CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The lightening flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage”...
Page 3
Adjustment procedures, parts list, pattern drawing and circuit diagrams are given in this manual to assist the service technician in maintaining the D-25 / D-30 with ADDA-2 PCB assy. For your information, the followings are the serial number of D-25 / D-30 with ADDA-2 PCB assy. D-25...
Playback the 1kHz, 0dB section (PROG NO. 1) of SONY test tape TY-7551. Adjust R192 (CH 1) and R292 (CH 2) on the ADDA-2 PCB so that the AC volt meter reading is +2dBV. By this adjustment, a 1kHz, +16dBm sine wave should appear at the D-25/D-30 audio output.
Output a 1kHz, +4dBm sine wave signal from the sine wave oscillator. Under this setting, a 1kHz, +4dBm sine wave signal will be applied to the D-25/D-30 audio input terminal. Adjust R191 (CH 1) and R291 (CH 2) on the ADDA-2 PCB so that the AC volt meter reading is -10dBV. CH 1...
