27) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 28: Port Specifications

    4.1 GPON Port Specifications This topic describes specifications and standards compliance of the GPON interfaces. Table 4-1 GPON port specifications Parameter Specifications Transmission rate Rx: 2.488 Gbit/s Issue 02 (2013-09-27) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 29: Fe Port Specifications

    Cable specifications Category 5 UTP Compliant standard IEEE 802.3i IEEE 802.3u 4.3 GE Port Specifications This topic describes the specifications and standards compliance of Gigabit Ethernet (GE) ports. Issue 02 (2013-09-27) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 30: Pots Port

    Pulse code modulation (PCM) Frame protocol Time division multiplexing (TDM) Standard compliance ITU-T Q.551 ITU-T Q.552 4.5 CATV Port Specifications This topic describes the specifications of cable TV (CATV) ports. Issue 02 (2013-09-27) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 31: Usb Port

    Automatic rate adjustment  Transmit power adjustment Authentication Open system and shared key  Encryption 64-bit and 128-bit WEP encryption  WPA-PSK, WPA2-PSK, WPA, WPA2, AES, and TKIP Issue 02 (2013-09-27) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 32 Denial of Service Forward Error Correction FAX over IP FoIP FTTH Fiber To The Home GPON Gigabit-capable Passive Optical Network Internet Group Management Protocol IGMP Modem over IP MoIP Issue 02 (2013-09-27) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 33 Universal Plug and Play VLAN Virtual Local Area Network Voice over IP VoIP Wireless Local Area Network WLAN Wired Equivalent Privacy Wi-Fi Protected Access Wi-Fi Protected Setup Issue 02 (2013-09-27) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
