Build up and Installation
Unpacking and checking
1. Take the product and its accessories carefully out of the packaging.
2. Check the package content for damage and / or completeness. If the package content is incomplete or damaged, do not
switch the product on. Bring it back to the place where you bought the product.
3. If you dispose the packaging materials, please adhere to the legal regulations.
4. Keep the packaging material if you want to pack, ship or transport the product.
Store it in a way that it shows no danger potential.
Warning - suffocation danger!
The packaging material is not a toy. children can choke on plastic bags, foils and polystyrene.
Therefore keep packaging material away from children.
Operation
Note - Place the product in direct sunlight to fully charge the batteries.
Switch on the product
1. Press the on / off button to turn on the product and manually adjust each color mode
(also see the section Selecting Color Mode).
2. The lamp automatically switches on at dusk and automatically turns off at dawn.
Note - When the batteries are exhausted, the product will automatically switch off to
avoid damage to the batteries and the article. In daylight, the batteries will automatically recharge.
pressed on/off
Color mode
button
1 x
red
2 x
green
3 x
blue
4 x
light blue
5 x
yellow-green
6 x
purple
7 x
warm-white
8 x
cold-white
automatic color changing
9 x
mode
10 x
out
Select color mode
Press the on / off button to choose between the different color
modes of the article.
Please refer to the table below for the sequence of color modes.
Note
When you select the color in daylight, the selected color lights up
3 seconds before the product automatically turns off.
If pressed further, the next color lights up in the order of the table.
12
Halterung
an/aus-Schalter
ON/OFF
1.
2.
Placing the product
On the floor: insert the earth spike into the holder
in the cap of the article. Then insert the earth spike
into a soft ground.
Note
Make sure that the product is placed into the sun,
so that the batteries can be fully recharged in
dayligh
Cleaning and storage
Note - Never use solvents and abrasives, hard brushes, metal or sharp objects when you clean the product.
Solvents are hazardous to health and attack the plastic parts , abrasive cleaners and tools to scratch the surface.
1. Clean the product with a damp cloth and – if necessary – use a mild detergent.
2. Dry the product carefully if you want to store it.
3. The item will not be used for a long time, keep it clean and protected from direct sunlight in a dry, cool place in its original
packaging.
Note - Before storing the product it must be turned off manually.
Specifications
Light source:
2 x 5050 LED RGB / 2 x 2835 LEDs (1 x warm-white / 1 x cold-white)
Power supply:
5050 RGB LED = 0,25W / 2835 LED = 0,5 W
Solar Panel:
max. 5.5 V
, 270 mA
Burn time:
8 hours (depending on color mode)
IP Rating:
67
Battery:
1 x INR18650 1800mAh battery (rechargeable)
Warranty
- For this article, the statutory warranty applies.
- The general warranty of 2 years from the date of purchase of the article applies to this article.
- The warranty does not cover abuse / or unappropriate use of the article.
- Keep the sales receipt along with the instruction manual, in case you may need to make use of the warranty.
Disposal methods
Please dispose the batteries environmentally suitable. Do not throw batteries into household waste.
Please use the return and collection systems in your community or contact the retailer where the product was purchased.
This sign indicates that electrical appliances in the EU must not be disposed of with normal household waste.
Please use the return and collection systems in your community or contact the retailer where the product was
purchased.
The packaging material is partially recyclable. Dispose of the packaging in an environmentally friendly and lead them to
the collection of recyclables.
The article complies with all standards which are necessary to obtain the CE-symbol. If necessary, please contact
the manufacturer at info@innocom-gmbh.de for the EC Declaration of Conformity of this product.
Importeur:
INNOcom GmbH
Ehnkenweg 9, 26125 Oldenburg,
Germany
Made in China
Articlenr.:
210001
13
