Summary of Contents for OVERPOWERED Gaming Laptop Series
- Page 1 Gaming Laptop Series GAME USER MANUAL GAMING LAPTOP: OP-LP1 & OP-LP2...
-
Page 2: Notice
THE PERFORMANCE OR USE OF THIS MANUAL. The illustrations in this user’s manual are for reference only. Actual product specifications may vary with territories. The information in this user’s manual is subject to change without notice. OVERPOWERED Products service@opowered.com warranty@opowered.com 800-379-3820... -
Page 3: Table Of Contents
TABLE OF CONTENTS Notice ....................Preface ....................Regulations Information ............Safety Instructions ..............Getting to Know the Basics ............OP-LP1 Product Specification ..........2.1.1 OP-LP2 Product Specification ..........2.1.2 Preparing Your Computer ........... Product Overview ..............Getting Started ................AC Adapter ................ - Page 4 BIOS Setup ..................About BIOS Setup ..............When to Use BIOS Setup? ........... 4.1.1 How to Run BIOS Setup? ............4.1.2 BIOS Setup Menu ..............Main Menu ................4.2.1 Advanced Menu ..............4.2.2 Security Menu ................ 4.2.3 Boot Menu ................4.2.4 Exit Menu ................
-
Page 5: Preface
CHAPTER PREFACE... -
Page 6: Regulations Information
. Regulations Information CE compliance This device is classified as a technical information equipment (ITE) in class B and is intended for use in living room and office. The CE-mark approves the conformity by the EU-guideliness: — EMC Directive 2014/30/EU, —... -
Page 7: Safety Instructions
1.2 Safety Instructions Do not apply heavy pressure to the computer or subject it to any form of strong impact as this can damage the computer's components or otherwise cause it to malfunction. Never cover or block the air vents including those located at the base of the computer. -
Page 8: Getting To Know The Basics
CHAPTER GETTING TO KNOW THE BASICS... -
Page 9: Op-Lp1 Product Specification
. . OP LP Product Specifications This user’s manual provides technical information of instructions and illustrations on how to operate this notebook for the customer. Please read this manual carefully before using this notebook. Physical Characteristic ..........(WxDxH) 14”x9.3”x0.8” Dimension .................. - Page 10 Audio ............Azalia standard Audio Codec D3 Mode ......... (x2) Realtek Audio (2W each) Speaker Digitial Microphone Support with Camera Inputs Mechanical LED RGB KB (Gen 2/RGB Backlight) Keyboard ....(WxD) 4”x2.8” (Option: TP+Finger Print) TouchPad Display ..........15.6" Narrow, FHD, 16:9, 144Hz ..............
- Page 11 Power AC Adapter ...... 100-240VAC 50/60Hz (Automatics voltage adjustment) 150 Watts (19V/7.89A), 3 Pins (Reports Only) 120 Watts (19V/6.32A), 3 Pins ..Soft Pack Li-Polymer Battery, SW Gas Gauge IC Battery 3 Cells (3s1p 4100mAh) 46.74wh CAUTION: MODEL IS DESIGNED TO USED WITH THE DC INPUT: 19V/7.89A (Optional) or 19V/6.32A...
-
Page 12: Op-Lp2 Product Specification
. . OP LP Product Specifications This user’s manual provides technical information of instructions and illustrations on how to operate this notebook for the customer. Please read this manual carefully before using this notebook. Physical Characteristic ............ (WxDxH) 14”x9.5”x1” Dimension .................. - Page 13 Audio ............Azalia Standard Audio Codec D3 Mode ......... (x2) Realtek Audio (2W Each) Speaker Digitial Microphone Support with Camera Inputs Mechanical LED RGB KB (Gen 2/RGB Backlight) Keyboard ........(WxD) 5.1”x2.8” (Mylar/Glass) TouchPad Display ............15.6", FHD, 16:9, 144Hz ..............
- Page 14 Power AC Adapter ...... 100-240VAC 50/60Hz (Automatics voltage adjustment) 180 Watts (19.5V/9.23A), 3 Pins ....Soft pack LiPo Battery, SW Gas Gauge IC Battery 3 cells (3s1p 4100mAh) 46.74wh CAUTION: MODEL IS DESIGNED TO USED WITH THE DC INPUT: 19.5V/9.23A...
