Antenna or Cable Connection
Antenna or Cable Connection
1. Analog and Digital TV signals provided on antenna
- Wall Antenna Socket or Outdoor Antenna without a Cable Box Connections
- For optimum picture quality, adjust antenna direction if needed.
Multi-family Dwellings/Apartments
(Connect to wall antenna socket)
Wall Antenna
Socket
VHF Antenna
UHF Antenna
Outdoor
Antenna
Single-family Dwellings /Houses
(Connect to wall jack for outdoor antenna)
2. Analog and Digital TV signals provided on cable
Cable TV Wall
Jack
DLP Projection TV
Bronze Wire
RF Coaxial Wire (75 ohm)
Turn clockwise to tighten.
Turn clockwise to tighten.
RF Coaxial Wire (75 ohm)
ANTENNA
Bronze Wire
Be careful not to bend the bronze wire when
connecting the antenna.
CABLE
Bronze Wire
