Avery Dennison
TrafficJet™ Purex Fume Extractor
Instructional Bulletin #1.00
December 2016
Contents
Installation
●
Control System
●
Switch ON the Machine
○
Adjust the Airflow
○
Replacing the Filters
●
Changing the Main Filter
○
Changing the Pre-Filter
○
Warning Alerts
●
Warning Status
○
Alarm Status
○
Changing the Fuse
●
Contact Information Purex
●
Instructional Bulletin #1.00
TrafficJet™ Purex Fume Extractor
Page 1 of 6
reflectives.averydennison.com
Ⓡ
Advertisement
Table of Contents
Summary of Contents for Avery Dennison TrafficJet Purex
- Page 1 Avery Dennison Ⓡ TrafficJet™ Purex Fume Extractor Instructional Bulletin #1.00 December 2016 Contents Installation ● Control System ● Switch ON the Machine ○ Adjust the Airflow ○ Replacing the Filters ● Changing the Main Filter ○ Changing the Pre-Filter ○...
- Page 2 Installation Position the fume extractor as near as possible to the TrafficJet printer allowing for easy access to the control panel, filter replacement, exhaust, electrical, and hose connections. Once in place, lock all casters. Connect the extraction hose to the intake of the fume extractor and the other end of the hose to the supplied Maintenance Cover.
- Page 3 Control System Switch ON the machine Press the center button on the keypad. The center button will illuminate green and the motor-run-icon on the display will rotate. To turn the extractor off, press the center button again and the light will go off and the icon will stop rotating.
- Page 4 Replacing the Filters Filters should be replaced annually. To avoid airflow false alerts, always check the extraction hose and air intakes for debris buildup before replacing filters. The fume extractor will warn the user with audible and visible alerts. Icons on graphic display will flash indicating the filters needing attention.
- Page 5 Changing the pre-Filter To remove the pre-filter pad, the main filter must be removed first and turned over Remove the older pre-filter and replace it with a new one making sure the smooth side of the pre-filter pad is facing the main filter Turn the filter locking handle 180º...
- Page 6 All statements, technical Information and recommendations about Avery Dennison products are based upon tests and information believed to be reliable, but do not constitute a guarantee or warranty of any kind. All Avery Dennison products are sold with the understanding that Purchaser has independently determined the suitability of such products for its intended and other purposes.
