Summary of Contents for Philips Momentum 276M1
- Page 1 Momentum 276M1 www.philips.com/welcome EN User manual Customer care and warranty 24 Troubleshooting & FAQs...
-
Page 2: Table Of Contents
6.1 Resolution & Preset Modes ... 22 7. Power Management ....23 8. Customer care and warranty . 24 8.1 Philips’ Flat Panel Monitors Pixel Defect Policy ....24 8.2 Customer Care & Warranty ..27 9. Troubleshooting & FAQs ..28 9.1 Troubleshooting ......28... -
Page 3: Important
DC power cord for normal operation. • Please use approved power cord 1.1 Safety precautions and provided by Philips all the time. If maintenance your power cord is missing, please contact with your local service Warnings center. - Page 4 1. Important bezel, ensure that the monitor does the monitor by placing your hand or not tilt downward by more than -5 fingers on the LCD panel. degrees. If the -5 degree downward • Oil-based cleaning solutions may tilt angle maximum is exceeded, the damage the plastic parts and void monitor damage will not be covered the warranty.
-
Page 5: Notational Descriptions
1. Important activate a periodic screen refresh 1.2 Notational Descriptions application if your monitor will The following subsections describe display unchanging static content. notational conventions used in this Uninterrupted display of still or document. static images over an extended period may cause “burn in”, also Notes, Cautions and Warnings known as “after-imaging”... -
Page 6: Disposal Of Product And Packing Material
From the planning, design and production stages, Philips emphasizes the important of making products that can easily be recycled. At Philips, end- of-life management primarily entails This marking on the product or on participation in national take-back... -
Page 7: Setting Up The Monitor
Top Victory Investments Ltd., and Top Victory Investments Ltd. is the warrantor in relation to this product. Philips and the Philips Shield Emblem are registered trademarks of Koninklijke Philips N.V. (4) Gently attach the stand to the and are used under license. - Page 8 2. Setting up the monitor Shading Hood installation instructions Connecting to your PC 1. Assemble the sky-side shading plate with the left and right side shading plates respectively, and use the shaft to pass through and fix it. 2 3 4 7 8 9 10 11 Fast Charger USB hub...
- Page 9 HDD, for example. The display must be powered ON at all times to be able to use this function. Some select Philips displays may not Power or Charge your device when it enters to “Sleep/Standby” mode (Red power LED breathing). In that case, please enter to OSD Menu and select “USB Standby Mode”, then, turn the...
-
Page 10: Operating The Monitor
What is On-Screen Display (OSD)? Description of the control buttons On-Screen Display (OSD) is a feature in all Philips LCD monitors. It allows an end user to adjust screen performance or select functions of the monitors directly through an on-screen instruction window. - Page 11 2. Setting up the monitor Resolution notification Main menu Sub menu Ambiglow Follow Video Follow Audio This monitor is designed for optimal Color Shift Clockwise, Anticlockwise Color Wave Clockwise, Anticlockwise performance at its native resolution, Color Breathing Starry Night Static Mode 2560 ×...
-
Page 12: Remove The Base Assembly For Vesa Mounting
2. Setting up the monitor Height adjustment 2.3 Remove the Base Assembly for VESA Mounting Before you start disassembling the monitor base, please follow the instructions below to avoid any possible damage or injury. 1. Extend the monitor base to its maximum height. - Page 13 2. Setting up the monitor Note This monitor accepts a 100mm x 100mm VESA-Compliant mounting interface. VESA Mounting Screw M4. Always contact manufacturer for wall-mount installation. 100mm 100mm 0° 90° -5° * Display design may differ from those illustrated. Warning • To avoid potential screen damage, such as panel peeling, ensure that the monitor does not tilt downward...
-
Page 14: Image Optimization
How does it work? • FPS: For playing FPS (First Person SmartImage is an exclusive, leading Shooters) games. Improves dark edge Philips technology that analyzes theme black level details. the content displayed on your screen. • Racing: For playing Racing games. Based on a scenario you select,... - Page 15 Developed for wellbeing, picture mode that best fits your needs. Philips LowBlue Mode setting uses There are multiple selections: HDR a smart software technology to Game, HDR Movie, HDR Photo, reduce harmful shortwave blue DisplayHDR 600, Personal, and Off.
-
Page 16: Smartcontrast
3. Image Optimization 3.2 SmartContrast 3.3 HDR Settings in Windows 10 system What is it? Steps Unique technology that dynamically analyzes displayed content and 1. Right click on the desktop, enter to automatically optimizes a Monitor's display settings. contrast ratio for maximum visual clarity 2. -
Page 17: Adaptive Sync
3. Image Optimization 3.4 Adaptive Sync Adaptive Sync PC gaming has long been an imperfect experience because GPUs and monitors STEP 5 update at different rates. Sometimes a GPU can render many new pictures during a single update of the monitor, and the monitor will show pieces of each picture as a single image. - Page 18 3. Image Optimization • AMD Radeon R9 285 • AMD Radeon R7 260X • AMD Radeon R7 260 ■ Processor A-Series Desktop and Mobility APUs • AMD A10-7890K • AMD A10-7870K • AMD A10-7850K • AMD A10-7800 • AMD A10-7700K •...
