Page 1 WaveGuide Direction Onboard 2 User Manual...
Page 2 WaveGuide Direction-OnBoard 2 User Manual Version 5.2-1-1 of Nov. 2020 Applicable for product number WG5-DO2-CP Related to software versions: do2 5.2-1 Radac B.V. Elektronicaweg 16b 2628 XG Delft The Netherlands tel: +31(0)15 890 3203 e-mail: info@radac.nl website: www.radac.nl...
Page 3 • Neglect of the general safety precautions for handling tools and use of electricity. The contents, descriptions and speciﬁcations in this installation guide are subject to change without notice. Radac BV accepts no responsibility for any errors that may appear in this user manual.
Page 4: Table Of Contents
Contents Preface Introduction 1 Positioning and installation 1.1 Safety notes ........1.2 Positioning .
Page 5 This manual describes the Compact version of the WaveGuide 5 Direction-OnBoard 2. Please refer to the radac website for all other manuals. Warning Do not use the instrument for anything else than its intended purpose.
Page 6: Positioning And Installation
Caution Modiﬁcation to the instrument may only be carried out by trained personnel that are authorized by Radac BV. Failure to adhere to this will invalidate the warranty and the approval certiﬁcate. Warning In hazardous areas it is compulsory to: •...
Page 7: Positioning
Positioning For obtaining the best results from each WaveGuide sensor, the following positioning criteria must be taken into account: • It is advised to choose a mounting position such that the WaveGuide radar beam is free of large reﬂecting obstacles (the beam of the F08 antenna can be approximated to a conical shape having a 5 [deg] half top angle as shown...
Page 8 • The point array is the recommended conﬁguration in most situations. For that pur- pose a 10 [deg] radar mounting frame WG5-MPD10-CP can be supplied by Radac. Here the three radars are mounted on a single frame. One radar is looking vertically downwards.
Page 9 Radar sensor (functional) position and orientation Tilt angle of radar sensor β α (functional) with respect to vertical North Angle formed by the β line AC (functional) and reference North α β X and Y axis of the Directional System Figure 1.3: Deﬁnitions for WaveGuide Direction-OnBoard 2 systems.
Page 10: The Point Array
Figure 1.4: Top view of the three radar positions labeled A,B Upon request, Radac can provide the mounting plates alone and C in an anticlockwise se- (product no. WG5-MPD10-CP) or the mounting plates to- quence. In this case the labels apply to the physical radars and gether with a mounting frame (product no.
Page 11 The optional point array mounting frame (product no. WG5-MPD10-CP) consists of three parts as shown in ﬁgure 1.6. The mounting frame should be installed on two horizontal beams (the horizontal beams are not included in the mounting frame package). Note: when designing and producing the horizontal mounting beams, enough horizontal distance should be left between the radars and the structure they are mounted to.
Page 12: The Line Array
A mounting plate can be used to ﬁx each radar to two horizontal beams at the desired location (an example sketch of such a plate is given in Fig. 1.9). Upon request, Radac can supply such a mounting plate (product no. WG-MP-SS). During installation it is advised to install the mounting plate ﬁrst and secondly install the radar.
Page 13: The Triangle Array
A mounting plate can be used to ﬁx each radar to two horizontal beams at the desired location (an example sketch of such a plate is given in Fig. 1.11). Upon request, Radac can supply this mounting plate (product no. WG-MP-SS). During installation it is advised to install the mounting plates ﬁrst and secondly install the radars.
Page 14: Wiring
Chapter 2 Wiring Block diagram Figure 2.1: Block diagram of the Waveguide 5 Direction-Onboard 2. The three sensors A, B and C are connected to the local network as well as the processing unit. This diagram assumes the processing unit and the radars to be powered by a single power supply.
Page 15: Waveguide Radar
• The cable must be shielded and can have a maximum length of 80 [m]. Upon request, Radac can supply an optional cable that complies with the WaveGuide system require- ments for power and data transmission. The terminal compartment contains a six pole and a two pole connector as well as a ground connection point, as shown in Fig.
