Summary of Contents for FRANCO UCP-fly
- Page 1 AND MAINTENANCE UCP-fly COOLER HUMIDIFIER E N G L I S H Before installing or running the unit, it is mandatory to carefully read and consult this manual. Franco srl – Via Nazionale, 80 12010 Cervasca (CN), Italy Manual version: 01-000/2010...
-
Page 2: Table Of Contents
FRANCO srl Manual of use and maintenance UCP-fly INDEX INDEX ............................2 1 - INTRODUCTION ......................... 3 1.1 General warnings ......................3 1.2 Instructions for proper disposal of the product ..............3 1.3 Conventions used in this manual ..................4 1.4 Instruction manual conservation .................. -
Page 3: Introduction
This device must be used only for the functions it was intended for: "Adiabatic Cooler – Humidifier”. Any other use has to be considered improper and dangerous. Franco s.r.l. cannot be held liable for any damages caused by improper, incorrect or unreasonable use, or if the device is used in systems that do not comply with safety regulations. -
Page 4: Conventions Used In This Manual
FRANCO srl Manual of use and maintenance UCP-fly 1.3 Conventions used in this manual The Manual is divided into autonomous chapters, each of which is addressed to a specific operator (installer, operator and maintenance operator), who have the skills needed to operate the machinery safely. -
Page 5: Recipients
FRANCO srl Manual of use and maintenance UCP-fly 1.5 Recipients The manual is addressed to: the installer, the operator, and the qualified personnel entitled to the maintenance of the device. EXPOSED PERSON: refers to any person wholly or partially exposed to a danger zone;... - Page 6 FRANCO srl Manual of use and maintenance UCP-fly OTHER DEFINITIONS: HUMAN-MACHINE INTERACTION: Any situation in which an operator interacts with the machine in any of the operational phases at any time of the life of the machine itself; OPERATOR’S QUALIFICATION: Minimum level of competence that an operator must have in order to perform the described operation;...
- Page 7 FRANCO srl Manual of use and maintenance UCP-fly PICTOGRAMS REGARDING THE OPERATOR’S QUALIFICATION Symbol Description Generic worker: operator lacking of specific competences, capable of performing only simple tasks under the control of qualified technicians. Lifting and handling vehicles driver: operator qualified for the use of vehicles used in lifting and handling materials and machines (carefully following the manufacturer’s instructions), in accordance...
- Page 8 FRANCO srl Manual of use and maintenance UCP-fly PICTOGRAMS REGARDING SAFETY Pictograms contained in a triangle indicate DANGER. Pictograms contained in a circle impose PROHIBITION / OBLIGATION. Pictogram Denomination Hazardous voltage. Entanglement. Dragging. General danger. Do not remove safety devices.
-
Page 9: Applications
The casing is made in PE, the screws are in stainless steel, and the remaining parts of the humidifier are made in PA PC and ABS. The UCP-fly combines the power of the humidification and the ease of installation. The water pressure required is the same as in the water supply network (between 2 and 4 atm). -
Page 10: Parts Description
FRANCO srl Manual of use and maintenance UCP-fly 1.10 Parts description Electric connections box Centrifugal atomizer Safety grill Electric motor Anchorage bracket Water flow regulation valve Fig.1.3 Constituent parts of the centrifugal atomizer Rear shelter Spinning disk Nozzle Fixed disk... -
Page 11: Transport And Handling
Franco s.r.l. from Cervasca (CN), Italy. During the warranty period, the company Franco s.r.l. undertakes to replace or repair free of charge those parts which result faulty from the origin. -
Page 12: Declaration Of Conformity
