Owner's manual original language – Lavina
V25E
02/2020
LAVINA
V25E USER MANUAL
®
Tech Support Line: 800-987-8403 | www.superabrasive.com |
info@superabrasive.us
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LAVINA V25E115 and is the answer not in the manual?

Questions and answers

Summary of Contents for Superabrasive LAVINA V25E115

  • Page 1 ® Superabrasive Owner’s manual original language – Lavina V25E 02/2020 LAVINA V25E USER MANUAL ® Tech Support Line: 800-987-8403 | www.superabrasive.com | info@superabrasive.us...
  • Page 2 ® Superabrasive Owner’s manual original language – Lavina V25E 02/2020...

  • Page 3: Table Of Contents

    ® Superabrasive Owner’s manual original language – Lavina V25E 02/2020 Contents 1. WARRANTY AND RETURNS ........................5 1.1 WARRANTY POLICY FOR LAVINA® V25E ..................5 1.2 RETURN POLICY FOR LAVINA® VACUUMS ..................6 2. GENERAL INFORMATION ........................7 2.1 MANUFACTURER ........................... 7 2.2 GENERAL DESCRIPTION .........................
  • Page 4 ® Superabrasive Owner’s manual original language – Lavina V25E 02/2020 11.1 GENERAL PARTS......................... 27 11.2 VACUUM HEAD COVER......................29 11.3 MAIN FILTER CHAMBER ......................31 11.4 INLET VALVE ..........................32 11.5 CARRIAGE ..........................33 11.6 POWER UNIT..........................34 11.7 CONTROL BOARD ........................37 11.8 VACUUM GAUGE ASSEMBLY .....................

  • Page 5: Warranty And Returns

    Superabrasive offers a guarantee on LAVINA® vacuums, covering manufacturing and material defects, for a period of 24 months from the date of purchase, as invoiced by Superabrasive. The following conditions pertain to this warranty: •...

  • Page 6: Return Policy For Lavina® Vacuums

    Vacuums returned without prior authorization will remain property of the sender and Superabrasive Inc. will not be responsible for these. • No vacuums will be credited after 90 days from the date of Superabrasive’s invoice. • All returns must be shipped freight prepaid.

  • Page 7: General Information

    2.1 MANUFACTURER Superabrasive was founded in 1987, as a manufacturer of high quality diamond tools for the stone and concrete industry. Today, Superabrasive is one of the world’s leading companies in the production of diamond tools and floor grinding machinery. At Superabrasive, we strive to deliver the very best solutions to our customers, and enable them to work more efficiently.

  • Page 8: Main Components And Controls

    (needed for maintenance purposes). Customer Service - For customer assistance and technical support call your local distributor or call Superabrasive Inc. at 1-800-987-8403 or visit us at www.superabrasive.com , where you can...

  • Page 9: Technical Data

    ® Superabrasive Owner’s manual original language – Lavina V25E 02/2020 4. TECHNICAL DATA Table 4.1 Model version V25E115 V25E230 V25EU Voltage/Hz 1phx115V50/60Hz 1phx230V50/60Hz 1phx230V50/60Hz 2.5kW 3.6kW 3.3kW Power 3.4HP 4.9HP 4.5HP Amperage Amps 19.5 Amps 19.5 Amps 15 Amps Filter...

  • Page 10: Safety Precautions

    ® Superabrasive Owner’s manual original language – Lavina V25E 02/2020 5.SAFETY PRECAUTIONS 5.1 RECOMMENDED USE The LAVINA® V25E vacuum is designed and manufactured for use with concrete, terrazzo and natural stone floors. It is recommended for use with LAVINA® machines. This vacuum is rated for dry use only, and with a machine of appropriate size.

  • Page 11: Operating The Vacuum

    ® Superabrasive Owner’s manual original language – Lavina V25E 02/2020 • Perform general daily inspections of the vacuum and inspect the vacuum before each use for any sign of damage. • Inspect all safety devices. • The vacuum/filters must be clean and the hose should be connected.
  • Page 12 ® Superabrasive Owner’s manual original language – Lavina V25E 02/2020 • If toxic or harmful substances accidentally enter the vacuum cleaner, the container and filters must be removed and cleaned immediately using the proper protective equipment and safety procedures. • Utilize the locking caster wheel to prevent movement while work is being performed.

  • Page 13: Unpacking, Handling, Transportation And Storage

    ® Superabrasive Owner’s manual original language – Lavina V25E 02/2020 6. UNPACKING, HANDLING, TRANSPORTATION AND STORAGE When unpacking the machine, please check that the following accessories are included: -The hose end fitting; -Steel wand; -Floor brush; -Main vacuum hose with camlock to connect to the machine;...

  • Page 14: Operating With The Vacuum

    ® Superabrasive Owner’s manual original language – Lavina V25E 02/2020 7. OPERATING WITH THE VACUUM IMPORTANT: Before connecting the power cord to the power source, ensure that the electrical voltage corresponds with the requirements identified on the information plate on the vacuum cleaner.

