SHDFTRX
System HD Optical HD-SDI Transceiver
CONTENTS
INTRODUCTION TO THIS INSTALLATION
MANUAL................................................................ 2
MODULE DESCRIPTION ................................. 4
FEATURES ............................................................ 6
TECHNICAL PROFILE.......................................... 7
TRANSMITTER INPUT..................................... 7
Active Loop-through..................................... 7
TRANSMITTER OUTPUTS .............................. 7
RECEIVER INPUT ............................................ 7
RECEIVER OUTPUTS ..................................... 7
SWITCHES, BOARD EDGE ............................. 7
INDICATOR LEDS............................................ 7
ROLLCALL  .................................................... 8
OPTIONS.......................................................... 8
REAR INTERFACE CONNECTIONS.................... 9
INPUT ............................................................. 11
ELECTRICAL LOOP-THROUGH ................... 11
OUTPUT OPTION .......................................... 12
OUTPUT OPTION .......................................... 12
OUTPUT OPTION .......................................... 12
STANDARD RECEIVER INPUT ..................... 13
OUTPUTS....................................................... 13
WDM COMBINED RECEIVER INPUT AND
OPTICAL TRANSMITTER OUTPUT .............. 14
ROLLCALL MENU SYSTEM .............................. 15
SHDFTRX
Version 1 Issue 5
Operation Manual
OPERATION
180203
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SHDFTRX0WQ2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Snell & Wilcox SHDFTRX0WQ2

  • Page 1: Table Of Contents

    SHDFTRX OPERATION System HD Optical HD-SDI Transceiver Operation Manual CONTENTS INTRODUCTION TO THIS INSTALLATION MANUAL..............2 SCOPE OF THIS OPERATION MANUAL .... 4 MODULE DESCRIPTION ......... 4 FEATURES ............6 TECHNICAL PROFILE.......... 7 TRANSMITTER INPUT........7 Active Loop-through........7 TRANSMITTER OUTPUTS ......7 RECEIVER INPUT ..........
  • Page 2: Manual

    SHDFTRX OPERATION Introduction to this Operation Manual This manual covers the operation and use of the modules described below. WARNING… THE FRONT PANEL OF THE UNIT MUST NOT BE OPENED BY THE OPERATOR. ACCESS IS ONLY PERMITTED FULLY QUALIFIED INSTALLATION ENGINEERS. System HD Modules must only be installed and/or replaced by qualified service personnel, with reference to the System HD Installation guide.
  • Page 3 SHDFTRX OPERATION Manufacturers Notice Copyright protection claimed includes all forms and matters of copyrightable material and information now allowed by statutory or judicial law or hereinafter granted, including without limitation, material generated from the software programs which are displayed on the screen such as icons, screen display looks etc. Reproduction or disassembly of embedded computer programs or algorithms is prohibited.
  • Page 4: Scope Of This Operation Manual

    : SHDFTRX0WQ4 – Standard Transceiver with 4 optical outputs from the Transmitter SHDFTRX0WQ2 – Standard Transceiver with 2 optical outputs from the Transmitter SHDFTRX0WQ0 – Standard Transceiver with a single optical output from the Transmitter SHDFTRX0WQC – WDM Transceiver with a single optical interface (Use with SHDFTRX6WQD) SHDFTRX6WQD –...
  • Page 5 SHDFTRX OPERATION device providing up to four identical optical outputs. This will allow easy identification of the laser option The options for this split are either a four way chosen and the type of interface card selected splitter, a two way splitter, or a single output. when referring to this manual at a later date.
  • Page 6: Features

    SHDFTRX OPERATION Features Optical transmission and recovery capability on single board SMPTE 292M 1.485Gbit/s HD-SDI data rates supported SMPTE 292M recommended SC/PC singlemode user interface connectors Four coaxial outputs from single optical input Four optical outputs from single coaxial input Transmission distances up to 20km Two optical output wavelengths (1300/1550nm) available for laser transmitter...
  • Page 7: Technical Profile