FRANCO srl Manual of use and maintenance UCP-fly 1.15 Declaration of conformity (Att. IIa DIR. 2006/42/CE) THE MANUFACTURER FRANCO S.r.l. Company Via Nazionale, 80 12010 Address Postal code Province Cervasca Italy City Country DECLARES THAT THE MACHINE Cooler / Humidifier... -
Page 13: Installation
Example of installation on the ceiling with chains. The machine must be installed in horizontal position. The positioning of the UCP-fly must be done by maintaining the minimum recommended distance that allows the correct operation of the machine and to perform maintenance when needed. -
Page 14: Electrical Connection
FRANCO srl Manual of use and maintenance UCP-fly 2.3 Electrical connection The installation requires a humidistat or an ON/OFF thermostat controlling the power of the machine; it is also possible to use, as an alternative, an ON/OFF switch, in this case the start and stop of the machine must be done manually. -
Page 15: Starting
FRANCO srl Manual of use and maintenance UCP-fly Adjust the water flow with the proper flow regulator in order to obtain a nebulization without droplets dragged by the spinning disk. Warning: an excessive quantity of water increase the size of the droplets The pump must not operate without water. -
Page 16: Changing The Float
FRANCO srl Manual of use and maintenance UCP-fly 4.3 Changing the float Disconnect the water supply by releasing the spreader pipe from the fast connection 3/8”. Remove the two screws from the lid using a crosshead or “Phillips” screwdriver. Remove the cover pulling it, grabbing the grip between the thumb and the forefinger. -
Page 17: Replacing The Spinning Disk
FRANCO srl Manual of use and maintenance UCP-fly 4.6 Replacing the spinning disk Remove the cap of the spinning disk. Lever it off using a flat-heat screwdriver on the specific groove. 3~5mm With a nut driver (pic no. 7) remove the M4 screw that fixes the disk to the motor shaft. -
Page 18: Replacing The Fan
FRANCO srl Manual of use and maintenance UCP-fly Using a screwdriver (pic no.10) tighten the screw. By tightening the screw into the hole the disk will be pulled out effortlessly. Once the disk is out, unscrew the M6x40 screw and take it off the hole. -
Page 19: Technical Specifications
FRANCO srl Manual of use and maintenance UCP-fly 5 – TECHNICAL SPECIFICATIONS 5.1 Technical data General characteristics Atomization capacity lt/h 15 - 25 15 - 25 15 - 25 Electrical supply 1 phase 1 phase 1 phase Degree of protection IP... -
Page 20: Wiring Diagram
FRANCO srl Manual of use and maintenance UCP-fly 5.2 Wiring diagram All the wires used must be suitable to carry the current intensity (A) of the motor (par. 5.1). Le terminal’s screws must be accurately tightened. Make sure that the electricity supply characteristics are exactly as shown in the table (par. 5.1). -
Page 21: Spare Parts
FRANCO srl Manual of use and maintenance UCP-fly 5.3 Spare parts It is highly recommended to use only original spare parts. Orders must be made by specifying what follows: - Device model - Reference to the piece (as indicated as follows) - Page 22 FRANCO srl Manual of use and maintenance UCP-fly Item Code Q.ty Description F.1800003 SPINNING DISK CAP F.6001001 HEXAGONAL HEAD INOX SCREW M4x16 F.1801006 SPINNING DISK FIXING WASHER F.1801002 SPINNING DISK F.1801010 SPINNING DISK SPACER F.6001501 INOX SCREW M4x16 F.6003000 INOX WASHER 4,4x9 F.6002500...
-
Page 23: Problems And Solutions
FRANCO srl Manual of use and maintenance UCP-fly 6 - PROBLEMS AND SOLUTIONS Before undertaking any maintenance, disconnect the device from the electricity and water supply! PROBLEM CAUSE SOLUTION The device does not The power supply is not Verify the electrical connection, or the start. - Page 24 FRANCO srl Manual of use and maintenance UCP-fly FRANCO s.r.l. Headquarters and plant: Via Nazionale n.80 - 12010 - CERVASCA (CUNEO) Italy Tel. (+39) 0171 611663 – Fax (+39) 0171 612337 www.francosrl.com info@francosrl.com For further information, requests or suggestions, please contact us at:...
