Frigidaire GLD4355RF Factory Parts Catalog

24-inch built-in dishwasher
Hide thumbs

Advertisement

Quick Links

P30L0078.eps P30C0157.eps P30B0044.eps P30U0023.eps P30M0036.eps P30F0022.eps
P30R0106.eps
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
GLD4355RFB0 GLD4355RFS0
Series
Built-in 24"
Color
black
Owner's Guide English 154580101
Owner's Guide Spanish 154580103
Owner's Guide French
154580102
Service Data Sheet
154580201
Energy Guide
154540031
Installation Instructions 154427301
Market
North America North America
Publication No.
5995475877
06/10/05
(EN/SERVICE/ECL)
821
Built-in 24"
white
154580101
154580103
154580102
154580201
154540031
154427301
24-INCH BUILT-IN
DISHWASHER
Model No.
GLD4355RF
©
Copyright
2006 Electrolux Home Products, Inc.
All rights reserved.

Advertisement

loading

  Also See for Frigidaire GLD4355RF

  Related Manuals for Frigidaire GLD4355RF

  Summary of Contents for Frigidaire GLD4355RF

  • Page 1 Built-in 24" Built-in 24" black white 154580101 154580103 154580102 154580102 154580201 154580201 154540031 154540031 154427301 North America North America 24-INCH BUILT-IN DISHWASHER Model No. GLD4355RF Publication No. 5995475877 06/10/05 (EN/SERVICE/ECL) © Copyright 2006 Electrolux Home Products, Inc. All rights reserved.
  • Page 2: Control Panel

    Publication No: 5995475877 GLD4355RF CONTROL PANEL 10/06...
  • Page 3 154592902 154570901 154540031 154200401 # Functional Parts * Non-Illustrated Parts GLD4355RF CONTROL PANEL A GLD4355RF (GLD4355RFS0) B GLD4355RF (GLD4355RFB0) DESCRIPTION Panel, control, white Panel, control, black Overlay Assy, top switch, white Overlay Assy, top switch, black Board, control Cover, control...
  • Page 4 Publication No: 5995475877 GLD4355RF DOOR 10/06...
  • Page 5 154320301 154425001 154200601 154409401 # Functional Parts * Non-Illustrated Parts GLD4355RF DOOR A GLD4355RF (GLD4355RFS0) B GLD4355RF (GLD4355RFB0) DESCRIPTION Spring, friction pulley, (2) Cable, friction pulley, (2) Screw, arm assy, (4) Arm Assy, LH, w/foam Arm Assy, RH, w/foam Pin, arm assy Nut, arm assy, and handle mtg.
  • Page 6 Publication No: 5995475877 GLD4355RF 10/06...
  • Page 7 154544701 154580801 154528701 154041001 5300807270 # Functional Parts * Non-Illustrated Parts GLD4355RF A GLD4355RF (GLD4355RFS0) B GLD4355RF (GLD4355RFB0) DESCRIPTION Tub assy, w/frame parts Foam, tub, (2) Strike, door Gasket, tub Screw, 10-16 x 3/8, hex Roller Assy, tub, front, (2)
  • Page 8: Motor & Pump

    Publication No: 5995475877 GLD4355RF MOTOR & PUMP 10/06...
  • Page 9 154579701 71 # 154473901 154376001 154200601 # Functional Parts * Non-Illustrated Parts GLD4355RF MOTOR & PUMP A GLD4355RF (GLD4355RFS0) B GLD4355RF (GLD4355RFB0) DESCRIPTION Heater, round Nut, heater, (2) Shield, heater terminal Bracket, heater, (2) Cover, volute Gasket, sump Housing, sump...
  • Page 10 Publication No: 5995475877 GLD4355RF FRAME 10/06...
  • Page 11 154200701 154200601 154571101 154597001 154041001 154409401 # Functional Parts * Non-Illustrated Parts GLD4355RF FRAME A GLD4355RF (GLD4355RFS0) B GLD4355RF (GLD4355RFB0) DESCRIPTION Valve, water Brace, front frame Toeplate, adjustable, white Toeplate, adjustable, black Insulation, toeplate Kickplate Assy, white Kickplate Assy, black Screw, phillips head, white Screw, #8A x .375", black...
  • Page 12 Publication No: 5995475877 GLD4355RF RACKS 10/06...
  • Page 13 154530802 154530902 154581802 154581702 # Functional Parts * Non-Illustrated Parts GLD4355RF RACKS A GLD4355RF (GLD4355RFS0) B GLD4355RF (GLD4355RFB0) DESCRIPTION Rack assy, lower, grey Basket, silverware, grey, main Basket, silverware, grey, (2), side Rack assy, upper, grey Roller, upper rack, (4)
