- Page 1 DMEGC Photovoltaic Modules Installation Manual Hengdian Group DMEGC Magnetics Co., Ltd DMEGC Solar Energy Hengdian Industrial Area, Dongyang City, Zhejiang Province China Tel: +86-579-86554950 Fax: +86-579-86554845 Version Email: solar@dmegc.com.cn ：202005 - 1 -...
-
Page 2: Table Of Contents
DMEGC Photovoltaic Modules Installation Manual Table of Contents 1. GENERAL INFORMATION - 1 - 2. SAFETY PRECAUTIONS - 1 - 2.1 G - 1 - ENERAL AFETY 2.2 O - 2 - PERATING SAFETY 2.3 I - 3 - NSTALLATION SAFETY 2.4 F... -
Page 3: General Information
Safety precautions DMEGC solar Modules are designed to meet the requirements of IEC 61215 and IEC 61730, applocation class A, Modules rated for use in this applications class may be used in system operating at greater than... -
Page 4: Operating Safety
2.2 Operating safety Do not open the package of DMEGC Solar Modules during transportation and storing until they are ready to be installed. -
Page 5: Installation Safety
DMEGC Photovoltaic Modules Installation Manual the frame strength. A module with broken glass or torn backsheet cannot be repaired and must not be used since contact with any module surface or the frame can cause an electric shock. Work only under dry conditions, and use only dry tools. Do not handle modules under wet conditions ... -
Page 6: Fire Safety
Consult your local authority for guidelines and requirements for building or structural fire safety. According to IEC 61730-2 standard, DMEGC modules have been rated Fire Class A, and are suitable for mounting on to a Class A roof. -
Page 7: Mechanical Installation
Dust building up on the surface of the modules can impair Module performance. DMEGC solar recommends installing the modules with a tilt angle of at least 10 degrees, making it easier for dust to be washed off by rain. -
Page 8: Conventional Requirements
For ground mounting systems, the minimum distance DMEGC recommend from the ground to the ... - Page 9 To maximize mounting longevity, DMEGC strongly recommends the use of corrosion proof (stainless steel) attachment hardware. The tightening torque (suggest stainless steel M8 bolts) should be around 15-20 Nm, the mounting details are shown in the following figures:...
-
Page 10: Attachment Guidelines
DMEGC Photovoltaic Modules Installation Manual Frameless module clamp 4.5 Attachment guidelines The Standard/lower loading capacity applies to normal environment : the modules are tested under a maximum positive pressure of 2400 Pa, and negative pressure of 2400 Pa, the modules are designed to meet a maximum positive pressure of 1600Pa, and negative pressure of 1600 Pa, this design load was then tested with a safety factor of 1.5 times. - Page 11 DMEGC Photovoltaic Modules Installation Manual 4.5.1Framed module bolt and clamp installation - 9 -...
- Page 12 DMEGC Photovoltaic Modules Installation Manual 4.5.2 Frameless clamp installation - 10 -...
-
Page 13: Electrical Installation
Based on the maximum series fuse rating of module and local electrical installation code, always make sure DMEGC PV modules are assembled with the appropriate string fuse for circuit protection. There is no specific limitation on the number of modules that can be connected in parallel, the number of modules is determined by system design parameters such as current or power output. -
Page 14: Grounding
If grounding is required, use a recommended connector type for the grounding wire. DMEGC PV Modules use an anodic oxidized aluminum frame to resist corrosion, so the frame of Modules should be connected to the equipment grounding conductor to prevent thunder and electrical shock. -
Page 15: Maintenance And Care
3) Addition Third-party Grounding Devices DMEGC PV Modules can be grounded using third party grounding devices so long as they are certified for grounding modules and the devices are installed according to the manufacturer’s specified instructions. -
Page 16: Visual Inspection
A mild, nonabrasive cleaning agent can be used to remove stubborn dirt. In order to reduce the potential for electrical and thermal shock, DMEGC recommends cleaning PV modules during early morning or late afternoon hours when solar radiation is low and the modules are cooler, especially in regions with hotter temperatures. -
Page 17: Disclaimer Of Liability
PV product. No license is granted by implication or otherwise under any patent or patent rights. The information in this manual is based on DMEGC’s knowledge and experience and is believed to be reliable; but such information including product specification (without limitations) and suggestions do not constitute a warranty, expresses or implied. - Page 18 DMEGC Photovoltaic Modules Installation Manual Appendix： Group 1 (60 156.75 cells module with aluminium frame xxx=255~310,in increment of 5) DMGxxxM6-60BT DMGxxxM6-60BW DMGxxxM6-60ST DMGxxxM6-60SW DMGxxxM6-60BB DMxxxM2-G60BT DMxxxM2-G60BW DMxxxM2-G60ST DMxxxM2-G60SW DMxxxM2-G60BB Group 2 (60 156.75 cells modules with frameless xxx=255~310,in increment of 5)
- Page 19 DMEGC Photovoltaic Modules Installation Manual Group 9 (144 156.75 cells modules with aluminium frame xxx=360~380,in increment of 5) DMGxxxM6-144HST DMGxxxM6-144HBT DMGxxxM6-144HSW DMGxxxM6-144HBW DMxxxM2-G72HST DMxxxM2-G72HBT DMxxxM2-G72HSW DMxxxM2-G72HBW Group 10 (144 156.75 Bifacial cells modules with aluminium frame xxx=360~385,in increment of 5)
