CONTROL UNIT INSTALLED IN A DOOR LEAF -
RESET »R« BUTTON
Performs FACTORY RESET.
IT IS MANDATORY TO PERFORM FACTORY RESET BEFORE FIRST CONNECTION.
WHEN X-MANAGER APP WILL CONNECT TO A READER FOR THE FIRST TIME (BEFORE
PAIRING), THE ORANGE LED WILL BLINK TEN TIMES. IF THERE ARE MORE READERS IN
RANGE (NONE OF THEM PAIRED), ORANGE LED WILL ALSO INDICATE TO WHICH OF THE
DEVICES X-MANAGER HAS BEEN CONNECTED. ONCE THE READER IS PAIRED, THERE WILL BE NO
MORE INDICATION WHEN THE CONNECTION IS ESTABLISHED.
1
SWITCH ON FREE ENTRANCE MODE – PRESS BUTTON 1:
0 The administrator confirms the operation with his fingerprint.
AS LONG AS THE FREE ENTRANCE MODE IS ON, THE GREEN LED SHINES.
SWITCH OFF FREE ENTRANCE MODE – PRESS BUTTON 1:
0 Hold button 1 until the green LED is replaced by the blue one.
2
3
DIN RAIL CONTROL UNIT -
On position 10.

FIRST CONNECTION TO THE READER

OPTION 1
0 Hold button 1 until the blue LED starts flashing.
TURNING THE BLUE BACKLIGHT ON/OFF:
0 Hold button 2 until the blue LED is turned on/off.
To access the button, unscrew the bolt first.
OPTION 2
BUTTON 1
BUTTON 2
BUTTON R
Performs FACTORY RESET.