  • Page 15: Main Filter Cleaning

    ® Superabrasive Owner’s manual original language – Lavina V25E 02/2020 7.2 MAIN FILTER CLEANING Figure 7.2 The Lavina V25E uses jet pulse manual filter cleaning. One cycle of filter cleaning takes 10 to 20 seconds, depending on the vacuum’s operator. The filter must be cleaned as the vacuum gauge goes to red or if there’s low suction.

  • Page 16: Main Filter Change

    ® Superabrasive Owner’s manual original language – Lavina V25E 02/2020 7.3 MAIN FILTER CHANGE Figure 7.3 WARNING: 1. Turn off the engine and wait for the fan impeller to completely stop before opening the machine to change filters. Do not touch the exhaust! It will get very hot even when running the engine for a short time.

  • Page 17: Hepa Filter Change

    ® Superabrasive Owner’s manual original language – Lavina V25E 02/2020 7.4 HEPA FILTER CHANGE Figure 7.4.1 Figure 7.4.2 Figure 7.4.3 Figure 7.4.4 Figure 7.4...
  • Page 18 ® Superabrasive Owner’s manual original language – Lavina V25E 02/2020 IMPORTANT: All of the following procedures must be performed with the dust collector turned off (look at the beginning of chapter 7). Before performing any work or maintenance on the vacuum, be sure to wear the proper protective equipment.

  • Page 19: Longopack ® Bag Replacement (Changing Bags)

    ® Superabrasive Owner’s manual original language – Lavina V25E 02/2020 7.5 LONGOPACK ® BAG REPLACEMENT (CHANGING BAGS) Figure 7.5.1 Figure 7.5.2 Figure 7.5 The Lavina® V25E has a LONGOPAC waste system for effective dust storage. This is a 20 m long plastic tube that will be divided into plastic bags using the zip ties attached to the machine.

  • Page 20: Installing Longopac® Refill Packs

    ® Superabrasive Owner’s manual original language – Lavina V25E 02/2020 7.6 INSTALLING LONGOPAC® REFILL PACKS Figure 7.6 When the plastic bag cartridge has reached the end, the plastic bag refill may be installed using the following procedures: 1. At fig. 7.6 pos. 1, you can see the locked position of the LONGOPACK® plastic bag holder and to take it off you should: Lift the holder upwards about 10-15mm to unlock it fig.

  • Page 21: Maintenance And Inspection

    ® Superabrasive Owner’s manual original language – Lavina V25E 02/2020 1. Place the LONGOPAC® bag refill into the support ring. Ensure that the 2 ends of the refill are directed in an upwards position. Pull the inner end of bag refill down over the inside surface of the bag support ring by making sure that the hook of the holder sticks out from the bag (Fig 7.6.1 and 7.6.2).

  • Page 22: Lavina® V25E Electric Circuit Diagram

    ® Superabrasive Owner’s manual original language – Lavina V25E 02/2020 8.1 LAVINA® V25E ELECTRIC CIRCUIT DIAGRAM Figure 8.1...

  • Page 23: Vacuum Motors Servising

    ® Superabrasive Owner’s manual original language – Lavina V25E 02/2020 8.2 VACUUM MOTORS SERVISING Figure 8.2...

  • Page 24: Filter Chamber Flap Replacement

    During the life of the vacuum motor, the carbon brushes inside the motor may be replaced once. These brushes are considered to be a ‘wear part’ and their replacement is not covered under the vacuum warranty. For additional information, please contact Superabrasive, or an authorized service facility.

  • Page 25: Troubleshooting

    LONGOPAC® SECTION OF BAG FILLED WITH DUST AND DEBRIS. THE VACUUM FILTER(S) HAS CLEAN THE FILTER. REPLACE IF NECESSARY EXCESSIVE BLOCKAGE REPLACE THE DAMAGED MOTOR. THE MOTOR(S) IS/ARE MAKING THE MOTOR(S) IS DAMAGED CONTACT SUPERABRASIVE OR AN EXCESSIVE NOISE. AUTHORIZED SERVICE FACILITY...

  • Page 26: Lavina® Vacuum Adapters And Connections

    ® Superabrasive Owner’s manual original language – Lavina V25E 02/2020 10. LAVINA® VACUUM ADAPTERS AND CONNECTIONS...

  • Page 27: Lavina® V25E Spare Parts

    ® Superabrasive Owner’s manual original language – Lavina V25E 02/2020 11. LAVINA® V25E SPARE PARTS Note: There are three variations of V25E – V25E115V, V25E230V and V25EU. 11.1 GENERAL PARTS Figure 11.1...
  • Page 28 ® Superabrasive Owner’s manual original language – Lavina V25E 02/2020 LAVINA® V25E GENERAL PARTS Model Item No. Description Pcs. Model Item No. Description Pcs. HEPA filter chamber + V25GE30.00.00 Head cover assembly 30323000006 filter V25GE10.00.00 Filter chamber V25GE40.00.04 HEPA inlet elbow V25E11560.00.0...

