- Page 1 EASYLIFE User Guide Oil/Gas-fired boiler NeOvo EcoNox EF 36 EF 46 S U S T A I N A B L E C O M F O R T ®...
- Page 2 Dear Customer, Thank you very much for buying this appliance. Please read through the manual carefully before using the product, and keep it in a safe place for later reference. In order to ensure continued safe and efficient operation we recommend that the product is serviced regularly. Our service and customer service organisation can assist with this.
-
Page 3: Table Of Contents
Contents Contents Safety ................... . 5 General safety instructions . - Page 4 Contents 8.2.2 Setting the heating ..............28 8.2.3 Setting the domestic hot water temperature .
-
Page 5: Safety
1 Safety Safety General safety instructions Danger This appliance is not intended for use by persons (including children) with reduced physical, senso ry or mental capabilities, or lack of experience and knowledge, unless they have been given su pervision or instruction concerning use of the ap pliance by a person responsible for their safety. - Page 6 1 Safety Important The installation must comply on all points with prevailing regulations and directives, which gov ern work and interventions in individual homes, blocks of flats and other buildings. Hydraulic safety Important Respect the minimum and maximum water inlet pressure to ensure correct operation of the boiler: refer to the chapter Technical Specifications.
-
Page 7: Recommendations
1 Safety Danger If you smell flue gases: 1. Switch off the appliance. 2. Open the windows. 3. Evacuate the premises. 4. Contact a qualified professional. Caution Do not neglect to service the boiler. Contact a qualified professional or take out a maintenance contract for the obligatory annual servicing of the boiler. -
Page 8: Liabilities
1 Safety Important Insulate the pipes to reduce heat losses to a mini mum. Caution Have the boiler and heating system drained by a qualified professional if the home is left empty for a long period of time and there is a chance of frost. -
Page 9: User's Liability
1 Safety 1.3.3 User's liability To guarantee optimum operation of the system, you must abide by the following instructions: Read and follow the instructions given in the manuals provided with the appliance. Call on a qualified professional to carry out installation and initial commissioning. -
Page 10: About This Manual
2 About this manual About this manual Symbols used 2.1.1 Symbols used in the manual This manual uses various danger levels to draw attention to special in structions. We do this to improve user safety, to prevent problems and to guarantee correct operation of the appliance. -
Page 11: Technical Specifications
3 Technical specifications Technical specifications Homologations 3.1.1 Certifications The boiler complies with current standards. CE identification number: 0085CQ0006 3.1.2 Oil categories Tab.1 Type of oil that can be used Maximum viscosity 6 mm /s at 20 °C Non-road diesel with a maximum FAME content of 7 % Note To be used exclusively for a boiler fitted with a burner with a heater. - Page 12 3 Technical specifications Product name EF 36 EF 46 Auxiliary electricity consumption elmax Full load 0.156 0.160 Part load elmin 0.064 0.066 Stand-by 0.004 0.004 Other specifications Standby heat loss 0.109 0.122 stby Ignition burner power consumption Annual energy consumption Sound power level, indoors Emissions of nitrogen oxides mg/kWh...
-
Page 13: Description Of The Product
4 Description of the product Description of the product General description The floor-standing oil boilers in the EF range have the following specifica tions: Heating only with possibility to produce domestic hot water by combining them with a domestic hot water tank High-efficiency heating Low polluting emissions Heating body in cast iron... -
Page 14: Description Of The Control Panel Inicontrol 2
4 Description of the product Description of the control panel IniControl 2 4.4.1 Description of the keys Fig.5 : back to the previous level without saving the modifications made : manual reset : accessing the heating parameters : lowering the value : accessing the domestic hot water parameters : raising the value : MODE display... - Page 15 4 Description of the product Display of PCB names Fig.9 The name of the PCB for which the parameters are displayed is shown as 3 characters. Fig.10 CU-OH04 central unit PCB for the boiler ...CUO / H04... Fig.11 SCB-04B additional PCB: 2 circuit ...SCB / 04- / B...