Page 16 Note Connecting the Reset poles for for 0.5 to 2 seconds during operation will cause the sensor to temporarily use the default IPV4 address 192.168.111.71 until the system is rebooted. Connecting the Reset poles for longer than 10 seconds during operation will cause the sensor to reset to default factory settings and reboot.
Page 17: Waveguide Processing Unit
WaveGuide processing unit Note The RS485 connectors labeled as Sensor 1, Sensor 2 and Sensor 3 should not be used. Figure 2.3: Connector panel on the WaveGuide processing unit. The connector panel of the WaveGuide processing unit includes the following functional connectors: •...
Page 18: Waveguide System Commissioning
Chapter 3 WaveGuide system commissioning With all system components correctly connected as described in the previous chapter, the processing unit can be conﬁgured using the following steps (explained in the current chapter): 1. Connect the WaveGuide processing unit to a computer. 2.
Page 19: Step 1. Connect The Waveguide Processing Unit To A Computer
Step 1. Connect the WaveGuide processing unit to a computer Once the WaveGuide system is connected to a Local-Area-Network, communication can be done via the available web interface (Fig. 3.1). For this purpose any web browser with JavaScript enabled can be used. Figure 3.1: The web-interface of the WaveGuide processing unit.
Page 20: Step 2. Become An Authorized User
In that case, the authorization data will be submitted automatically by the browser without a pop-up dialog. The default login password is “radac”. After a successful authorization, the user can view and change settings. After submitting any new settings a reboot dialog will appear.
Page 21: Step 3. Configuration
Step 3. Conﬁguration The conﬁguration page contains ﬁve sections as listed in Table 3.2. Link Description Date&Time For viewing and setting the system time. Network For viewing and changing the network settings. Sensor For viewing and changing the sensor speciﬁc settings and for view- ing reﬂection diagrams.
Page 22: Step 3.2: Adjust Network Settings
network that includes a time server, then the system can be adjusted to synchronize time and date with the local time server using the "Set NTP" button and submitting the local NTP server address. Step 3.2: Adjust network settings Figure 3.4: Adjusting the network settings. The network settings can be modiﬁed via the web-interface (Fig.
Page 23: Step 3.3: Sensor Configuration
Step 3.3: Sensor conﬁguration Figure 3.5: Sensor conﬁguration menu. The WaveGuide Direction-OnBoard 2 is designed with a high level of ﬂexibility in mind, to apply to every possible mounting situation. The sensor menu allows the conﬁguration of those parameters that are speciﬁc to the sensor installation (Fig. ??). During the installation process it is important to register the position of each of the three sensors.
Page 24 Figure 3.6: Preview of the array orientation based on user input. The mounting height above the reference water level, and possibly a number of other parameters, needs to be set for each speciﬁc mounting location. This can be done in the conﬁguration table that is shown in Fig.
Page 25 Max. Range The range maximum in [m] is the maximum distance at which the sensor will detect the water level. In general there is no need to modify this parameter. Yet in some situations it is advised to set this parameter to a value lower than two times the distance from the radar to the lowest expected water level.
Page 26: Step 4: Perform A System Check
Step 4. Perform a system check This section explains how to inspect the quality of measurements after conﬁguring and rebooting the WaveGuide processing unit (the start-up process can take up to 5 minutes): Step 4.1: Check the system information page The system information table can be reached through the status menu item on the right top.
Page 27: Step 4.2: Check The Reflection Diagrams
Step 4.2: Check the reﬂection diagrams The reﬂection diagram for each sensor can be accessed via the sensor conﬁguration page by clicking on the corresponding "reﬂection" button (Fig. 3.9). A reﬂection diagram is a graphic representation of a 25 [ms] scan, where the signal strength [dB] is plotted against the measurement distance [m].
