Campbell Hausfeld IN228704AV Operating Instructions Manual

See Warranty on page 6 for important information about commercial use of this product.
Operating Instructions
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product described.
Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury and/or
property damage! Retain instructions for future reference.
Table of Contents
Description . . . . . . . . . . . . . . . . . . . . . .1
Unpacking . . . . . . . . . . . . . . . . . . . . . . .1
Safety Guidelines . . . . . . . . . . . . . . . . .1
General Safety Information . . . . . . . . .2
Assembly . . . . . . . . . . . . . . . . . . . . . . . .2
Maintenance . . . . . . . . . . . . . . . . . . . . .3
Troubleshooting Chart . . . . . . . . . . . . .5
Warranty . . . . . . . . . . . . . . . . . . . . . . . .6
Description
Single stage, oil lubricated air
compressor pumps are intended for
use as replacements on air compressor
units, and for use as components in
specially designed air compressor
systems . For replacement use, the
compressor pump must match the
vibration characteristics of the original
pump . The compressed air from these
pumps is intended to be used with
air tools and spray guns . Atmospheric
moisture and trace oil from compressors
may require additional treatment
for some application . All models are
equipped with solid cast-iron cylinders
and crankcase, an aluminum head and
stainless steel valves .
© 2010 Campbell Hausfeld/Scott Fetzer
This compressor/pump is NOT equipped and should NOT be used "as is" to supply
breathing quality air . For any application of air for human consumption, you must
fit the air compressor/pump with suitable in-line safety and alarm equipment . This
additional equipment is necessary to properly filter and purify the air to meet minimal
specifications for Grade D breathing as described in Compressed Gas Association
Commodity Specification G 7 .1 - 1966, OSHA 29 CFR 1910 . 134, and/or Canadian
Standards Associations (CSA) .
DISClAIMeR OF WARRAnTIeS
In the event the compressor is used for the purpose of breathing air application
and proper in-line safety and alarm equipment is not simultaneously used, existing
warranties are void, and Campbell Hausfeld disclaims any liability whatsoever for any
loss, personal injury or damage .
Unpacking
After unpacking the unit, inspect carefully for any damage that may have occurred
during transit . Make sure to tighten fittings, bolts, etc ., before putting unit into
service .
Safety Guidelines
This manual contains information that is very important to know and understand .
This information is provided for SAFETY and to PREVENT EQUIPMENT PROBLEMS .
To help recognize this information, observe the following symbols .
nOTe: Information that requires special attention .
REMINDER: Keep your dated proof of purchase for warranty purposes!
Attach it to this manual or file it for safekeeping.
For parts, product & service information
visit www.chpower.com
Single-Stage Compressor Pumps
Air Compressor
Pumps
Breathable Air Warning
Do not operate unit if damaged during shipping, handling or
use. Damage may result in bursting and cause injury or
property damage.
ReAD & FOllOW All InSTRUCTIOnS
SAve TheSe InSTRUCTIOnS
DO nOT DISCARD
Danger indicates an imminently hazardous situation which, if
not avoided, WILL result in death or serious injury.
Warning indicates a potentially hazardous situation which, if
not avoided, COULD result in death or serious injury.
Caution indicates a potentially hazardous situation which, if
not avoided, MAY result in minor or moderate injury.
Notice indicates important information, that if not followed,
may cause damage to equipment.
IN228704AV 7/10
