- Page 1 Ethernet Access Residential Unit 111x (EARU 1112/EARU 1113) Please read this manual carefully before operating your set. Retain it for future reference.
- Page 2 C O N T E N T S Product and personal safety guidelines Regulatory information About EARU 111x Checking package contents Installing EARU 111x Setting EARU 111x Open Source Software Notice...
-
Page 3: Precautionary Messages
Precautionary messages To prevent personal injury, equipment damage, and service interruptions, you must follow all precautionary messages in LG-Ericsson documentation and all local safety standards required by your service provider. The following precautionary messages appear in LG-Ericsson documentation:... -
Page 4: Safety Standards
Safety standards LG-Ericsson products conform to all relevant safety standards. The EARU 111x complies with the following safety standards: • IEC 60950-1:2005+A1:2009 and EN 60950-1:2006+A11:2009—Information technology equipment - Safety, Part 1 : General requirements • IEC 60825-1:2001 and IEC 60825-2:2004—Safety of Laser Products •... -
Page 5: Handling Optical Fibers
Handling optical fibers When you work with optical fibers, you must take the following general precautions: • Wear safety glasses when you install optical fibers. • Do not look into the opening of an optical fiber, or the opening of an optical fiber connector, if the optical fiber is active or the unit has the power turned on. - Page 6 Repairing optical fibers When an accidental break occurs in the optical fiber, do the following: • Report the location of the damaged optical fiber to both the service provider and the field repair personnel. • Power down all laser sources to the optical fiber or disconnect the remote optical fiber end from the laser sources.
- Page 7 CAUTIONS Warranty: Customers can receive repair services for this product under specified conditions. This warranty does not cover failure or damage of the product caused from, using a power adapter other than the one provided, PC failures, data loss, or negligent treatment of the product. For questions or to report damage or failures contact your service provider.
-
Page 8: Regulatory Information
Regulatory information This chapter contains the following information: • a list of global technical standards (electromagnetic compatibility, safety) to which the EARU 111x complies • a country-by-country list of specific regulatory text required by national authorities • information on the regulatory labels affixed to the product (artwork and location on the product) The list of global technical standards provided in this chapter is not exhaustive. -
Page 9: United States Of America
Country-specific regulatory information Canada This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. United States of America This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. - Page 10 • EN 300 386 V1.3.3 (Class B, other than telecommunications centres criteria) EN 60950-1:2006 +A11:2009 • • EN 60825-1:2001 • EN 60825-2:2004...
-
Page 11: Australia/New Zealand
The product bears the CE mark as illustrated in figures on page14. A signed Declaration of Conformity is available upon request. Brazil The EARU 111x conforms with the requirements of Anatel Resolution Number 442:2006 (EMC) for a Class B product and Anatel Resolution NR 238:2000 for product safety. -
Page 12: Names And Functions Of Each Part
About EARU 111x Thank you for selecting EARU 111x (1112, 1113). The EARU 111x is an equipment working as a modem in WDM-PON (Wavelength Division Multiplexing - Passive Optical Network). This product multiplexes 125Mbps to 100Mbps Fast Ethernet signals (maximum 4ea) into WDM-PON optical signal. -
Page 13: Rear View
Rear view EARU 1112 Optical port Ethernet port 1~4 Power(12V) EARU 1113 Optical port Ethernet port 1~4 Power(12V) Telephone port Rear port functions Indicator Color Function Power Power This is the port for the power adapter. (DC 12V,1A) For connection... -
Page 14: Bottom View
Bottom view Number item Label Location PEC & SN Label Rear 9.652mm x 27.94mm Hazard level 1 Front (per IEC 60825-2) 9.5mm x 15mm Regulatory Rear 40mm x 81mm... - Page 15 Specifications of EARU 111x Item Label Dimensions in mm 203(w) x 150(d) x 35(h) Power DC 12V, 1A Ambient Temperature 0℃ to 50℃ Humidity 20% to 80% Data rate 100Mbps SC/APC (optical), RJ45 (Ethernet), Connectors RJ11(POTS) LED indicators Power, Alarm, Data...
-
Page 16: Checking Package Contents
Checking package contents Before installing this product, ensure all parts are provided. Checking what is in the package Check the package to make sure the following items are included. Main body C clamps Cradle of EARU 111x for EARU 111x for EARU 111x Dedicated Power cable... -
Page 17: Preparing For Installation
Installing EARU 111x This section provides the specifications for EARU 111x installation, it also describes how to install it and connect it into a network. Preparing for installation Before you install the EARU 111x, review following information. Item Quantity Supplied Main body of EARU 111x C clamps for... -
Page 18: Installing The Product
Assemble the main body of EARU 111x and C clamps with the non-slip strips are facing down. Vertacal Mode Connect the C clamps on the EARU 111x as shown above. Insert the EARU 111x into the cradle. The LG-Ericsson logo should be at the bottom in the cradle. -
Page 19: Connecting Ethernet Cable
Connecting optical cable Check that the power is on.. Insert the green APC connector, into the optical port of the EARU 111x. Insert the other end of the APC optical cable into the optical outlet on your wall. Only green colored APC connector should be used. Other connector Types will not work properly. -
Page 20: Checking The Connection Status
Connecting power cable & checking the power status Make sure that both ends of the optical cable and the Ethernet cables are installed. And insert the connector of adapter, into the port of the EARU 111x. Make sure that the PWR LED (green) turns on. Do not pull on the power cable or adapter. - Page 21 Setting EARU 111x When you select to receive WDM-PON service, you do not have to make additional settings on the product to use it. Using Internet With a web browser such as the Internet Explorer on your PC, you can surf freely through the Internet. Note EARU 111x does not require any access programs such as ACEMAN_Pro, Enternet 300 and WinPoET;...
- Page 22 LG- Ericsson at : opensource@lgericsson.com This offer is valid for a period of three (3) years from the date of the distribution of this product by LG-Ericsson. ...
- Page 23 Copyright © 2010 LG-Ericsson Co., Ltd. All Rights Reserved. Copyright of this manual belongs to LG-Ericsson Co., Ltd. Reproduction, distribution or revision of part or all of contents in this manual in any form without written permission of LG-Ericsson Co., Ltd. is prohibited.