Page 28: Step 4.3: Check Measurements
Step 4.3: Check the measurements On the ’Dashboard’ page, the heave parameter shows data measured during the last 1, 3 or 10 minutes. Please inspect the available heave and slope graphs to visually conﬁrm the measured data. From the same menu all calculated parameters are available. Please take into account that it can take up to 10 minutes to gather enough raw data to calculate the parameters.
Page 29 Default message format The Default format starts a new line for each parameter in the subscription. The time used in the Radac format is Unix Epoch time in milliseconds (UTC time in milliseconds since 00:00:00 on the 1 of January 1970). Each line in the Default format ends with a Line-Feed character (char10).
Page 30 +0001 - 0004 A+9999 Format02 message format Modiﬁcations can be made upon request. For example, the Format02 the Korean Meteoro- logical Administration (KMA format) preferred a readable time format in the Korean time zone. An example of the output strings in the KMA format is: time=2018/01/25 21:55:00;H1=-266.33362cm;...
Page 31: Technical Assistance
Please note that it can take up to 3 minutes to generate and download the diagnostics ﬁle and that it can contain up to 100 [kB] of data. It is recommended to share the diagnostics ﬁle with Radac B.V. because it can help with providing future technical support.
Page 32: Using The System
Dutch government for wave height analysis. It also meets the standards set by the International Association of Oil & Gas Producers (OGP). A detailed description of the SWAP package is available on the Radac website (http://www.radac.nl).
Page 33 Additionally the data can be transferred easily to other computers using an FTP application. Both login name and password for FTP ﬁle transfers are by default set to ’radac’. The port number is set to 21. Figure 4.1: Data logger page.
Page 34: Appendix 1: System Parameters
Appendix 1: System parameters The web user interface presents the raw and processed parameters to the user through the Dashboard page. Tables 1 to 10, describe all the parameters that are measured and calculated by the WaveGuide direction Onboard 2 system. Unless stated otherwise, all processed parameters are calculated once per minute and are based on the most recent 20 minutes of data.
Page 35 Name Description Unit H1/3 Average height of the highest 1/3 of the waves TH1/3 Average period of the highest 1/3 of the waves H1/10 Average height of the highest 1/10 of the waves H1/50 Average height of the highest 1/50 of the waves T1/3 Average period of the longest 1/3 of the periods Average height of all waves...
Page 36 In the directional spectral analysis the frequency range from 30-500mHz is divided in sep- arate frequency bands. These frequency bands are given in the Table 9. Name Description Unit 200-500 100-200 30-100 Peak frequency band ( fmax-∆ f to fmax+∆ f ) Table 9: Frequency bands from 5 [mHz] spectra Per frequency band 2 parameters are calculated.
Page 37: Appendix 2: System Specifications
Appendix 2: System speciﬁcations WaveGuide Direction Onboard 2 - Performance Heave Range 2 - 75 [m] to surface Accuracy ± 1 [cm] Sampling rate 10 [Hz] Vessel draft level Accuracy ± 1 [cm] Processing average Interval 10 [sec], 1, 5 and 10 [min] Wave height range Range 0 - 60 [m]...
Page 38 WaveGuide Sensor - Design Mechanical Dimensions 265 x 245 [mm] (diameter, height) Weight 12.5 [kg] Material Stainless Steel AISI 316L Electrical Power 24-65 [VDC] or 65-240 [VAC] and 14 [W] Radar frequency 9.319 – 9.831 [GHz] Modulation Triangular FMCW Emission max.
Page 39: Appendix 3: Led Blinking Modes
Appendix 3: LED blinking modes The WaveGuide sensor is equipped with a blue indicator LED inside the top lid. The purpose of this LED is is twofold: • The LED functions as a status indicator when in standard operating mode. This is the status mode of the LED.
Page 40 Indicator pattern Deﬁnition Remark Oﬀ No power connected. − Solid on Power is connected and the system is Wait for 2 minutes, after which the in- starting. dicator should change its behavior. Blink 1 time The system is up and running, but no Check the network cable connections.
