Features
•
Mounts onto the back of the SONX PXW-FX9
•
Multi Voltage 5,0V, 14,4V unreg, 19,5V
•
5 Outputs (1x USB, 1 Lemo 2p, 2 Twist Dtap, 1 Cinch)
•
1 XLR4 Input with Hotswap function
•
Main On-Off Switch with led for all accessories Output
•
5 led dimmable/Switchable Fuel Gauge
Hotswap functionality
•
st
1
option: Keep a BPU-35 in the camera to Swap the Vmount without interruption
•
nd
2
option: Plug an external 10-17V Power Source into the XLR4 IN to Swap the Vmount
battery without interruption
•
rd
3
option: Swap one Amicro battery after the other
bebob factory GmbH – Höglwörtherstr. 350 – D-81379 München – Tel.: +49 89 27818282
COCO-FX9-AMICRO MULTI VOLTAGE
AMICRO JUNCTION BOX FOR SONY PXW-
FX9
User Manual
WE STRONGLY RECOMMEND THAT YOU
READ THIS INSTRUCTION BEFORE USING
YOUR BEBOB COCO-FX9-AMICRO
ADAPTER! PLEASE KEEP THIS MANUAL
FOR FUTURE REFERENCE
www.bebob.de
July 2020
Advertisement
Table of Contents
Related Manuals for Bebob COCO-FX9-AMICRO
Summary of Contents for Bebob COCO-FX9-AMICRO
- Page 1 Plug an external 10-17V Power Source into the XLR4 IN to Swap the Vmount battery without interruption • option: Swap one Amicro battery after the other bebob factory GmbH – Höglwörtherstr. 350 – D-81379 München – Tel.: +49 89 27818282 www.bebob.de July 2020...
- Page 2 • Keep the COCO-FX9-AMICRO dry and do not immerse in water. • Do not attempt to open or repair the COCO-FX9-AMICRO . Contact your dealer for help if it becomes defective. • Handle with care! Do not throw! Do not drop! •...
- Page 3 1 (14,4V unreg. / max. 2,0A) Self reset Fuse XLR4 IN 1 (10 to 17V) Hotswap Dimensions (WXHXD) 45x 141 x 42mm Weight 0,43 Kg bebob factory GmbH – Höglwörtherstr. 350 – D-81379 München – Tel.: +49 89 27818282 www.bebob.de July 2020...