  • Page 29: Vacuum Head Cover

    ® Superabrasive Owner’s manual original language – Lavina V25E 02/2020 11.2 VACUUM HEAD COVER Figure 11.2...
  • Page 30 ® Superabrasive Owner’s manual original language – Lavina V25E 02/2020 LAVINA® V25E VACUUM HEAD COVER - V25GE30.00.00 Item No. Description Pcs. Item No. Description Pcs. V25GE33.00.00 Vacuum head body V25GE30.00.02 Top cover 30301240114 Nut M4 DIN 985 30301240095 Nut M8 DIN 6923...

  • Page 31: Main Filter Chamber

    ® Superabrasive Owner’s manual original language – Lavina V25E 02/2020 11.3 MAIN FILTER CHAMBER Figure 11.3...

  • Page 32: Inlet Valve

    ® Superabrasive Owner’s manual original language – Lavina V25E 02/2020 LAVINA® V25E FILTER CHAMBER - V25GE10.00.00 Item No. Description Pcs. Item No. Description Pcs. 30301240103 Nut M6 DIN 985 V25GE11.00.00 Inlet valve assembly V25GE10.00.02 Flap restrictive plate 30301240110 Nut M5 DIN 982 V25GE14.00.00...

  • Page 33: Carriage

    ® Superabrasive Owner’s manual original language – Lavina V25E 02/2020 11.5 CARRIAGE Figure 11.5 In the newer versions, the rear base plate (pos. 10) is revised. With the revised version, the foot buffer (pos. 12) is excluded from the assembly.

  • Page 34: Power Unit

    ® Superabrasive Owner’s manual original language – Lavina V25E 02/2020 11.6 POWER UNIT IMPORTANT: There is new version of the power unit assembly. V25E230V now is using the same power unit as the V25EU (fig. 11.6-1). Washers pos. 8 fig 11.6 are excluded from the assembly.
  • Page 35 ® Superabrasive Owner’s manual original language – Lavina V25E 02/2020 Figure 11.6-1 LAVINA® V25E POWER UNIT: CURRENT VERSION 1. V25E115V - V25E11540.00.00-1; 2. V25E230V – Using V25EU40.00.00-1; 3. V25EU - V25EU40.00.00-1; Model Item No. Description Pcs. Model Item No. Description Pcs.
  • Page 36 ® Superabrasive Owner’s manual original language – Lavina V25E 02/2020 Figure 11.6.1 LAVINA® V25E VACUUM MOTORS HOLDER PLATE ASSEMBLY Model Item No. Description Pcs. V25E115V V25E11543.20.00 Vacuum motors assembly V25EU43.20.00 Vacuum motors assembly V25EU V25E115V 30313000328 Vacuum motor 30313000332 Vacuum motor V25EU V25E43.20.01...

  • Page 37: Control Board

    ® Superabrasive Owner’s manual original language – Lavina V25E 02/2020 11.7 CONTROL BOARD...

  • Page 38: Vacuum Gauge Assembly

    ® Superabrasive Owner’s manual original language – Lavina V25E 02/2020 11.8 VACUUM GAUGE ASSEMBLY Figure 11.8 LAVINA® V25GE VACUUM GAUGE ASSEMBLY Item No. Description Pcs. 30313000187 Vacuum gauge 30302000131 Sealing Vacuum gauge base V25GE50.10.00 plate...

  • Page 39: Accessories

    ® Superabrasive Owner’s manual original language – Lavina V25E 02/2020 12. ACCESSORIES Figure 12.1 Figure 12.2 Figure 12.3 Figure 12.4 Figure 12.5 Figure 12.6 Figure 12.7...
  • Page 40 ® Superabrasive Owner’s manual original language – Lavina V25E 02/2020 ACCESSORIES Item No. Description Pcs. Fig. 30310000104 Floor Brush combo 18 in L-FB-50 12.1 30316000062 Steel wand L-A-50 12.2 V25X-00.50.00 Аccessory vacuum hose with CAMOLOCK and cuff 12.3 30316000063 Guff L-R-C-1 V25X-00.51.00...

  • Page 41: Disposal

    Superabrasive or a local distributor, where a professional disposal complying with the environment laws and directives is guaranteed. 14. MANUFACTURER’S CONTACTRS If you need to contact Superabrasive Inc. with technical support questions, below is the contact information. Address: 9411 Jackson Trail Road, Hoshton GA 30548, USA Email: info@superabrasive.us...

  • Page 42: Emmision Control Warranty Statement

    As the SORE owner you should however be aware that Superabrasive Inc. may deny your warranty if your SORE or its part has failed due to abuse, neglect, improper maintenance or unapproved modification.
  • Page 43 If the part fails during the period of warranty coverage, the part will be repaired or replaced by Superabrasive Inc. according to subsection (4) below. Any such part repaired or replaced under warranty will be warranted for the remainder of the period.
  • Page 44 The repair or replacement of any warranted part otherwise eligible for warranty coverage may be excluded from such warranty coverage if Superabrasive Inc. demonstrates that the SORE has been abused, neglected, or improperly maintained, and that such abuse, neglect, or improper maintenance was the direct cause of the need for repair or replacement of the part.
