Summary of Contents for Blockbit BB 2-C
-
Page 2: Table Of Contents
1. SAFETY ORIENTATIONS ..................3 2. -
Page 3: Safety Orientations
Under no circumstance attempt to access the interior of the equipment. For security reasons, the equipment can only be open by trained and qualified personnel authorized by BLOCKBIT. The act of opening the equipment violates the contractual terms, refer to chapter Warranty This equipment is intended to be installed or stored in a restricted access area;... - Page 4 Ensure that the equipment is secured on a firm and reliable surface, never install the product in an unstable location, such as an inclined shelf, an unleveled floor or a location exposed to vibrations; Do not take any action that creates potential risks to people or that make the equipment potentially unsafe.
-
Page 5: Introduction
Thank you for choosing Blockbit. This document is intended to help you and your company in the process of installing and using Blockbit appliances. After reading and applying the steps described in this document, its recommended to read the User Manual, for a complete description of all features and functionality of the product. -
Page 6: Appliance Specifications
APPLIANCE SPECIFICATIONS In this chapter we will deal with the technical details of each appliance. We will see in a table a summary of all specifications according to your model. The appliance models distributed by Blockbit are: 2-C; 5-C; 10-C;... -
Page 7: Bb 1000-C-01 Specifications
BB 1000-C-01 specifications Below is a table showing a summary of the BB 1000-C-01 appliance specifications. Table - Appliance Specifications FEATURES DESCRIPTION INFORMATION Width 360 mm Height 46 mm Length 430 mm Physical Details Weight 10,6 kg Material Galvanized Steel Type/Watts 220W Single Power Supply System Entry... -
Page 8: Package Specifications
PACKAGE SPECIFICATIONS Blockbit's equipment is protected by a cardboard box containing a protective foam wrap, the main purpose of which is to protect the equipment from impacts during transport. The boxes are identified with the Blockbit logo and an identifying label stating the serial number and UUID of the appliance... -
Page 9: Bb 1000-C-01 Package Specifications
BB 1000-C-01 package specifications The BB 1000-C-01 boxes have the Blockbit logo and an identifying label on the side (as shown below). This label contains the appliance's serial code and UUID. Blockbit box Blockbit Box - Top Blockbit box - Side... - Page 10 After doing this, use both hands to remove the unit from the box with the foam support attached; Carefully remove both foam supports. Blockbit will not be liable for any kind of damage caused as a result of improper transportation. Next, we will analyze the components that come with the product.
-
Page 11: Package Content
PACKAGE CONTENT Before installing your equipment, check if the items are contained in the box, accompanying the appliance. Here is a table with the amount of items that come with each appliance model: Table - Package Contents ITEM BB 2- BB 5- BB 10- BB 50-... - Page 12 Serial Cable Serial to USB Converter Cable Screws...
- Page 13 Power Cable Power Supply Ethernet Cable...
- Page 14 Rack Ears Slide-Rails Slide-Rails Screw Pack Slide-Rails Brackets...
-
Page 15: Appliance Components
In this chapter we will detail the specific characteristics of the components present on the front and rear panel of each appliance, in addition we will detail the functionalities of each component. The appliance models distributed by Blockbit are: BB 2-C;... -
Page 16: Bb 1000-C-01 - Front Panel
Eth1 is the management interface with the standard IP for configuring your appliance, for more information on these procedures, consult the appropriate manual at the Blockbit Resource Center. Right LED: If the LED is orange, it indicates that the connection speed is 100Mbps, if the LED is green, indicates that the connection speed is of 1000 Mbps;... -
Page 17: Bb 1000-C-01 - Rear Panel
BB 1000-C-01 - Rear Panel The BB 1000-C-01 rear panel contains the following components: BB 1000-C-01 - Rear Panel Cooler The coolers have an intelligent activation feature, when the CPU temperature becomes too high they are activated to ensure the cooling of internal components;... -
Page 18: Console Access
CONSOLE ACCESS Next, we will analyze how to execute a console access using Putty. Before starting the following procedures, Putty must be available on the computer in which the connection with the equipment will be made. Putty is a terminal emulation software. Now, configure the terminal emulator with the following parameters: Port: COM1 (The port may vary, check the device manager on Windows);... -
Page 19: Installation
INSTALLATION In this chapter we will detail how to install each appliance model, in addition we will detail the installation of ears and rails on models that use these accessories. The appliance models distributed by Blockbit are: 2-C; 5-C; 10-C;... -
Page 20: Bb 1000-C-01 Installation
BB 1000-C-01 Installation Before carrying out the installation itself, familiarize yourself with the safety orientations. To install the device correctly, follow the instructions below: 1. The equipment has 4 anti-vibration rubber feet at the bottom part, when installing the appliance it should be supported by these feet; Bottom of the appliance Anti-vibration feet 2. -
Page 21: Rack Ears Installation
Rack Ears Installation The models BB 50-C-02, BB 100-C-02, BB 500-C and BB 1000-C-01 are attached to the rack using ears, follow a step by step on how to install them. Before performing the installation, note that you will need to have the following items: 2 x Rack Ears;... - Page 22 Rack ear screwed in appliance. 2. Attach 4 caged nuts on the rack considering the necessary spacing. Caged Nuts mounted on the rack – Frontal View...
- Page 23 Caged Nuts mounted on the rack – Lateral View 3. Screw the Rack Ears on the rack using the caged nuts. Rack Ear Screwed on the rack 4. After screwing the rack ears, the appliance will be attached to the rack, as displayed on the image below. Appliance attached on the rack...
-
Page 24: Lan Bypass
Therefore, an eventual failure on your system will not interrupt your network traffic. Normally there are two communication statuses for the Bypass function, one is the “Normal” status and the other is the “Bypass” status. Blockbit appliances that allow LAN Bypass are: Table - LAN Bypass Information... - Page 25 BIOS 3. On BIOS access the tab “Advanced”; BIOS - Advanced LAN bypass can be enabled or disabled in two states of the system: When it is on or when it is off. The following is the BIOS menu and the illustration of the two LAN Bypass configuration possibilities.
- Page 26 BIOS - ByPass BIOS - Power-Off Lan ByPass 4. After enabling the desired options, press “F10” or go to the Bios “Exit” tab, as shown in the image below; BIOS – Save Changes and Exit...
- Page 27 5. Select the “Save Changes and Exit” option to save the changes.
-
Page 28: Warranty
3. If your product is diagnosed as defective, carefully pack the defective product, it is of utmost importance that absolutely ALL items that came on the box are shipped, otherwise Blockbit will be unable to perform an evaluation and will not be responsible for the integrity of these, preferably use the original Blockbit packaging;...
