USER MANUAL
P R O F E S S I O N A L U S B C A M E R A
w i t h P A N - T I L T - Z O O M F U N C T I O N A L I T Y
Model: C20PTZ
SETUP GUIDE
To learn more about using your camera, scan the
QR code or enter the URL below into your web
browser: MEEaudio.com/CameraHelp

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C20PTZ and is the answer not in the manual?

Questions and answers

Summary of Contents for MEE AUDIO C20PTZ

  • Page 1 P R O F E S S I O N A L U S B C A M E R A w i t h P A N - T I L T - Z O O M F U N C T I O N A L I T Y Model: C20PTZ SETUP GUIDE...

  • Page 2: Getting Started

    Getting Started Installing Batteries Install 2x AAA batteries in the battery compartment located on the back of the remote control Note: Batteries not included Placement Option 1: Table or Tripod Place the camera on a flat, stable surface or on attach to a compatible tripod...
  • Page 3 Getting Started Placement Option 2: Mounting Kit Contents Ceiling Mount 1x mounting plate The camera can also be 3x drywall anchor mounted on a ceiling using the included mounting kit 3x screw Use the included hardware to Push the camera against the attach the mounting plate to the mounting plate and rotate it ceiling as shown.

  • Page 4: Video Setup

    C20PTZ camera camera integrated webcam For more information about using your camera with different applications, scan the QR code or enter the URL below into your web browser: MEEaudio.com/CameraHelp...

  • Page 5: Microphone Setup

    To use the integrated microphone, you may also need to select it from your video recording or teleconferencing app: settings audio MEE C20PTZ camera audio Microphone Array Microphone default communications device This camera also supports up to two external 3.5mm microphones. To use external microphones, simply plug them into the 3.5mm inputs on...

  • Page 6: Camera Overview

    Functionality Camera Overview 4K UHD Lens ANC Mic ANC Mic Power Indicator Power button 3.5 mm 3.5 mm Privacy indicator Mute indicator microphone input microphone input Base IR remote sensor (with 1/4 inch tripod thread)

  • Page 7: Using The Remote Control

    Functionality Using the Remote Control Note: Aim the remote at the IR sensor on the base of the camera. Power on/off Audio mute 50° Pan up Pan left Pan right Pan down Reset camera position and zoom 340° Zoom in Zoom out Vertical flip Increase volume...

  • Page 8: Additional Information

    For more information, visit For Additional Support MEEaudio.com/support View MEEaudio.com/CameraHelp for easy-to-follow setup videos and the latest MEE audio and its logo are registered trademarks of S2E, Inc. troubleshooting information. All rights reserved. Microsoft Windows is a registered trademark of Microsoft ®...

This manual is also suitable for:

Cam-c20ptz
