Campbell Hausfeld TL103700AV Operating Instructions Manual

See Warranty on page 4 for important information about commercial use of this product.
Operating Instructions
Operating Instructions & Parts Manual
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product described.
Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury and/or
property damage! Retain instructions for future reference.
Table of Contents
Description . . . . . . . . . . . . . . . . . . . . . .1
Unpacking . . . . . . . . . . . . . . . . . . . . . . .1
Safety Guidelines . . . . . . . . . . . . . . . . .1
General Safety Information . . . . . . . . .1
Assembly . . . . . . . . . . . . . . . . . . . . . . . .2
Pre-operation . . . . . . . . . . . . . . . . . . . .2
Operation . . . . . . . . . . . . . . . . . . . . . 2-3
Troubleshooting Chart . . . . . . . . . . . . .3
Warranty . . . . . . . . . . . . . . . . . . . . . . . .4
Description
Air operated grease guns are air tools
designed for lubricating automobiles,
recreational vehicles, machinery and
farm equipment .
Unpacking
When unpacking this product, carefully
inspect for any damage that may
have occurred during transit . Check
to be sure all supplied accessories are
enclosed with the unit .
Safety Guidelines
This manual contains information
that is very important to know and
understand . This information is
provided for SAFETY and to PREVENT
EQUIPMENT PROBLEMS . To help
recognize this information, observe the
following symbols .
Danger indicates
an imminently
hazardous situation which, if not
avoided, WILL result in death or serious
injury.
Warning indicates
a potentially
hazardous situation which, if not
avoided, COULD result in death or
serious injury.
Caution indicates a
potentially
hazardous situation which, if not
REMINDER: Keep your dated proof of purchase for warranty purposes! Attach it to this manual or file it for safekeeping.
© 2010 Campbell Hausfeld/Scott Fetzer
Gun Head
Air Vent
Bulk Fill Valve
Grease
Fitting
Adaptor
avoided, MAY result in minor or
moderate injury.
Notice indicates
important
information, that if not followed, may
cause damage to equipment.
NOTE: Information that requires special
attention .
General Safety Information
CalIfOrNIa PrOPOSITION 65
This product or
its power cord may
contain chemicals known to the State
of California to cause cancer and birth
defects or other reproductive harm.
Wash hands after handling.
GENEral SafETy
This product is part of a high pressure
system and the following safety
precautions must be followed at all
times along with any other existing
safety rules .
1 . Read all manuals included
with this product carefully .
Be thoroughly familiar
with the controls and the
proper use of the equipment .
For parts, product & service information
visit www.chpower.com
XXXXX, XXXXX and XXXXX
air Operated
Grease Gun
Slotted
Screws
Container
Tube
2 . Only persons well acquainted with
these rules of safe operation should
be allowed to use the air tool .
pressure of the air tool (90 psi). This
can reduce the life of the tool.
3 . Do not exceed any pressure rating
of any component in the system .
4 . Disconnect air tool from air supply
before changing tools or
attachments, servicing and during
non-operation .
Safety glasses must be worn
during operation.
5 . Do not wear loose fitting
clothing, scarves, neck ties or
jewelry when operating any tool .
Loose clothing or jewelry may
become caught in moving parts and
result in serious personal injury .
6 . Do not depress trigger when
connecting the air supply hose .
7 . Always use attachments designed
MANUAL
for use with air powered tools . Do
not use damaged or worn
attachments .
Exhaust
Port Hole
Trigger
1/4 inch Female
NPT Air Inlet
Plunger Release
Plunger Handle
Do not exceed the
maximum operating
IN230402AV 8/10
