PRODUCT NO.
BASE MODEL NO.
FAC089L7A1
FAC089L7A
MARKET
USA
WIRING DIAGRAM - # 309341601
OWNER'S GUIDE - # 309000834
ENERGY GUIDE - # 309367434
ELECTROLUX HOME PRODUCTS, INC
P.O.BOX 212378, AUGUSTA, GA 30917
FACTORY PARTS CATALOG
ROOM AIR CONDITIONER
SERIES
VOLTS
Gallery
115
Publication No.
5995367876
020309
©2002 Electrolux Home Products, Inc.
-EN/SERVICE /BLT
All rights reserved
345
BTU-COOLING
8000 BTU
ROOM AIR CONDITIONER
Model No.
FAC089L7A1
Advertisement
Table of Contents
Related Manuals for Frigidaire FAC089L7A1
Summary of Contents for Frigidaire FAC089L7A1
-
Page 1: Room Air Conditioner
PRODUCT NO. BASE MODEL NO. FAC089L7A1 FAC089L7A MARKET WIRING DIAGRAM - # 309341601 OWNER’S GUIDE - # 309000834 ENERGY GUIDE - # 309367434 ELECTROLUX HOME PRODUCTS, INC P.O.BOX 212378, AUGUSTA, GA 30917 FACTORY PARTS CATALOG ROOM AIR CONDITIONER SERIES VOLTS... -
Page 2: Cabinet Front And Wrapper
Publication No. FAC089L7A1 5995367876 CABINET FRONT AND WRAPPER 03/02... - Page 3 Front-cabinet,4 way ,complete assy 3015312 Screw,8-18AB x 0.500 309340803 Overlay 309328603 Door,fresh air vent 309330201 Detent-vent 309638201 Handle,vent door 309646301 Panel,cabinet front 309646401 Frame,cabinet front 309342201 Enclosure,elec control mt 309350502 Remote Control,transmitter ,with batteries 309367434 Energy Guide,FAC089L7A1 Publication No. 5995367876 03/02...
- Page 4 Publication No. FAC089L7A1 5995367876 CONTROLS 03/02...
- Page 5 POS. NO 13 # 17 # 71 # 72 # 72*# # = Fast-moving Parts * = Non-Illustrated Parts FAC089L7A1 CONTROLS PART NO DESCRIPTION 309643801 Control Box 309643702 Bulkhead 309111201 Grommet,wire protector 5304413782 Holder,thermistor ,w/seal 5304426336 Capacitor,250 V ,35+10 mfd 3015312 Screw,8-18AB x 0.500...
-
Page 6: Air Handling Parts
Publication No. FAC089L7A1 5995367876 AIR HANDLING PARTS 03/02... - Page 7 POS. NO 11 # # = Fast-moving Parts * = Non-Illustrated Parts FAC089L7A1 AIR HANDLING PARTS PART NO DESCRIPTION 309624502 Fan Blade,with clamp 3202975 Screw,10-16AB x 0.72 ,square drive 309643901 Housing,fan shroud 5303303759 Seal,bottom 5304421913 Seal,top 08007481 Nut,Keps ,motor mtg ,(4)
-
Page 8: Compressor Parts
Publication No. FAC089L7A1 5995367876 COMPRESSOR PARTS 03/02... - Page 9 POS. NO 10 # 11 # 12 # 13 # 16 # 17 # 03/02 COMPRESSOR PARTS PART NO DESCRIPTION 309616919 Compressor 5303283877 Grommet,compressor mtg ,(3) 5308006948 Nut,compressor mtg ,(3) 3201668 Gasket,terminal cover 5304405245 Cover,compr terminal 5303317553 Overload Protector 3201670 Nut,terminal cover 5303317601 Start Assist Kit,compressor...
- Page 10 Publication No. FAC089L7A1 5995367876 WINDOW MOUNTING PARTS 03/02...
- Page 11 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FAC089L7A1 WINDOW MOUNTING PARTS PART NO DESCRIPTION 5304407729 Seal,window stuffer 5303211056 Bracket,sash lock 309644901 Frame Extension Kit,accordian ,LH & RH ,includes 4 & 14 5304414120 Frame,cab extension ,LH 08016226 Seal,top rail/cab...
-
Page 12: Wiring Diagram
Publication No. FAC089L7A1 5995367876 WIRING DIAGRAM 03/02...
