Operating Instructions and Parts Manual
BUILT TO LAST
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product
described. Protect yourself and others by observing all safety information. Failure to comply with instructions could result in
personal injury and/or property damage! Retain instructions for future reference.
Safety Section
This manual contains information that is very important to
know and understand. This information is provided for SAFE-
TY and to PREVENT EQUIPMENT PROBLEMS. To help recog-
nize this information, observe the following symbols.
Warning indicates a potentially
WARNING
!
hazardous situation which, if not
avoided, COULD result in death or serious injury.
Caution indicates a potentially
CAUTION
!
hazardous situation which, if not
avoided, MAY result in minor or moderate injury.
Notice indicates important
NOTICE
information that, if not followed,
may cause damage to equipment.
WARNING
!
• Do not spray flammable liquids such as gasoline.
• Never spray steam on oneself, others, animals, or
electrical appliances - serious burn or scald hazard.
(Note: Steam will continue to spray for a few sec-
onds after the switch is turned off.)
• Keep away from children. Serious burn potential.
• Do not drink from this device.
CAUTION
!
• To provide continued protection against risk of
electric shock, connect to properly grounded out-
lets only.
• Never leave unit unattended when it is plugged in.
• Cleaning cold glass may cause glass to break!
• Never store the unit outdoors. Store only indoors in
a cool, dry area.
• Never unplug by pulling on cord. To unplug grasp
the plug, not the cord.
• Do not use extension cords or outlets with inade-
quate current carrying capacity. The unit uses up to
13 amps of electricity.
• Do not pull or carry the cord as a handle. Keep cord
away from sharp edges or corners. Keep cord away
from heated surfaces
• Not for space heating purposes
• Unplug when not in use.
© 2005 Campbell Hausfeld/Scott Fetzer
For parts, product & service information
visit www.chpower.com
PW1095
Automobile
Steam Cleaner
Figure 1
NOTICE
Keep unit from freezing. Do not operate with tank
empty.
Description
The Campbell Hausfeld Automobile Steam Cleaner is
designed to provide a continuous steam jet that melts away
tough grime and stains. The jet of steam is fully automatic at
the flip of the switch after just seconds of preheating. Unlike
some other hand held steam cleaners, the water storage tank
can be filled immediately after being run dry with no waiting
for the heating element to cool down. Many accessories are
provided to make cleaning easier. Three small brushes and
one triangle brush are included along with a special cleaning
cloth, wire-tip cleaning tool, and easy-to-attach shoulder belt.
The steamer is equipped with a built-in water filter that does
not need replacing.
Unpacking
When unpacking the unit, inspect carefully for any damage
that may have occurred during transit. Refer to Page 4 to
ensure that all of the items are present:
1. Main steam unit
2. Water tank assembly
3. Plastic tip body
4. Triangle brush
5. Cleaning cloth for triangle brush
6. Two short-bristle round brushes
7. Long bristle round brush
8. Wire tip cleaner
9. Shoulder belt
IN465502AV 5/05
U L
13 V V
