1.

INSTALLATION

1.1 Unpacking and preparing the aplliance for use
•
Unpack the appliance and remove the packing material.
•
Place the appliance on a surface which is not slippery.
1.2 Connection to the mains
The connection to the electric supply have to be made by a
magnetothermic omnipolar switch, with distance of 3 mm between
the contacts, or by fuses, or by a differential properly sized according
to the electric norms in force.
This switch have to be dedicated only to this use and installed close to
the aplliance.
Please make sure that there is a proper ground connection.
N.B. The connection cable must have the following characteristics. it
must be at least of the H05 RN F type and have a section suitable for
the aplliance power.
N.B.: The appliance is equipped with a 220-240 Vac 50 Hz
connection.
2.

TECHNICAL DATA

SPECIFICATIONS
Dimensions (mm)
Power supply
Frequency
Absorbed power
(Watt)

INSTALLER SECTION

SPM
220x180x320
220-240 Vac
50 Hz
250
UK
SPL
220x180x350
220-240 Vac
50 Hz
300
page 13
