PRODUCT NO.
PLDB999CC0
MARKET
North America
SERVICE DATA SHEET # - 154444501
OWNER'S GUIDE # - 154448401
INSTALLATION INSTRUCTIONS # - 154427301
ENERGY GUIDE LABEL # - 154399007
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
BASE MODEL NO.
SERIES
PLDB999C
PRO GALLERY
Publication No.
5995380135
-EN/SERVICE /ECL
FACTORY PARTS CATALOG
COLOR
stainless
021023
©2002 Electrolux Home Products, Inc.
821
All rights reserved
DISHWASHER
24" Built-In
DISHWASHER
Model No.
PLDB999C
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Frigidaire PLDB999C
Summary of Contents for Frigidaire PLDB999C
- Page 1 PRODUCT NO. BASE MODEL NO. PLDB999CC0 PLDB999C MARKET North America SERVICE DATA SHEET # - 154444501 OWNER’S GUIDE # - 154448401 INSTALLATION INSTRUCTIONS # - 154427301 ENERGY GUIDE LABEL # - 154399007 ELECTROLUX HOME PRODUCTS, INC. P.O. Box 212378, Augusta, GA 30917...
-
Page 2: Control Panel
Publication No. PLDB999CC0 5995380135 CONTROL PANEL 10/02... - Page 3 POS. NO 34 # # = Fast Moving Part * = Non-Illustrated Part CONTROL PANEL PART NO DESCRIPTION 154412205 Panel,control ,stainless 154445405 Insert,control panel ,stainless 154445803 Control,electronic 154200401 Screw,6-10 x 3/8 ,pan plask 154287901 Cover,control 154446105 Nameplate,Pro Series 154423601 Vent assy,active dry ,w/actuator 154436201 Screw,dry duct ,(3) 154433501...
- Page 4 Publication No. PLDB999CC0 5995380135 DOOR 10/02...
- Page 5 POS. NO # = Fast Moving Part * = Non-Illustrated Part DOOR PART NO DESCRIPTION 154414001 Spring,door ,(2) 154325201 Linkage,door spring ,(2) 154093301 Screw,arm assy ,(4) 154325304 Arm Assy,LH 154325303 Arm Assy,RH 154400601 Pin,arm assy 154079601 Nut,arm assy ,and handle mtg. 154299004 Door,inner assy 154230104...
- Page 6 Publication No. PLDB999CC0 5995380135 10/02...
- Page 7 POS. NO 24 # 25 # 29 # # = Fast Moving Part * = Non-Illustrated Part PART NO DESCRIPTION 154209301 Tub assy,w/frame parts 154429101 Strike,door 154211801 Gasket,tub 154200602 Screw,10-16 x 3/8 ,hex 154333902 Roller,tub 5303943103 Screw,w/washer ,(8) 154239801 Tubing,water inlet 5303318539 Clamp,tubing ,(2) 154411003...
-
Page 8: Motor & Pump
Publication No. PLDB999CC0 5995380135 MOTOR & PUMP 10/02... - Page 9 POS. NO 24A* 70 # # = Fast Moving Part * = Non-Illustrated Part MOTOR & PUMP PART NO DESCRIPTION 154247601 Heater 154106201 Nut,heater ,(2) 154289801 Shield,heater terminal 154359701 Bracket,heater ,(2) 154245501 Cover,volute 154246801 Gasket,sump 154365901 Housing,sump 154246502 Retainer,sump 154414101 Spray arm,lower ,w/heat shield 154313601 Spray arm,center...
- Page 10 Publication No. PLDB999CC0 5995380135 FRAME 10/02...
- Page 11 POS. NO # = Fast Moving Part * = Non-Illustrated Part FRAME PART NO DESCRIPTION 154373303 Valve,water 154208701 Brace,front frame 154322903 Toeplate,adjustable ,black 154397203 Kickplate Assy,black ,w/foam 5300808658 Screw,#8A x .375" ,black 154409401 Screw,#8-18 x .375 154200601 Screw,#10-16 x 3/8 154419301 Screw,leveling 154209601...
- Page 12 Publication No. PLDB999CC0 5995380135 RACKS 10/02...
- Page 13 POS. NO 14A* # = Fast Moving Part * = Non-Illustrated Part RACKS PART NO DESCRIPTION 154432602 Rack assy,lower 154424001 Basket,silverware ,main 154424101 Basket,silverware ,(2) ,side 154319519 Rack assy,upper 5304407064 Wheel & bushing assy,upper rack 5300809927 Cap,slide ,(4) 154232701 Slide,rack ,(2) 154174501 Wheel &...
