CAUTION
Read all precautions
and instructions in this
manual before using
this equipment.
Keep this manual for
future reference.
Installation Video
https://youtu.be/gNXEiI0vYHw
MAGNETIC BIKE USER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MAGNETIC BIKE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Ancheer MAGNETIC BIKE

  • Page 1 MAGNETIC BIKE USER’S MANUAL CAUTION Read all precautions and instructions in this manual before using this equipment. Keep this manual for future reference. Installation Video https://youtu.be/gNXEiI0vYHw...
  • Page 2: Table Of Contents

    CONTENTS Safety Precautions ………………………………………………………………………………………...3 Exploded View …………………………………………………………………………………………..4 Part List ............................5 Assembly Instructions ………………..................6 Computer Operation Instructions …………………………………………………………………10 Maintenance …………………………………………………............11 Exercise Instructions …………………………………………………………………………………..12 Troubleshooting ……………………………………………………………………..…………………….13 Warranty ………..……………………………………………………………………..………………………14...
  • Page 3: Safety Precautions

    Safety Precautions – Please Read the Instruction before Using! According to the installation instruction, use original parts to assemble this product properly. Before assembly, inspect whether packages are in good condition and whether spare parts are complete in accordance with transport precautions and the list of spare parts. Prior to exercise, make sure equipment fasteners are in locking state.
  • Page 4: Exploded View

    EXPLODED VIEW...
  • Page 5: Part List

    Ø8 Curved Washer M8 Cap Nut Ø8 Flat Washer Spring Washer M7*1.0 Screw M8*50 Bolt M8*16 Hexagon Screw Self-tapping Screw 13-15 Wrench Multi-function Wrench (Screwdriver) L shape Wrench PART LIST DESCRIPTION DESCRIPTION Main Frame Ø8 Flat Washer Front Stabilizer M8*50 Bolt Rear Stabilizer M10 Lock Knob Seat Support Tube...
  • Page 6: Assembly Instructions

    ASSEMBLY INSTRUCTIONS 7 easy steps to assemble then you’re ready to workout – it takes approx 30 mins to assemble. STEP 1 Fix the Front Stabilizer (2) to Main frame (1) using 2 X M8*50 Bolts (16), 2 X Ø8 Flat Washers (15) and 2 X M8 Cap Nuts (14) provided by 13-15 Wrench (25).
  • Page 7 STEP 3 Fix the Saddle (8) to the Horizontal Sliding Bar (7) with the provided 13-15 Wrench (25) until tight. STEP 4 a. Before fixing the Handlebar Support Tube (26), please connect the tension and sensor cables as shown in the following illustrations: (1) Adjust the tension control to 8 levels, making sure the supper tension cable (A) to bet the longest.
  • Page 8 b. After finish connecting all cables, insert the Handlebar Support Tube (26) to the front opening tube of the Main Frame (1), to tighten it with 4 X Ø8 Curved Washers (12) and 4 X M8*16 Hexagon Screws (13) by L shape wrench (23). STEP 5 Fix Handlebar (9) on the Handlebar Support Tube (26) and tighten with 2 X M7*1.0 Screws (19), 2 X Spring Washers (11-2) and 2 X Ø8 Flat Washers (11-1) by L shape Wrench (23).
  • Page 9 STEP 6 a. Unscrew the two Screws (28) pre-fitted on the Computer (10). b. Fix the Computer (10) on the bracket with 2 x Screws (28) by the provided Multi-function Screwdriver (24). c. Unscrew the two Self-tapping Screws (27) pre-fitted on the handlebar support tube, then fix the Water Bottle (20) on it with the two Self-tapping Screws (27) by the provided Screwdriver (24).
  • Page 10: Computer Operation Instructions

    COMPUTER OPERATION INSTRUCTIONS SCAN Scans all functions – TIME, SPEED, DISTANCE, TOTAL DIST, CALORIES TIME Displays work out time lapse while exercising SPEED Displays the current speed DISTANCE Displays the distance while exercising TOTAL DIST Displays the total distance at the end of your workout CALORIES Displays the calories you have burned PULSE...
  • Page 11: Maintenance

    MAINTENANCE Regular maintenance will prolong the life of your spin bike and prevent injury. We strongly recommend that you do the following on a regular basis: Clean the bike after use with a soft cloth – ensure it is dry. Note, a build up of moisture over time will cause corrosion.
  • Page 12: Exercise Instructions

    EXERCISE INSTRUCTIONS Using your EXERCISE CYCLE will provide you several benefits, it will improve your physical fitness, tone your muscle, and in conjunction with calorie controlled diet, it will help you lose weight. 1. The Warm Up Phase This stage helps the blood flow around the body and the muscles work properly. It will also reduce the risk of cramp and muscle injury.
  • Page 13: Troubleshooting

    TROUBLESHOOTING PROBLEM SOLUTION THE PEDALS ARE SPINNING 1. ADD MORE RESISTANCE BY TURNING THE TENSION CONTROL TO THE OUT OF CONTROL RIGHT. 2. START PEDALLING SLOWLY. 3. KEEP TURNING THE TENSION CONTROL TO THE RIGHT UNTIL YOU CAN FEEL RESISTANCE WHEN YOU PEDAL. THE BIKE IS UNSTABLE 1.
  • Page 14: Warranty

    WARRANTY We have one year quality warranty to the products. Within the warranty period, we provide the FREE replacement parts, and provide technical support for life. If caused by incorrect assembly, incorrect use or change of parts failures, our company takes no responsibility.
