Freedom9 freeView Power 80ME Specifications

freeView Power
Power Managment over IP
freeView Power 80ME > 8-port Power
Management over IP
The freeView Power 80ME allows you to remotely control the
power of up to 8 devices. Ideal for secure server rooms and
remote locations, the freeView Power 80ME can reboot
servers, routers, and switches that have locked up by accessing
it through a computer on the network or over the internet or
by using an analog telephone. In addition, up to 16 units of
the freeView Power 80ME can be daisy chained together to
provide control of up to 128 devices using a single IP address.
With enhanced management features such as email and trap
notifications, MIB support for network management software,
and an easy to use graphical web interface, the freeView
Power 80ME allows you to control the power to your devices
with ease.
The included freeView Power Env module adds an external
modem port and a temperature and humidity sensor to the
freeView Power 80ME. The environmental sensor is integrated
with the freeView Power 80ME web interface, allowing the
unit to automatically turn individual ports on or off if the
ambient temperature or humidity exceeds preset limits. For
example, if the server room starts to get too warm, the
freeView Power 80ME can turn on a fan to cool down the
room, and turn servers off to prevent them from overheating.
Specifications
Programmable Power Outlets
Power Output
Power Source Input Ports
Power Source Input
Surge Protection
Circuit Breakers
10/100 Ethernet Ports
RS-485 Chain Out Ports
RS-485 Chain In Ports
Power Requirements
Temperature Range
Humidity
Dimensions (W x H x D)
Model Numbers
Model Name freeView Power 80ME
Description 8-port IP Power with Environmental Module and Sensor
Part Number KPM-008ME
Revision 2.0 Specifications are subject to change without notice. Copyright 2008 Freedom9 Inc.
80ME
8
125V AC, 15A, 50-60 Hz (max)
1
125V AC, 15A, 50-60 Hz (max)
Yes
1
1
1
1
DC 12V, 2.5A
32°F - 104°F (0°C - 40°C)
0-95% RH
17.3 x 1.8 x 5.7 in (440 x 44.5 x 145 mm)
freeView Power Env - Included Environmental
Module and Sensor
Specifications
Operating Temperature
Operating Humidity
Temperature Resolution
Features
• Turn any AC powered device on or off via
IP network, analog telephone, or manual
push buttons
• Integrated 10/100BASE-T Ethernet port for
connection to a TCP/IP network
• IP Address filtering prevents unauthorized
computers from accessing the web interface
through the network
• Supports Network Management Software
control using a MIB
• Download data and events log to server
• Can be daisy chained up to 16 units
• Email and trap event notification
• Configurable power-up and power-down
sequence for each outlet
• Ports can be powered on and off based on
a predefined schedule
www.freedom9.com
1-888-998-9189
32 - 158°F (0 - 70°C)
5 - 95%
1°C
