1 Base unit connection
2
Fixed camera probe
1
Focal depth
The FixView Camera delivers sharp images in a range
between 3 and 7 cm from the camera head.
Objects well beyond the focus range may appear blurred.
2
Connection for Camera probe
08
EN
2
< 3 cm
2.
3.
3 Camera head with
4 high-power LEDs
3 - 7 cm
1.
3
> 7 cm
