- Page 1 JPTLIIPA IP INTERFACE FOR JP SYSTEM OPERATION MANUEL 22.07.15 – V1.1 AIPHONE...
- Page 2 5. For power supply, use Aiphone power supply model specifications. This manual was created by Aiphone Co., Ltd., all specified for use with system. If non-specified product is used, fi re or malfunction could result.
-
Page 3: Package Contents
- fixed on the wall: to do this action, it must be fixed with 2 crews with plugs adapted of the supporting material. Don’t install JPTLIIPA near heating equipment that varies in temperature and near subject to moisture and humidity extremes. -
Page 4: Using The System
Interface is not registered on AIPHONE’s server 5-blinking every seconds USING THE SYSTEM JPTLIIPA interface allow audio and video call transfer from the AIPHONE JP series door station to 2 smartphones with Androïd or Apple software. ATTENTION! To get an audio or video good reception, your smartphone must receive phone calls by WIFI or 3G/4G (3G minimum) mode. - Page 5 When a call is placed on the Door Station, the image from this one appear on the video station and send automatically the video onto 2 Smartphone. Without answer with the Smartphone, the JPTLIIPA goes back into Stand-by mode into the next call.
- Page 6 Operating time of the relay 1 5 seconds (Door1 Name) Operating time of the relay 2 5 seconds (Door2 Name) Operating time of the relay 3 (JPTLIIPA) 5 seconds (Optional Relay Name) Operating time of the relay 4 (JPTLIIPA) 5 seconds (Optional Relay Name)
-
Page 7: Quick Start
QUICK DEBUG DEFAUTS VERIFICATIONS The JPTLIIPA Status Led don’t turn ON - Check the Power Adaptor is well plugged The call activate to the JP4MED but not - Check the selector is on « ON » Position activate the JPTLIIPA Interface - Check the connection on the «... - Page 8 Fonction Smartphone Launching Screen : Running Application : you can receive call Application Launching To return to Stand-by Mode, push the IPhone “Home” Button 03.07.15 – V1.0 AIPHONE...
- Page 9 To permit the application remains in stand-by mode, you must activate the “AiphoneJP” notifications: 03.07.15 – V1.0 AIPHONE...
- Page 10 Push , Audio / Video communication begin : If you push the JPTLIIPA go Stand-by Mode. Caution! The call will not send to the voice mail. If the area is not covert by 3G/4G network, you will only have audio call : Call answering 03.07.15 –...
- Page 11 - Activate or deactivate the micro (private mode) with . The symbol below become red: the micro is deactivate. Disabling function - Activate or deactivate the video with . The symbol below become red: the video is deactivate. 03.07.15 – V1.0 AIPHONE...
- Page 12 Door opening and optional Move the green symbol to the grey symbol relay For opening the 1st Entry choose : For opening the 2 Entry choose : For activate the optional relay (3rd Entry or else) choose : 03.07.15 – V1.0 AIPHONE...
- Page 13 Alarm Activated Screen: Alarm Functioning When the key “ ”, you will have the message “ Alarm activated” and the following screen 03.07.15 – V1.0 AIPHONE...
-
Page 14: Technical Precautions
Stand-by 350mA, when relay is on 430mA. Standards: EN60950 EN55022 Edition 98 Classe B EN55024 Edition 98 Classe B Exit Contact: 3 (N.O., N.F.) Programming: By Internet. Saving of parameters: No volatile memory Material : ABS module 03.07.15 – V1.0 AIPHONE... - Page 15 03.07.15 – V1.0 AIPHONE...
- Page 16 Distributed par AIPHONE Print in France 03.07.15 – V1.0 AIPHONE...
