- Page 1 WWW.AAPRODUCTSINC.COM INSTRUCTION MANUAL X35-AW / X35-W ( BLK & WHT ) Pick-up Truck Rack With Protective Screen Set X35-AW X35-W...
- Page 2 Rear window while transporting loads. The Cab. Protective Screen is removeable. All Bracket Bars are adjustable, providing more compatible fitments to different model trucks. X35-AW: This is an upgrade extension for X35-A Series truck rack. Single Bar Pickup Truck Utility Ladder Rack with Protective Screen Set.
- Page 3 NSTRUCTION MANUAL AAPRODUCTS INC. For Technical Support Call:1-888-806- 3972 / 626-332-4245 ART LIST PART# X35-AW X35 -W ITEMS Upright Pole ( Left ) Upright Pole ( Right ) Middle Cross-Bar T-Bar Screen Half Bracket Bracket Bar Adjustable Hex-Nut Bolt M10*45mm...
- Page 4 NSTRUCTION MANUAL AAPRODUCTS INC. For Technical Support Call:1-888-806- 3972 / 626-332-4245 NSTALLATION DIAGRAM TEP 1 Adjustable Hex-Nut Adjustable Hex-Nut NOTE: DO NOT tighten any hex-nuts on the T-bars. TEP 2 Mark as needed For outer bed-rail drilling Bed-rail For inner bed-rail drilling Mounting Bolt ( M10*45MM ) TEP 3 &...
- Page 5 NSTRUCTION MANUAL AAPRODUCTS INC. For Technical Support Call:1-888-806- 3972 / 626-332-4245 TEP 4 Screen Adjustable Hex-Nut Bracket Bar NOTE: DO NOT tighten any hex-nuts on the Screen. The Installation The Installation Direction Of Upper Direction Of Lower Bracket Bar Bracket Bar Half Bracket Half Bracket Carriage Bolt...
- Page 6 AA Products Inc™ will remedy defects in the structural integrity of the product related to materials or workmanship by repairing or replacing, at its discretion, a defective product without charge for parts or labor. In addition, AA Products Inc™ may elect, at its discretion, not to repair or replace a defective product but rather to issue to a purchaser a refund equal to the purchase price paid for the product or a credit to be used toward the purchase of a new AA Products Inc™ product.
