PRODUCT NO.
BASE MODEL NO.
FAC065K7A1
FAC065K7A
WIRING DIAGRAM - # 309341601
OWNER'S GUIDE - # 309000825
ELECTROLUX HOME PRODUCTS NORTHAMERICA
P.O.BOX 212378, AUGUSTA, GA 30917
FACTORY PARTS CATALOG

ROOM AIR CONDITIONER

COLOR
MARKET
white
USA
Publication No.
5995348306
010111
-EN/SERVICE /DJH
345
BTU-COOLING
6000BTU
ROOM AIR CONDITIONER
Model No.
FAC065K7A
©2001 White Consolidated Industries, Inc
All rights reserved

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FAC065K7A1 and is the answer not in the manual?

Questions and answers

Related Manuals for Frigidaire FAC065K7A1

Summary of Contents for Frigidaire FAC065K7A1

  • Page 1: Room Air Conditioner

    PRODUCT NO. BASE MODEL NO. FAC065K7A1 FAC065K7A WIRING DIAGRAM - # 309341601 OWNER’S GUIDE - # 309000825 ELECTROLUX HOME PRODUCTS NORTHAMERICA P.O.BOX 212378, AUGUSTA, GA 30917 FACTORY PARTS CATALOG ROOM AIR CONDITIONER COLOR MARKET white ROOM AIR CONDITIONER Publication No.

  • Page 2: Cabinet Front And Wrapper

    Publication No. FAC065K7A 5995348306 CABINET FRONT AND WRAPPER 06/01...
  • Page 3 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FAC065K7A CABINET FRONT AND WRAPPER PART NO DESCRIPTION 5304413783 Cabinet 309638001 Link,vertical louver ,with handle 309640202 Louver Assy,horizontal ,Incl-7,8,9 309639301 Louver,horizontal 309342001 Louver,vertical ,(6) 309343501 Filter-air,7.12 x 17.31 ,no frame 309640102 Front-cabinet,4 way ,complete assy 309340802...
  • Page 4 Publication No. FAC065K7A 5995348306 CONTROLS 06/01...
  • Page 5 POS. NO 13 # 17 # 72 # # = Fast-moving Parts * = Non-Illustrated Parts FAC065K7A CONTROLS PART NO DESCRIPTION 309350301 #Control Box 309602404 Bulkhead 309111201 Grommet,wire protector 5304420621 Capacitor,370 V ,35+5 microfarad 3015312 Screw,8-18AB x 0.500 5303303086 Strap-capacitor 309343101 Cord-electric power,18 AWG ,115 V 5303302855...

  • Page 6: Air Handling Parts

    Publication No. FAC065K7A 5995348306 AIR HANDLING PARTS 06/01...
  • Page 7 POS. NO 11 # # = Fast-moving Parts * = Non-Illustrated Parts FAC065K7A AIR HANDLING PARTS PART NO DESCRIPTION 309624502 Fan Blade,with clamp 3202975 Screw,10-16 x 0.72 ,square drive 309624201 Housing-fan 5303270043 Seal,condenser 5300105402 Grommet,motor ,(3) 309627302 Motor-fan,3 speed 309602404 Bulkhead 309617101 Blower Wheel...

  • Page 8: Compressor Parts

    Publication No. FAC065K7A 5995348306 COMPRESSOR PARTS 06/01...
  • Page 9 POS. NO 10 # 11 # 12 # 16 # # = Fast-moving Parts * = Non-Illustrated Parts FAC065K7A COMPRESSOR PARTS PART NO DESCRIPTION 5304420589 Compressor,Goldstar 5303283877 Grommet,compressor mtg ,(3) 5308006948 Nut,compressor mtg ,(3) 5303291330 Gasket,terminal cover 5304416126 Cover-terminal,compressor 5303293809 Washer 5304417320 Overload Protector...
  • Page 10 Publication No. FAC065K7A 5995348306 WINDOW MOUNTING PARTS 06/01...
  • Page 11 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FAC065K7A WINDOW MOUNTING PARTS PART NO DESCRIPTION 5304407729 Seal-window frame,stuffer 5303211056 Bracket 309644901 Extension Kit-frame,LH & RH with accordians 5304413847 Frame,LH ,w/o accordian 5304414120 Extension-frame,LH ,w/accordian 08016226 Seal-top rail 5304414121 Extension-frame,RH ,with accordian 5304413848 Frame,RH ,w/o accordian...

  • Page 12: Wiring Diagram

    Publication No. FAC065K7A 5995348306 WIRING DIAGRAM 06/01...
