PRODUCT NO.
BASE MODEL NO.
FAC051K7A4
FAC051K7A
WIRING DIAGRAM - # 309107201
OWNER'S GUIDE - # 309000825
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O.BOX 212378, AUGUSTA, GA 30917
FACTORY PARTS CATALOG
ROOM AIR CONDITIONER
MARKET
BTU-COOLING
USA
5000BTU
Publication No.
5995355269
010626
-EN/SERVICE /DJH
345
©2001 White Consolidated Industries, Inc.
All rights reserved
ROOM AIR
CONDITIONER
Model No.
FAC051K7A
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Frigidaire FAC051K7A4
Summary of Contents for Frigidaire FAC051K7A4
-
Page 1: Room Air Conditioner
PRODUCT NO. BASE MODEL NO. FAC051K7A4 FAC051K7A WIRING DIAGRAM - # 309107201 OWNER’S GUIDE - # 309000825 ELECTROLUX HOME PRODUCTS NORTH AMERICA P.O.BOX 212378, AUGUSTA, GA 30917 FACTORY PARTS CATALOG ROOM AIR CONDITIONER MARKET BTU-COOLING 5000BTU CONDITIONER Publication No. 5995355269... - Page 2 Publication No. FAC051K7A 5995355269 CABINET FRONT AND WRAPPER 06/01...
- Page 3 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FAC051K7A CABINET FRONT AND WRAPPER PART NO DESCRIPTION 309643602 Cabinet 309639301 Louver,horizontal 309343501 Filter-air,7.12 x 17.31 ,no frame 309640101 Front-cabinet,2 way ,complete assy 309342901 Dial Plate 309306811 Knob-control,rotary 309639201 Panel,cabinet front 309639101 Frame,cabinet front Publication No.
- Page 4 Publication No. FAC051K7A 5995355269 CONTROLS 06/01...
- Page 5 POS. NO 13 # 17 # # = Fast-moving Parts * = Non-Illustrated Parts FAC051K7A CONTROLS PART NO DESCRIPTION 309643802 Box-control 5303318550 Switch-selector 309643701 Bulkhead 5304423280 Capacitor,35+6/250 vac 3015312 Screw,8-18AB x 0.500 309351901 Strap-capacitor 309343101 Cord-electric power,18 AWG ,115 V 5303007754 Screw,6-32 x 0.188 Publication No.
- Page 6 Publication No. FAC051K7A 5995355269 AIR HANDLING PARTS 06/01...
- Page 7 POS. NO 11 # # = Fast-moving Parts * = Non-Illustrated Parts FAC051K7A AIR HANDLING PARTS PART NO DESCRIPTION 309624502 Fan Blade,with clamp 3202975 Screw,10-16 x 0.72 ,square drive 309643901 Housing-fan 5300105402 Grommet,motor ,(3) 309642405 Motor fan,6PLGEHI 309643701 Bulkhead 309643301 Blower Wheel,5"Hub 309112101 Clamp-blower...
- Page 8 Publication No. FAC051K7A 5995355269 COMPRESSOR PARTS 06/01...
- Page 9 POS. NO 10 # 11 # 12 # 13 # 17 # # = Fast-moving Parts * = Non-Illustrated Parts FAC051K7A COMPRESSOR PARTS PART NO DESCRIPTION 5304417319 Compressor 5303283877 Grommet,compressor mtg ,(3) 5308006948 Nut,compressor mtg ,(3) 5303291330 Gasket,terminal cover 5304416126 Cover-terminal,compressor 5303293809 Washer...
- Page 10 Publication No. FAC051K7A 5995355269 WINDOW MOUNTING PARTS 06/01...
- Page 11 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FAC051K7A WINDOW MOUNTING PARTS PART NO DESCRIPTION 5304407729 Seal-window frame,stuffer 5303211056 Bracket 309644902 Frame-complete assy 5304423372 Frame-extention assy,L.H 08016226 Seal-top rail 5304423373 Frame-extention assy,RH 309645501 Closure-accordion,LH/RH 5304417362 Rail-top 3002803 Screw,wood, type 17 ,10-12 x 0.750 5303303691 Screw,truss head ,8-18AB x 0.375 w/nibs 5303295750...
- Page 12 Publication No. FAC051K7A 5995355269 WIRING DIAGRAM 06/01...
