Frigidaire FDB125RH Factory Parts Catalog

24-inch built-in dishwasher
Hide thumbs Also See for FDB125RH:

Advertisement

Quick Links

Download this manual
PRODUCT NO.
FDB125RHB1
FDB125RHD1
FDB125RHS1
MARKET
North America
SERVICE DATA SHEET # - 154388101
OWNER'S GUIDE # - 154361601
INSTALLATION INSTRUCTIONS # - 154373601
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O. Box 212378, Augusta, GA 30917
BASE MODEL NO.
SERIES
FDB125RH
24" Built-in
FDB125RH
24" Built-in
FDB125RH
24" Built-in
Publication No.
5995347662
-EN/SERVICE /ECL
FACTORY PARTS CATALOG
COLOR
black
almond
white
001214
©2000 White Consolidated Industries, Inc.
821
All rights reserved
DISHWASHER
24" Built-In
DISHWASHER
Model No.
FDB125RH
