Modine Manufacturing HBP Installation And Service Manual

Indirect gas-fired weatherproof make-up air units
Hide thumbs
Table of Contents

Advertisement

Quick Links

WARNING
1. Improper installation, adjustment, alteration,
service or maintenance can cause property
damage, injury or death, and could cause
exposure to substances which have been
determined by various state agencies to
cause cancer, birth defects or other
reproductive harm. Read the installation,
operating and maintenance instructions
thoroughly before installing or servicing this
equipment.
2. Installing, starting up and servicing heating,
ventilation and air conditioning equipment
poses significant hazards and requires
specialized knowledge of Modine products
and training in performing those services.
Failure to have any service properly
performed by, or making any modification
to Modine equipment without the use of,
qualified service personnel could result in
serious injury to person and property,
including death. Therefore, only qualified
service personnel should work on any
Modine products.
CAUTION
To prevent premature heat exchanger failure
do not locate ANY gas-fired units in areas
where chlorinated, halogenated, or acid
vapors are present in the atmosphere.
PLEASE BE SURE TO LEAVE IT WITH THE OWNER WHEN YOU LEAVE THE JOB.
INSTALLATION AND SERVICE MANUAL
indirect gas-fired weatherproof make-up air units
THIS MANUAL IS THE PROPERTY OF THE OWNER.
models HBP/HCP/HDP/HPP
OBP/OCP/ODP/OPP
All models approved for use in California by the CEC.
FOR YOUR SAFETY
IF YOU SMELL GAS:
1. Open windows.
2. Don't touch electrical switches.
3. Extinguish any open flame.
4. Immediately call your gas supplier.
FOR YOUR SAFETY
The use and storage of gasoline or other
flammable vapors and liquids in open containers
in the vicinity of this appliance is hazardous.
IMPORTANT
The use of this manual is specifically intended
for a qualified installation and service agency.
A qualified installation and service agency
must perform all installation and service of
these appliances.

Inspection on Arrival

1. Inspect unit upon arrival. In case of damage, report it
immediately to transportation company and your local
factory sales representative.
2. Check rating plate on unit to verify that power supply meets
available electric power at the point of installation.
3. Inspect unit upon arrival for conformance with description of
product ordered (including specifications where applicable).
5-572.10
5H0762330001
January, 2020
