Cree XLamp ML Series Handling

Cree XLamp
® ®
IntroDuCtIon
This application note applies to XLamp
have order codes in the following fomat:
MLxxxx-xx-xxxx-xxxxxx
This application note explains how XLamp ML family LeDs and
assemblies containing these LeDs should be handled during
manufacturing. Please read the entire document to understand
how to properly handle XLamp ML family LeDs.
