Summary of Contents for GreenTec HXF 2800
- Page 2 Should you find the information given in this book different to the machine it relates to please contact the “After Sales Department” for advice Merkurvej 25 DK 6000 Kolding Danmark Tlf: +45 75553644 Email: info@greentec.eu http: www.greentec.eu © Greentec Machinery Limited 2015 HXF 2800 / 2802 AHS...
-
Page 3: Table Of Contents
Hydraulic diagrams ....................22 Maintenance ....................... 23 Lubrication ........................ 23 Hydraulic Hoses ....................... 23 Oil Supply ......................... 24 Maintenance chart ....................24 Pins and Bushes ...................... 25 Storage ........................25 Problem solving ......................26 GreenTec Warranty ....................27 HXF 2800 / 2802 AHS... -
Page 4: Introduction
Pay particular attention to the instructions regarding safety. You are welcome to visit our website www.greentec.eu - where the login via the dealer's access gives you the latest updates on instructional and part books on our entire product range. The password for dealer log-in: PUBLISHER We hope, you will be pleased with your new Greentec machine. -
Page 5: Useful Information
Please fill out the list below to ensure that the necessary information is at hand when ordering spare parts etc. Serial No Delivery date Dealer Tlf./ fax Merkurvej 25 DK 6000 Kolding Danmark Tlf: +45 75553644 Email: info@greentec.eu http: www.greentec.eu Opening hours: Mon-Fri 8-16 HXF 2800 / 2802 AHS... -
Page 6: General Information
General Information Read this manual before fitting or operating the machine or accessory. Whenever any doubt exists contact your local dealer or the GreenTec Service Department for assistance. Only use ‘Genuine GreenTec Parts’ on GreenTec machinery and equipment. DEFINITIONS: The following definitions apply throughout this manual;... -
Page 7: Eu Declaration Of Conformity
Adapted EEC directive EG Guideline 2006/42/EF, 89/392/EEC & 98/37/EC We, GreenTec A/S, Merkurvej 25, 6000 Kolding, hereby declare that in terms of its design, method of construction and our execution thereof, the item of machinery described below complies with the basic health and safety regulations of the respective EU Directives. -
Page 8: Vehicle / Tractor Preparation
– in the instance of Power Arm hedgecutters it must be remembered that the machines centre of gravity during work will be constantly moving and will differ from that during transport mode, therefore balance becomes critical. HXF 2800 / 2802 AHS... -
Page 9: Factors That Affect Stability
For reasons of safety the blade guard should be fitted to machine at all times and only removed for machine operation. HXF 2800 / 2802 AHS... -
Page 10: Safety
Stay clear of mower Warning sawblades when running. Carefully read operator’s Never remove the manual before handling this safety protection. machine. Observe instructions and safety rules when operating. Warning Stay out of gears swing area. HXF 2800 / 2802 AHS... -
Page 11: Safety Recommendations
Disengage the machine, stop the engine and remove the key before leaving the tractor cab for any reason. • Clean up any debris left at the work site. • Ensure that when you remove the machine from the tractor it is secured in a safe position using the stands provided. HXF 2800 / 2802 AHS... - Page 12 Never transport with the PTO engaged • Never enter the working area of the machine (risk of injury!) • Never transport with the controls live, always turn off electrical isolator switch (red) and disconnect supply. HXF 2800 / 2802 AHS...
-
Page 13: Additional Safety Advice
No advice given here can replace ‘good common sense’ and ‘total awareness’ at all times, but will go a long way towards the safe use of your GreenTec machine. HXF 2800 / 2802 AHS... -
Page 14: Specifications
Start the tool by low oil flow (Low rpm). • Adjust the HFX 2802 AHS to vertical when hedge cutting. Too much back Vertical Too much forward Arm falls back too often Best work Risk of machine failure HXF 2800 / 2802 AHS... -
Page 15: Tool Start
If the sawblades anyway blocks, then stop the saw, stop the carrier, take out the ignition key, pull the handbrake, take your safety goggles and gloves on and remove the jammed piece of wood. HXF 2800 / 2802 AHS... -
Page 16: Overhead Power Lines
Assembly / Disassembly 1) Drive forward. Tip the holder on arm 90˚. 2) Tighten the machine. 3) Tip holder on arm 90˚ back to correct working position. 4) Mount the hydraulic hoses and electric cords HXF 2800 / 2802 AHS... -
Page 17: Transport Position
Transport position Remove the bolt - Turn the arm 180˚ Working position Mount the bolt to the ram HXF 2800 / 2802 AHS... -
Page 18: Storage
Before you attempt to do any repairs, service, maintenance or adjustment on your machine, ensure the engine has stopped and the key removed. P.T.O. is disengaged, handbrake secured, and the head is firmly on the ground. HXF 2800 / 2802 AHS... -
Page 19: Extra Equipment
4. Pressure relief valve (200 bar) A Flow for tool (regulated) B Not in use C Cutting angle D Cutting angle P Pressure, flow from pump T Tank Connection, pressure less + T from motor HXF 2800 / 2802 AHS... -
Page 20: Diagrams
Diagrams Splitter Valve HXF 2800 / 2802 AHS... -
Page 21: Electric Diagram
Electric diagram HXF 2800 / 2802 AHS... -
Page 22: Hydraulic Diagrams
Break-back 40-50 bar 1. Lynkobling ½”. Schnellkupplung ½” Quick coupling 2. Afspæringshane Absperrhahn Cut-off valve 3. Manometer. Mini-mesh 4. Akkumulator 32 bar Drückspeicher 32 bar Accumulator 32 bar 5. Påkørselscylinder Anfahrsicherungs Zylinder Break back ram HXF 2800 / 2802 AHS... -
Page 23: Maintenance
Hoses with damaged metal braid should be replaced. When replacing hoses quote number stamped on fitting at one end. The GreenTec hydraulic system works at very high pressure, when replacing hoses use only genuine hoses, a burst hose could be very dangerous. -
Page 24: Oil Supply
Clean Change Hours 1 – 4 hours Bolts are completely tightened Seals at valve block (If leaking, replace ( X ) them) Check for leaks from fittings and hoses Bolts and bushes greased and tightened HXF 2800 / 2802 AHS... -
Page 25: Pins And Bushes
Pins and Bushes All main pivot points are furnished with replaceable bushes. If there are any signs of wear, these must be replaced. All bushes are available from Greentec’s Parts Department. Warning Do not use grease containing Molybdenum disulphide on nylon bushes and wear pads... -
Page 26: Problem Solving
Defective seals in hydraulic cylinder Hydraulic ram repair Defektive wiring Check the wiring and switches Dirt in valve Check for ingress of dirt. Electrically Valve stuck Replace the valve operated valve is Insufficient voltage Check for loose connections. not responding HXF 2800 / 2802 AHS... -
Page 27: Greentec Warranty
Should you have a problem within 12 months from the date of sale please contact your original Greentec dealer, or Greentec’s Service Department. Any part found to be defective during this period will be replaced or repaired, at Greentec’s discretion, by the dealer or a Greentec Service Engineer.