    SHDFTRX OPERATION Technical Profile Optical power input Max. <-3dBm range Min. >-23dBm Detector damage +10dBm TRANSMITTER INPUT threshold Electrical 1.485GBit/s HD-SDI Connector Format BNC 75ohm panel jack RECEIVER OUTPUTS Input Cable Length >100m Electrical 1.485Gbit/s HD-SDI Peak-to-peak 800mV ± 10% Connector Format BNC 75ohm panel jack signal amplitude...
  • Page 8: Rollcall

    SHDFTRX OPERATION Notes… RollCall™ RollCall control 1. The transmitter section of the transceiver options: can have a different laser type depending RollCall monitoring General alarm on its intended application. Refer to the options: Supply voltage levels laser device option code on page 4 to Board temperature identify what laser is fitted to the board.
  • Page 9: Rear Interface Connections

    SHDFTRX OPERATION Rear Interface Connections Rear Interface Notation Guide Electrical HD-SDI Input A High Definition Serial Digital electrical input though a 75 Ω BNC connector is denoted in the way shown opposite. The “ H ” denotes the High Definition element and the “ n ” is the connection number for that particular rear interface.
  • Page 10 SHDFTRX OPERATION Multiple Optical HD-SDI Outputs Multiple High Definition Serial Digital optical outputs though two or four SC/PC single mode panel uniters are denoted in the way shown opposite. The numbers 1 to 4 are arranged to indicate the individual element within the multiple output connector.
  • Page 11: Standard And Wdm Transmitter Input

    SHDFTRX OPERATION Standard and WDM Transmitter Input Electrical HD-SDI Used On : SHDFTRX0WQ4 SHDFTRX0WQ2 SHDFTRX0WQ0 SHDFTRX0WQC SHDFTRX6WQD The high definition serial digital electrical input for the laser transmitter is connected to a 75 Ω BNC connector. This connector is shown opposite and is labelled H2 on the rear panel.
  • Page 12: Standard Transmitter Outputs

    Do not remove the covers from the uniters until a fibre connection is ready to be inserted. Optical HD-SDI Output – Dual Output Option Used On : SHDFTRX0WQ2 The high definition serial digital optical outputs are provided via a dual PC/SC single mode panel mounted uniter set.
  • Page 13: Wdm Transmitter Interfaces

    Standard Receiver Input Optical HD-SDI Input Used On : SHDFTRX0WQ4 SHDFTRX0WQ2 SHDFTRX0WQ0 The high definition serial digital optical input is connected to an SC/PC single mode panel uniter. This connector is shown opposite and is labelled H8 on the rear panel.
  • Page 14: Optical Transmitter Output

    SHDFTRX OPERATION WDM Combined Optical Receiver Input and Optical Transmitter Output Optical HD-SDI Input and Output Used On : SHDFTRX0WQC SHDFTRX6WQD For the WDM options of this module the high definition serial digital optical input is combined with the optical output from the transmitter. This is achieved using different optical wavelengths for the transmit and receive paths.
  • Page 15: Rollcall Menu System

    SHDFTRX OPERATION RollCall Menu System When a System HD Control and Monitor board is fitted in the enclosure a range of monitoring information is available to RollCall  External Monitoring Description General alarm Input power fault or overcurrent trip or system failure Supply voltage levels Actual voltage levels...
  • Page 16: Rollcall Monitoring Features

    SHDFTRX OPERATION Rollcall Monitoring Features Module Infrastructure: General Alarm Supply Voltage Levels Board Temperature Incoming Signal analysis: Input Status Line Standard Frame Type Frame Rate CRC Error analysis: CRC Error Count CRC Error Total CRC Reset Bias/EQ – The value in this field is a guide to the strength of equalisation that is being applied to the input signal for longer cable runs.
  • Page 17 SHDFTRX OPERATION Manual Revision Record Date Version No. Issue No. Change Comments 16/06/01 Revised draft document Issued 22/08/01 Edited current feature list Only New issue released states features that are present in current release A1.0.000 030402 New monitoring features added New issue released 100203 Corrections...
