it's a personal experience
This instruction booklet covers these models:
OMI-100M, OMI-100, OMI-100E.
Wedmore Road, Cheddar, Somerset, England BS27 3EB
tel 01934 744466.
aftersales @ vado.com
www.vado.com
Version 1, 1-8-17
Vado
fax 01934 744345
OMIKA
Installation Guide
Mono Basin Mixers
100M
100
100E
Keep for future reference
Advertisement
Table of Contents
Related Manuals for VADO OMIKA 100
Summary of Contents for VADO OMIKA 100
- Page 1 Installation Guide Mono Basin Mixers 100M 100E This instruction booklet covers these models: OMI-100M, OMI-100, OMI-100E. Vado Wedmore Road, Cheddar, Somerset, England BS27 3EB tel 01934 744466. fax 01934 744345 aftersales @ vado.com www.vado.com Keep for future reference Version 1, 1-8-17...
- Page 2 Important - please read Contents of Packaging Please read these instructions carefully before starting installation and keep for future reference. Remove all packaging and check the product for missing parts or damage before starting installation. Any alterations made to this product and fittings may infringe water regulations and will invalidate the guarantee.
- Page 3 Installation - Quick guide Installation Before installing your new mixer, flush through the pipe work to ensure removal of debris, turn off the water supply. Make sure that the seal is in position in the base of the mixer body. Max - 5 Bar Min - 1 Bar Screw the threaded rod into the back...
- Page 4 Valve dimensions - 100m Valve dimensions - 100e 108mm 50mm 126mm 50mm 25mm 17mm 48mm 78mm Valve dimensions - 100 121mm 50mm 25mm 17mm 48mm 78mm 25mm 17mm 48mm 78mm...
- Page 5 (2 years parts and labour plus 10 years parts only). User Guide VADO digital and i-tech products have a 6 year guarantee (2 year parts and labour plus 4 years parts only). All other VADO products have a 3 year guarantee (2 years parts and labour plus 1 year Keep for future reference parts only) [SEE NOTE 2].
-
Page 6: Operation
Hot control offer our premium 12 year guarantee. We work to ensure our product designs are harmonious with all sanitaryware, so when you choose VADO, your choice of coordinating items is unlimited. With VADO, you can really let your inspiration flow. -
Page 7: Cleaning Instructions
Cleaning instructions: Notes The electroplating on this product is finished to the highest standard. Due care needs to be taken to ensure the appearance is retained. We recommend cleaning all products with a soft damp cloth ONLY and advise strongly against the use of all aggressive/corrosive cleaning products i.e. -
Page 8: Parts List
Parts list: Parts: Item Description Part Code Quantity Body Uncoded Headwork FL-401-RTC Handle assembly OMI-1-C/P 1 pair Aerator/housing OMI-AERATOR-C/P Fixing kit OMI-FIXING KIT Flexible hose T-½ x M10-400mm-FLX 1pair Flow regulation Uncoded Installation guide & User manual...