-
Page 16: Utilisation With The Control Panel B-Control
5 Utilisation with the control panel B-Control Utilisation with the control panel B-Control Browsing in the menus Press any key to turn on the backlight for the control panel screen. Important If no key is pressed within 3 minutes, the backlight will go out. key is used to access the various menus: Tab.3 Menus available... -
Page 17: Stopping Domestic Hot Water Production
5 Utilisation with the control panel B-Control 5.3.2 Stopping domestic hot water production Fig.20 1. Turn the setting button all the way to the left until is dis played. Note Frost protection continues to run on the domestic hot water tank. The venting cycle is not tripped when domestic hot water produc... -
Page 18: Utilisation With The Control Panel Inicontrol 2
6 Utilisation with the control panel IniControl 2 Utilisation with the control panel IniControl 2 Browsing in the menus Press any key to turn on the backlight for the control panel screen. Important If no key is pressed within 3 minutes, the backlight will go out. Fig.21 Press the 2 right-hand keys together to access the different menus: Tab.4... -
Page 19: Description Of The Pcbs
6 Utilisation with the control panel IniControl 2 The display shows the operating status of the boiler, the heating flow tem perature and any error codes. 6.2.1 Description of the PCBs Fig.25 When commissioning the boiler, the PCB displayed is the CU-OH04. The primary circuit is managed by the CU-OH04 central unit PCB. -
Page 20: Shutdown
6 Utilisation with the control panel IniControl 2 Shutdown 6.3.1 Switching off the heating Note Heating mode can be managed via the TIME PROG sub-menu dedicated to timer programming. Fig.29 1. Go to stop mode by pressing the key. MW-5000027-4 Fig.30 2. -
Page 21: Shutting Down The Installation
6 Utilisation with the control panel IniControl 2 Fig.33 2. Select domestic hot water production mode pressing the key. 3. Confirm by pressing the key. MW-5000136-3 Fig.34 4. Select domestic hot water production shut-down by pressing the key. The screen displays: The frost protection function continues to run. -
Page 22: Control Panel Settings B-Control
7 Control panel settings B-Control Control panel settings B-Control List of parameters 7.1.1 Information menu Tab.5 Information list Information Description Display Heating water temperature (°C) °C The symbol flashes Domestic hot water temperature (°C) The symbol flashes °C If no domestic hot water sensor connected: dis play —... -
Page 23: Modifying The Domestic Hot Water Temperature Setpoint
7 Control panel settings B-Control 7.2.2 Modifying the domestic hot water temperature setpoint Fig.37 1. Set the domestic hot water temperature setpoint by turning the set ting button MW-3000246-3 Fig.38 2. Go back to the main display by pressing the key for two seconds. -
Page 24: Control Panel Settings Inicontrol 2
8 Control panel settings IniControl 2 Control panel settings IniControl 2 List of parameters 8.1.1 User Menu Fig.39 MW-2000435-1 1 Sub-menu available 3 Setting parameters 2 Name of the PCB or circuit Tab.6 List of User sub-menus Sub-menu Description Name of the PCB or circuit Main heating circuit Additional heating circuit B Additional heating circuit C... - Page 25 8 Control panel settings IniControl 2 Parameter Description CU-OH04 factory Factory setting setting SCB-04B / SCB-04C CP085 Activity zone 6 temperature set point 20°C 20°C Can be set from 5 to 30°C CP140 Reduced cooling set point not available 30°C Can be set from 20 to 30°C CP141 Comfort cooling set point...
-
Page 26: Counters /Time Prog / Clock Menus
8 Control panel settings IniControl 2 Tab.8 List of parameters in the sub-menu of the User menu Parameter Description CU-OH04 factory setting DP060 Number of timer programs selected for domestic hot water production mode Can be set from 0 to 2 DP070 Domestic hot water temperature set point in comfort mode 55°C... - Page 27 8 Control panel settings IniControl 2 Sub-menu Description Timer programming for the main heating circuit Timer programming for the additional heating circuit B Timer programming for the additional heating circuit C Timer programming for the domestic hot water circuit Setting the clock and the date (1) This menu is not displayed if a room sensor is connected.
