Fortinet FortiLog FortiLog-100A Quick Start Manual

FortiLog unit LED Indicators
LED State Description
Power On The FortiLog unit is powered on.
Off The FortiLog unit is powered off.
Status On The FortiLog unit is running normally.
Ethernet Flashing Network activities at this interface.
ports
Off No link at the interface.
(back)
10/100 On The interface is connected at 100 Mbps.
Off The interface is connected at 10 Mbps.
Link Act Flashing Network activities on the FortiLog unit
On Interface connected.
1

Checking the package contents

Power LED
Connector
Ports 1, 2, 3, 4
CONSOLE
2
Planning the installation
You can add the FortiLog unit to your local FortiGate network to receive log messages from your local FortiGate units, or
connect the FortiLog unit to the FortiGate units remotely using FortiManager. To connect the FortiLog unit to the
FortiGate units remotely, you must configure the DNS server and the default gateway.
To manage the FortiLog unit, you can use a computer within the local network or over the Internet.

Factory Defaults

User name:
Administrator
account
Password:
IP:
Port 1 Netmask:
Management Access:
IP:
Port 2 Netmask:
Management Access:
IP:
Port 3 Netmask:
Management Access:
IP:
Port 4 Netmask:
Management Access:
3
Connecting the FortiLog unit
• Place the FortiLog unit on a stable surface. It requires 1.5 inches (3.75 cm)
clearance on each side to allow for cooling.
• Make sure the power is not plugged into the wall before connecting the power
cable.
• The Status light flashes while the unit is starting up and remains lit when the
system is up and running.
Front
1 2 3 4
POWER 10/100
LINK / ACT
STATUS
Interface
Status LED
status LEDs
Type Speed Protocol Description
RJ-45 10/100Base-T Ethernet
DB-9 9600 bps RS-232
serial
admin
(none)
192.168.1.99
255.255.255.0
ping, https, ssh, http
192.168.2.99
255.255.255.0
ping, https, ssh, http
192.168.3.99
255.255.255.0
ping, https, ssh, http
192.168.4.99
255.255.255.0
ping, https, ssh, http
FortiLog-100A
