BW60 SportBuds
Models: GDI-EXBW60...69
User Guide
Control Buttons & Operations
On / Off
PRESS & HOLD the Multi-Function Button
for 4 seconds to turn
it on. The LED Indicator will flash BLUE. PRESS & HOLD
for about
4 seconds, until the LED flashes RED, to turn the SportBuds off.
Bluetooth
LED Indicator
When turned on, the SportBuds will enter into
Bluetooth Pairing Mode and search for your
Bluetooth device to pair and connect. The LED
Indicator will flash BLUE and RED. Refer to
Bluetooth Pairing & Audio for details.
Play / Pause / Answer
PRESS
ONCE to pause & play song tracks
and to answer incoming mobile calls & end calls.
PRESS & HOLD
for 1 second to reject a call.
DOUBLE-CLICK
to redial your last call.
Volume / Track Selection
PRESS _ ONCE to decrease the volume.
PRESS & HOLD _ for 2 seconds for previous
track selection.
PRESS + ONCE to increase the volume.
PRESS & HOLD + for 2 seconds to advance
the track selection.
NOTE: Some Bluetooth devices must be manually set at maximum
audio level.
Your SportBuds will beep to indicate when maximum or minimum
volume setting is reached.
Advertisement
Table of Contents
Summary of Contents for EcoxGear BW60 SportBuds
- Page 1 BW60 SportBuds Models: GDI-EXBW60...69 User Guide Control Buttons & Operations On / Off PRESS & HOLD the Multi-Function Button for 4 seconds to turn it on. The LED Indicator will flash BLUE. PRESS & HOLD for about 4 seconds, until the LED flashes RED, to turn the SportBuds off.
-
Page 2: Connecting With Bluetooth
Turn on your smartphone’s Bluetooth. Set the smartphone to Pairing Mode. Available Bluetooth connections shall appear. Select ‘ECOXGEAR’ from the list of discovered devices on your smartphone. Wait a few seconds until the connection is completed. NOTE: Some Bluetooth devices may ask for a password. Enter, ‘0000’... - Page 3 Bluetooth Section within the device currently connected to the SportBuds and delete the ‘ECOXGEAR’ Bluetooth selection from your phone. The SportBuds will then be available to pair & connect to an alternate Bluetooth enabled smartphone / Audio Device.
-
Page 4: Troubleshooting
SportBuds volume to a reasonable level. The higher the volume for a prolonged time, the higher the risk of damaging your hearing. Use your BW60 SportBuds responsibly! It is dangerous, and even illegal in some areas, to use earphones in situations that require your full attention, such as driving a car or motorcycle, riding a bicycle, and crossing a street. -
Page 5: Specifications
Specifications Unit Weight Charging Time 2 ounces Approximately 1 hour Output Power Optional Accessories For Charging* <100mW AC (5V, 1A) USB Wall Outlet Power Adapter AC (5V, 1A) USB Car Power Adapter Frequency Range 20Hz-20,000Hz Bluetooth Bluetooth® 4.2; Up to 33 ft / 10 m Power Source 3.7V, 100mAh Supported Bluetooth Profiles... - Page 6 Read and follow all instructions. Use only as intended. The ECOXGEAR Bluetooth earphones are intended to be used indoors or outdoors. The earphones have been tested to IPX6 waterproofing standards, which means that they are sweatproof. However, the unit and USB cable are NOT waterproof.
-
Page 7: Limited Manufacturer's Warranty
2) Never use your ECOXGEAR in a wet environment. 3) Never attempt to fix, repair your ECOXGEAR unit. Please send it back to Grace Digital for any assessments and repairs.