-
Page 28: Setting The Parameters
8 Control panel settings IniControl 2 Parameter Description Unit CU-OH04 PCB SCB-04B PCB SCB-04C PCB AC002 Number of hours' burner operation since the last hours service AC003 Number of hours' operation since the last service hours AC004 Number of burner start-ups since the last service SERVICE Resetting the maintenance service : hour run meters... -
Page 29: Setting The Domestic Hot Water Temperature
8 Control panel settings IniControl 2 Fig.42 1. Access the heating parameters by pressing the key. MW-5000144-3 Fig.43 2. Select the desired circuit, if there are several PCBs, by pressing the key. 3. Confirm the selection by pressing the key. The status of the heating and the associated heating water tem... - Page 30 8 Control panel settings IniControl 2 Fig.47 4. Select the desired day number by pressing the key until the icon dedicated to the desired day flashes. Day selected Description every day of the week Monday Tuesday MW-1000594-3 Wednesday Thursday Friday Saturday Sunday Note...
-
Page 31: Activating Manual Forcing For Heating
8 Control panel settings IniControl 2 Times 06:00-08:00 06:00 08:00 11:30 14:00 17:30 22:00 11:30-14:00 17:30-22:00 8.2.5 Activating Manual Forcing for heating The Manual Forcing menu is only used with the heating mode. Fig.50 1. Accessing the Manual Forcing menu. Important The Manual Forcing menu is only available when the icon flash... - Page 32 8 Control panel settings IniControl 2 Sub-menu Description HMI control panel Tab.16 Values available (X) in the sub-menus Parameter Description Unit CU-OH04 SCB-04B PCB SCB-04C PCB AM010 Pump rotation speed AM012 Control system sequence: Status Note See following table AM014 Control system sequence: Sub-Status Note See following table...
- Page 33 8 Control panel settings IniControl 2 Control system sequence Tab.17 List of statuses and sub-statuses Status (parameter Sub-status (parameter = rest = system on standby = heat demand (boiler start-up) = anti-short cycle activated = isolating valve open = boiler pump or domestic hot water start-up = burner start-up = opening of the flue gas valve / oil valve = opening of the flue damper...
-
Page 34: Maintenance
9 Maintenance Maintenance General We recommend having the boiler inspected and serviced at regular inter vals. Caution Do not neglect to service the boiler. Contact a qualified professio nal or take out a maintenance contract for the obligatory annual servicing of the boiler. Failure to service the appliance voids the warranty. -
Page 35: Venting The Installation
9 Maintenance Venting the installation Fig.52 Venting the installation Any air in the appliance, the pipes or the valves must be removed in order to prevent annoying noises that may occur during heating or when tapping water. Proceed as follows: 1. -
Page 36: 10 Troubleshooting
10 Troubleshooting 10 Troubleshooting 10.1 Error messages B-Control 10.1.1 Error code display If an error is detected, the error code is displayed automatically. Fig.53 Error code display Note The reset is automatic. MW-3000240-4 10.1.2 Fault code display If a fault is detected, the fault code is displayed automatically. Fig.54 Fault code display Note... - Page 37 10 Troubleshooting Fig.58 2. Select the Malfunction menu by pressing the key. Fig.59 3. Select the PCB by pressing the keys. The icon appears. Confirm the PCB selection by pressing the key: the PCB name appears. Note parameter flashes. corresponds to the number of stored errors.
-
Page 38: 11 Environmental
11 Environmental 11 Environmental 11.1 Disposal and Recycling Fig.61 Recycling Warning Removal and disposal of the boiler must be carried out by a quali fied installer in accordance with local and national regulations. MW-3000179-03 11.2 Energy savings Energy-saving advice: Do not block ventilation outlets. Do not cover the radiators. -
Page 39: 12 Warranty
12 Warranty 12 Warranty 12.1 General We would like to thank you for buying one of our appliances and for your trust in our product. In order to ensure continued safe and efficient operation, we recommend that the product is regularly inspected and maintained. Your installer and our service department can assist with this. - Page 40 12 Warranty 7642076 - v04 - 27072017...
- Page 41 12 Warranty 7642076 - v04 - 27072017...
- Page 42 12 Warranty 7642076 - v04 - 27072017...
- Page 43 © Copyright All technical and technological information contained in these technical instructions, as well as any drawings and technical de scriptions supplied, remain our property and shall not be multiplied without our prior consent in writing. Subject to alterations.
