- Page 1 Motor Blower SG 90 E Operating Manual Geheit GmbH Benzstraße 2 D – 72636 Frickenhausen Germany Phone: + 49 (0) 7022 78969021 Fax: +49 (0) 7022 78969029 www.shop.geheit.de...
- Page 2 Година / Έτος / An / Rok/ Год / Gads / Aasta / Metai/ Rok / Leto / Év: Name und Anschrift der Person, die bevollmächtigt ist, die technischen Unterlagen zusammenzustellen. Name and address of the person authorised to compile the technical documents. GEHEIT GmbH Benzstr. 2 D-72636 Frickenhausen Stand.
-
Page 3: Table Of Contents
All rights reserved, but particularly the right of duplication, distribution and translation. No part of this publication may be reproduced in any form (printed, photocopying, microfilming or by any other method) without the previous written consent of Geheit GmbH, or be stored, processed, duplicated or distributed by means of electronic systems. -
Page 4: Intended Use
Intended Use The ABAC Motor Blower SG 90 E (electronic) – named in this manual also as Motor Blower or simply Blower – is intended to be used in connection with the ABAC Low Pressure Spray Guns PN 2 or PN 5 to spray and apply paints and lacquers. For spraying you may use materials approved by paint manufacturers for High Volume Low Pressure (HVLP) air-spraying technique application. -
Page 5: Brief Description
Brief Description The ABAC SG 90 E Motor Blower generates an adjustable flow of low-pressure working air, which is fed to the ABAC spray gun via the air hose. The main operating device is motor mounted together with air blower, which has two stages. The Motor Blower is self-cooled, which means that working air, sucked from the atmosphere, is also used to cool the motor. -
Page 6: Technical Data
Technical Data Sound Pressure Level, average, DIN 45635 80 dB(A) (for spraying operation) Only for paints and solvents with a flash point above 21°C / 70°F Operating Voltage………………………….. AC 100 V 1/N, 50 / 60 Hz AC 115 V 1/N, 50 / 60 Hz AC 230 V 1/N, 50 / 60 Hz Insulation (Protection Class II)…………….. -
Page 7: Safety Notes
ABAC SG 90 E Motor Blower. -
Page 8: Safe Operation
● The ABAC SG 90 E Motor Blower is not splash-proof. It must not be used out of doors, when it is raining or splashed or washed with water or immersed in liquid. ●... - Page 9 ● Always switch off your SG 90 E Motor Blower before refilling paint into your spray gun paint container. ● Never pull the connecting cable over sharp-edged objects and make sure the cable is in perfect condition each time before using it. ●...
-
Page 10: Transportation And Storage
Transportation and Storage The ABAC SG 90 E Motor Blower is supplied in a box. To avoid damage during transportation and storage, we recommend to use this original packaging. Store your equipment in a dry ventilated room. Ambient temperature range for equipment storage is from 0°С to +45°С, relative humidity must not exceed 80%. -
Page 11: Start-Up And Operation
Start-Up and Operation 6.1 Setting up the Motor Blower ● Check that the mains voltage corresponds to the operating voltage indicated on the rating plate or in this Operating Manual. ● Connect the air hose to the Blower by turning the air hose connector clockwise in the blower opening (fig. -
Page 12: Switching Off The Motor Blower
● The air flow and pressure can be adjusted steplessly using the rotary knob. The Blower can thus be adapted to the material to be sprayed. The spray consistency of the material must be determined beforehand in order to select the best possible settings for the Blower and spray gun. -
Page 13: Replacing Intake Filter
8.1 Replacing Intake Filter Attention!!! Switch off the Motor Blower, disconnect from mains and wait until motor is stationary before opening filter cap. Always replace the intake filter when it is dirty. Do not attempt to clean it. The intake filter should always be checked before spraying and replaced when dirty as shown in figure 7. -
Page 14: Faults, Possible Causes And Remedies
Faults, Possible Causes and Remedies Attention! Never use hard or sharp-edged tools for cleaning! Fault Possible causes Remedy · Intake filter is dirty · Replace intake filter Motor Blower delivers insufficient air flow · Rotary knob incorrectly set · Reset rotary knob such that Motor Blower delivers too much or too little required... -
Page 15: Operating Instructions
For speedy and efficient ordering of spare parts we require the following details: · Equipment type, serial number · Designation of the part, identification number · Quantity of parts required · Address Spare Parts List for ABAC SG 90 E Motor Blower (fig. 7) Fig. No. Quantity Designation Ident. Number...