-
Page 15: Preparing Your Computer
2.2 Preparing Your Computer Connect the AC adapter’s DC output plug to the DC IN jack. The display panel can be opened to a wide range of angles for optimal viewing. Press the power button to turn on your notebook computer. -
Page 16: Product Overview
2.3 Product Overview Please become familiar with each component before you operate the computer. Top-Open View The product’s color/ LED color, I/O port, indicator location, and specification will depend upon the actual shipping product. CAUTION: When computer is not in use, keep LCD screen closed for dust prevention. - Page 17 Webcam The built-in webcam allows picture taking or video recording from your computer. Camera Status LED The LED indicator shows when the build-in camera is in use. Microphone Built-in microphone. LCD screen Your notebook computer's default display. Caps Lock Status LED Default: Green.
- Page 18 Fan Boost Button FAN full speed ON/OFF Keyboard Full 15.6" KB with RGB backlight support. (The keyboard will depend upon the actual product shipped) TouchPad/ClickPad Touch-sensitive pointing device which functions like the mouse. Tochpad LED indicator/TochPad switch Right Side View USB Ports Connects any USB device.
- Page 19 Left Side View 2 3 4 Vents The thermal vents are designed to cool the internal components and avoid overheating. Network Jack This jack lets you connect to a LAN. USB Ports Connects any USB device. (such as USB Zip drive, keyboard or mouse). Microphone Input Jack Connects amplified speakers, headphones or microphone into this jack.
- Page 20 Bottom View The product’s thermal vent will depend upon the actual shipping product. Vents The thermal vents are designed to cool the internal components and avoid overheating. HDD / RAM / SSD / WLAN Compartment Cover Screws You can remove the screws to install or remove the HDD / RAM / SSD / WLAN compartment cover.
- Page 21 HDD / RAM / SSD / WLAN Compartment View (Optional) NVME NVME (SATA) Battery Speaker If need to upgrade SATA SSD to PCIE SSD: Please contact technical support and after-sales service. CAUTION: Do not put the computer on your lap or other parts of the body to avoid injury from the heat.
- Page 22 Front Side View Light Bar Light bar (choose color from APP). Back Side View 3 4 5 Vents The thermal vents are designed to cool the internal componentsand avoid overheating. Mini DisplayPort Connect to an external display, monitor, or home theater system. HDMI Port Supports high-definition digital video connections.
-
Page 23: Getting Started
CHAPTER GETTING STARTED... -
Page 24: Ac Adapter
3.1 AC Adapter Please note that it is strongly recommended to connect the AC adapter and use the AC power while using this notebook for the first time. When the AC adapter is connected, the battery is being charged immediately. Attach the AC adapter when you need to charge the battery or want to operate from AC power. -
Page 25: Knowing The Keyboard
NOTE: The power adapter can become hot when in use. Please be sure the AC adapter is not covered with any materials and kept away from exposed parts of your body. The AC adapter appearance may vary depending on your region. 3.2 Knowing the Keyboard The following defines the colored hot keys on the Keyboard. -
Page 26: For Keyboard Users
3.2.1 For Keyboard Users To activate these functions, press the hot key associated with the desired function as below: Function Keys Keypad Function Description Press this key combination Suspend: (Fn+F1) to enter sleep mode. Press this key combination Windows (Fn+F2) to turn Windows Lock/On: Lock/On. - Page 27 Keypad Function Description Keyboard Press this key combination (Fn+F6) to decrease brightness Brightness down: of Keyboard. Press this key combination Keyboard (Fn+F7) to increase brightness Brightness of Keyboard. Press this key combination Mute: (Fn+F8) to enter Mute Mode. Volume Press this key combination down: (Fn+F9) to turn the volume down.
- Page 28 Keypad Function Description Search Press this key combination (Windows logo key+Q) to open the Charm: search charm and search apps. (Optional) Press this key combination Settings Charm: (Windows logo key+I) to open the settings charm. (Optional) Share Press this key combination Charm: (Windows logo key+H) to open the share charm.
