JAMO STUDIO8 Series User Manual

Hide thumbs Also See for STUDIO8 Series:

USER MANUAL

STUDIO8 SERIES

S 81 0 SUB | S 808 SUB

Table of Contents

Need help?

Do you have a question about the STUDIO8 Series and is the answer not in the manual?

Page 1 USER MANUAL STUDIO8 SERIES S 81 0 SUB | S 808 SUB...
Page 2 INSPECTION We want your new speaker system to look as good as it did leaving the factory! Please check promptly for any transit damage. Carefully unpack your new speaker system and verify the components against the packing list. In extreme circumstances, items may have become damaged in transit.
Page 3 ENGLISH 6 ’ - 15 ’ + Optional X=Y=Z + Optional + Optional Figure 1 Speaker Placement in Listening Area...
Page 4 “LOWPASS” Control - The crossover point chosen determines where low bass frequencies are “handed off” from the speakers to the subwoofer. If setting the crossover point in the receiver, turn the Lowpass Filter knob on the subwoofer to the farthest point right (160Hz).
Page 5 LOW PASS VOLUME (Hz) PHASE LINE IN 80Hz 120Hz 0° AUTO 180° DOWN 40Hz Processor/Pre-Amp/Receiver LFE OUTPUT LFE Output on Processor/Pre-Amp/Receiver connected to LFE input on subwoofer amplifier Figure 2 Figure 3 Line Level Connections Rubber Feet...
Page 7 ©2014 Klipsch Group, Inc. All Rights Reserved Jamo is a trademark of Klipsch Group, Inc., registered in the US and other countries. Engineered by Klipsch Group, Inc., USA, Made in China A Wholly-Owned Subsidiary of VOXX International Corporation 1-800-554-7724 • 3502 Woodview Trace, Indianapolis, IN USA 46268-1104...

S 810 sub S 808 sub