-
Page 19: Ambiglow
[Color Shift], [Color Wave], [Color image. Whether you are playing games, Breathing], [Starry Night], [Static or watching movies, Philips Ambiglow Mode], [Your Color], [Light Position], offers you a unique and immersive [Speed], [Brightness], [Off]. -
Page 20: Power Delivery And Smart Power
5. Power Delivery and Smart Power 5. Power Delivery and Smart Power Smart Power is an exclusive Philips technology that provides flexible power delivery options. With Smart Power, you can still charge your device without sacrificing the screen brightness, even set your screen as VESA DisplayHDR 600. -
Page 21: Technical Specifications
6.Technical Specifications 6. Technical Specifications Picture/Display Monitor Panel Type Nano IPS Techonology Backlight W-LED system Panel Size 27" W (68.5 cm) Aspect Ratio 16:9 Pixel Pitch 0.2331(H) mm x 0.2331(V) mm Contrast Ratio (typ.) 1,000:1 2560x1440 @ 144Hz (HDMI) Recommended Resolution 2560x1440 @ 240Hz (DP/USB C) Viewing Angle 178°... - Page 22 6.Technical Specifications Plug & Play Compatibility DDC/CI, sRGB, Windows 10/8.1/8/7, Mac OSX Stand Tilt -5 / +20 degree Swivel -35 / +35 degree Height adjustment 130mm Pivot -90 / +90 degree Power AC Input AC Input AC Input Consumption Voltage at Voltage at Voltage at 100VAC , 60Hz...
- Page 23 Finish Glossy/Textured Note 1. This data is subject to change without notice. Go to www.philips.com/support to download the latest version of leaflet. 2. SmartUniformity and Delta E information sheets are included in the box. 3. The version of HDMI and DisplayPort comply with the Compliance Test...
-
Page 24: Resolution & Preset Modes
2. For best output performance, please always ensure that your graphic 51.08 640x480 99.769 card is capable of achieving the 61.91 119.518 640x480 maximum resolution and refresh rate of this Philips display. 31.469 720x400 70.087 29.855 720x480 59.710 31.25 720x576 35.156 800x600 56.25... -
Page 25: Power Management
7.Power Management 7. Power Management If you have VESA DPM compliance display card or software installed in your PC, the monitor can automatically reduce its power consumption when not in use. If an input from a keyboard, mouse or other input device is detected, the monitor will 'wake up' automatically. -
Page 26: Customer Care And Warranty
Pixel Defect Policy single black pixel. Other combinations of lit and dark sub pixels appear as Philips strives to deliver the highest single pixels of other colors. quality products. We use some of the industry's most advanced... - Page 27 Proximity of Pixel Defects Because pixel and sub pixels defects of the same type that are near to one another may be more noticeable, Philips also specifies tolerances for the proximity of pixel defects. Three adjacent lit sub pixels (one white pixel).
- Page 28 In order to qualify for repair or replacement due to pixel defects during the warranty period, a TFT Monitor panel in a Philips flat panel monitor must have pixel or sub pixel defects exceeding the tolerances listed in the following tables.
-
Page 29: Customer Care & Warranty
Please contact our Philips Customer Service Representative or local contact center (by Consumer care number) for more details. Philips Customer Care Center number listed below. -
Page 30: Troubleshooting & Faqs
• Disconnect the monitor from mains This page deals with problems that can power source immediately for safety be corrected by a user. If the problem • Contact with Philips customer still persists after you have tried these service representative immediately. solutions, contact Philips customer service representative. -
Page 31: General Faqs
Service contact information listed in • Shut down your computer, Important information manual and disconnect your old monitor and contact Philips customer service reconnect your Philips monitor. representative. • Turn on your monitor and then turn * Functionality different according to on your PC. - Page 32 Can I connect my monitor to any not use other solvents such as PC, workstation or Mac? ethyl alcohol, ethanol, acetone, Ans.: Yes. All Philips monitors are fully hexane, etc. compatible with standard PCs, Macs and workstations. You may Can I change the color setting of...
- Page 33 EDFU? time after the power has been switched off. Ans.: Important Information manual can be download on the Philips Always activate a moving screen website support page. saver program when you leave your monitor unattended.
- Page 34 This product has been manufactured by and is sold under the responsibility of Top Victory Investments Ltd., and Top Victory Investments Ltd. is the warrantor in relation to this product. Philips and the Philips Shield Emblem are regis- tered trademarks of Koninklijke Philips N.V. and are used under license.