-
Page 29: Using The Touchpad/Clickpad
3.3 Using the TouchPad/ClickPad The TouchPad/ClickPad is a rectangular electronic panel located just below your keyboard. Click twice within 0.5”x0.5” of left corner to open or close (Green light) TouchPad functionality. You can use the static-sensitive panel of the TouchPad/ClickPad to slide and move the cursor. Press the left (1) and right (2) buttons located on the edge of the TouchPad/ClickPad to make selections and run functions. -
Page 30: Bios Setup
CHAPTER BIOS SETUP... -
Page 31: About Bios Setup
4.1 About BIOS Setup 4.1.1 When to Use BIOS Setup ? You may need to run the BIOS Setup when: • An error message appears on the screen during system boot-up and requesting to run SETUP. • You want to change the default settings for customized features. •... -
Page 32: Bios Setup Menu
NOTE: The drivers, BIOS and utilities bundled in the support DVD may vary by model and are subject to change without notice. 4.2 BIOS Setup Menu Once you enter the BIOS Setup Utility, the Main Menu will appear on the screen. Select tags to enter the other menus. Main Menu Show system overview about memory size, main HDD or ODD and setting of system time and date. -
Page 33: Main Menu
4.2.1 Main Menu System Time This item allows you to set the system time. There is a small internal (CMOS) battery which is designed to maintain your system clock. It is designed to maintain time even when the PC is powered down or in sleep mode. The time format is [hour:minute:second]. - Page 34 Day of the week, from Sun to Sat, which is determined by BIOS (read-only). The month from 01 (January) Month to 12 (December). Date The date from 01 to 31. Year The year can be adjusted by users. Total Memory This allows you to see the total amount of memory.
-
Page 35: Advanced Menu
4.2.2 Advanced Menu Wake on LAN Enable/Disable integrated LAN to wake the system. Serial ATA HDD It will show AHCI SATA HDD info. NVMe Device Will show NVMe Device info. Intel Virtualization Technology When enabled, a VMM can utilize the additional hardware capabilities provided by Vanderpool Technology. -
Page 36: Security Menu
4.2.3 Security Menu Change Administrator Password When this item is selected, a message box shall appear on the screen as below: Enter New Password Type a maximum of 20-digit password and press [Enter]. The password typed now will replace any previously set password from CMOS memory. - Page 37 Select “Change User Password” to give or to abandon password setting, same as Change Administrator Password item above. Note that Administrator Password field allows users to enter and change the settings of the BIOS SETUP UTILITY, while User Password field only allows users to enter the BIOS SETUP UTILITY without having the authorization to make any change.
-
Page 38: Boot Menu
4.2.4 Boot Menu • Boot Configuration Configure Settings during System Boot. • LAN Remote Boot [Disable]: Boot from LAN or not. • Set Boot Priority (1st/2nd/3rd/..Boot) Specify the boot sequence from the available devices. A device enclosed in parenthesis has been disabled in the corresponding type menu. -
Page 39: Exit Menu
4.2.5 Exit Menu • Save Changes and Reset Exit system setup after saving the changes. F4 key can be used for this operation. • Discard Changes and Exit Exit system setup without saving any changes. ESC key can be used for this operation. •... -
Page 40: Important Product Information
Important Product Information This product information pamphlet contains important information about your Overpowered (or “Product”) and how to use it as well as the One-year Limited Warranty provided by Overpowereds, LLC (the “Company”), included with your purchase. Failure to follow these safety instructions could result in fire, electric shock, damage to your Product or property, or serious injury to you or others. -
Page 41: Disposal And Recycling Information
Receipted invoice must be presented upon request as proof of purchase. The Overpowered Service Center listed below will repair your Product or if repairs cannot be made, Overpowered will replace your Product with the same or similar Product at no charge to you. If the Product is defective as specified in... - Page 42 Product is received damaged by the Overpowered service center, it is the responsibility of the consumer to file a claim against the shipping carrier. The Overpowered service center will only store the damaged product for thirty (30) days and reserves the right, in its sole discretion to dispose of the damaged product or ship it back to the consumer at consumer's expense after thirty (30)days.
-
Page 43: Contact Information
Opting out of this dispute resolution procedure will not affect the coverage of the Limited Warranty in any way, and you will continue to enjoy the benefits of the Limited Warranty. 5.3 Contact Information To obtain Warranty service, please contact OVERPOWERED Products service@opowered.com warranty@opowered.com 800-379-3820... - Page 44 GAME OVER by ESPORTS ARENA...
